- Page 1 PIPE & WALL VIDEO INSPECTION SYSTEM USER MANUAL 3188SD Series ASSEMBLING AND OPERATING INSTRUCTIONS...
- Page 2 ---------------------------------------------------------------------------------------- Read this manual carefully before operating this system...
-
Page 3: Table Of Contents
WARNING NEVER USE THIS DEVICE IN AN ENVIRONMENT WITH EXPLOSIVE MATERIALS SUCH AS GAS, OIL, ETC. Avoid using the device in extremely cold, hot or humid environment; otherwise it may damage the device. Do not drop or press hard on the device. Avoid using the parts / components from other manufacturers to this system, which may damage the equipment due to the un-compatibility. -
Page 4: Assembly Drawing And Parts List
Cable Reel......................4 Remote Control (For Operating DVR only)...........4 System Set-Up....................5 System Menu Setting................6 Recording Operation..............6 Recording Time Limit..................8 Schedule Recording..................8 Recording via Micro SD Card………........8 Video Recording Format................8 Voice Recording ...................8 Video Playing....................8 Select the Video File..................9 Fast Forwarding and Rewinding..............9 Compatible Video Format................9 Video Player Software …………..............9 Locating the Camera Head with Built-in Transmitter…………... -
Page 5: Specifications
1.5 m Video soft cable (short) Specifications ITEM DESCRIPTION Power adapter 110VAC~240VAC 13.5VDC1700mA Battery Case LI-ION battery Length of Cable □ □ 2 0m(65FT) 3 0m(100FT) □ 4 0m(130FT) Camera Light Source 12pcs built-in white LED Camera Angle-of-View 90°or 120°... -
Page 6: Application
Application WATER SUPPLY SYSTEM WASTE WATER SYSTEM ELECTRICAL AIR CONDITIONER CABLE DUCTING DUCTED VACCUM SYSTEMS PLUMBING BUILDINGS WARNING: NEVER USE THIS DEVICE IN AN ENVIRONMENT WITH EXPLOSIVE MATERIALS SUCH AS GAS, OIL, ETC. Know Your Device Fig 2... -
Page 7: Camera Head
Camera Head 1. 12 WHITE LEDS ( 8 for old versions) 2. LENS 3. SPRING 4. GOLD PINS 5. Built-in Transmitter: 512HZ (Options) Cable Reel 1. MALE PLUG (To monitor) 2. HANDLE 3. CABLE CONNECTER (To camera) 4. CABLE REEL Control... - Page 8 your device and see Figure 1-C); if you choose to use the charged battery, plug the power output cord of the battery to the DC 13.5V-Input Jack of the Monitor, then press the button on the Battery. The user can also charge the battery while using the device in the following way: plug the Charger to the wall AC socket and the other end to the jack on the Battery, and connect the power output cord of the battery to the DC 13.5V-Input Jack of...
-
Page 9: Recording Operation
Master reset: press OK again to perform a master reset Firmware update: locate the directory where new firmware is stored Browse File: Showing all files on the current Micro SD medium. Remove micro SD device(only when Micro SD device is connected) Always use this option before safely removing the micro SD device from the micro SD port Recording Operation... -
Page 10: Recording Time
let it run about 20 seconds each time when you try to record. Micro SD’s max memory is 32G bit. Recording time limit Sometimes you may forget to stop the recording after it is initiated. This unit is featured with a recording time limit. The default time limit is 60 minutes. If recording time over 1 hour, the system will record with a new file Schedule recording You can schedule a recording in advance. -
Page 11: Fast Forwarding And Rewinding
Use [►/ENT] button to start or pause the playing .Use [■/exit] button to stop or go back to previous menu. The screen will display “loading, please wait …” for a few seconds before playing videos. Fast forwarding and rewinding You can use [►] or [◄] button on the remote control to fast forwarding or rewinding (1x, 2x, 4x, or 8x, speed).Always press[►/ENT] button to go back to normal playing. -
Page 12: Recharging The Battery
one with 512 HZ built-in sonde transmitter. Recharging the Battery 1) Plug the charger into the AC socket on the wall and insert the other end into the DC Jack on the battery box (See Figure2- A) 2) Press the button (See Figure2-B) while the battery box is turned off. - Page 13 cables No Working of Misuse of the charger cable and power cord : to use the Battery right charger cable. Recharging...
