Item # 1000 807 370
Model # FSS60428RST
USE AND CARE GUIDE
REDWOOD VALLEY 5 PIECE FIRE PIT CHAT SET
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HOMEDEPOT.CA
THANK YOU
We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of th
. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY REDWOOD VALLEY FSS60428RST
Summary of Contents for HAMPTON BAY REDWOOD VALLEY FSS60428RST
- Page 1 HOMEDEPOT.CA THANK YOU We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of th . We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 2: Table Of Contents
Table of Contents Pre-Assembly................3 Table of Contents ............2 Planning Assembly..............3 Important Safety Instructions ........2 Hardware Included..............3 Save These Instructions ............2 Read All Instructions Before Use ..........2 Chair Package Contents............4 Fire Pit Package Contents............5 Warranty ................ -
Page 3: Warranty
Warranty 2 YEAR FRAME AND 2 YEAR LIMITED FABRIC WARRANTY WHAT IS COVERED We warrant the frame to be free of manufacturing defects to the original purchaser for two years, and a two year limited warranty for fabric. WHAT IS NOT COVERED It remains the customer’s responsibility for freight and packaging charges to and from our service center. -
Page 4: Chair Package Contents
Pre-Assembly (continued) CHAIR PACKAGE CONTENTS Part Description Quantity Right arm Left arm Chair back Chair seat Support tube... -
Page 5: Fire Pit Package Contents
Pre-Assembly (continued) FIRE PIT PACKAGE CONTENTS Part Description Quantity Cover Barbecue grate Log grate Poker e r i HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON for further assistance. -
Page 6: Chair Assembly
Chair Assembly Attaching the support tube to the right leg Place the right leg (G) on a soft place. Attach the support tube (E) to the right leg (G) using M8x20 combination hex bolts (DD). Do not tighten all the bolts at this step. NOTE: Loosely tighten all the bolts using the wrench (GG). - Page 7 Attaching the support tube to the left leg Repeat the above step to attach the left leg (H) to the support tube (E) using M8x20 combination hex bolts (DD). Do not tighten all the bolts at this step. NOTE: Loosely tighten all the bolts using the wrench (GG). HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON for further assistance.
- Page 8 Attaching the connection bars to the legs Attach the two connection bars (F) to the right and the left leg (G & H) using M6x15 combination bolts (AA). Do not tighten all the bolts at this step. NOTE: Loosely tighten a ll the bolts using the he wrench (FF).
- Page 9 Attaching the support tube to the chair seat Attach the support tube (E) to the chair seat (D) using M8x20 combination hex bolts (DD). Do not tighten all the bolts at this step. NOTE: Loosely tighten a ll the bolts using the wrench (GG). HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON for further assistance.
- Page 10 Attaching the chair seat to the right arm Attach the back of the chair seat (D) to the back of the right arm (A) and secure by M6x15 combination bolt (AA). Attach the front of the chair seat (D) to the front of the right arm (A) using M6x30 combination bolt (CC).
- Page 11 Attaching the chair seat to the left arm Repeat step 4 to attach the chair seat (D) to the left arm (B). Do not fully tighten all the bolts at this step. HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON for further assistance.
- Page 12 Attaching the chair back to the arms Turn the chair right side up. Attach the chair back (C) to the right and the left arm (A & B) using M6x25 combination bolts (BB). Once all of the bolts are in place, fully tighten all the bolts using the hex wrench (FF) and the wrench (GG).
- Page 13 Checking the chair Ensure all connections are secure before use. HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON for further assistance.
-
Page 14: Fire Pit Assembly
Fire Pit Assembly Attaching the table legs to the table top Place the table top (K) upside down on a soft surface. Attach the table legs (L) to the table top (K) using M6x25 combination bolts (BB) and plastic washers (EE). Do not fully tighten all the bolts at this step. - Page 15 Fire Pit Assembly (continued) Attaching the leg connector to the table legs Attach the leg connector (M) to the legs (L) using M6x25 combination bolts (BB). Once all of the bolts are in place, fully tighten the bolts using the hex wrench (FF). HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON for further assistance.
-
Page 16: Care And Cleaning
Fire Pit Assembly (continued) Tightening all bolts and adding the fire pit Once all bolts are in place, fully tighten all bolts. Turn the table right side up. Carefully place the fire bowl (S) in the table rim (K). Then place the following in order, from bottom to top: the log grate (Q), the barbecue grate (P) and the lid (O) or the cover (N). When not in use, store the poker (R) under the log grate (Q). - Page 17 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HOMEDEPOT.CA Retain this manual for future use. Factory chair ID # FSS60428RA...
