Summary of Contents for Hisense N3000
-
Page 18: Making Connections
Making Connections Connect an outdoor VHF/UHF antenna or cable. Outdoor Antenna TV JACK Cable ANT OUT ANT 1 DVB-T/T2/C Antenna Cable (75Ω) (not included) VHF/UHF Antenna Connecting a satellite antenna. TV JACK ANT 2 DVB-S/S2 (not included) HEADPHONE Connect Headphone for audio out of the TV. TV JACK HEADPHONE Headphone (not included) - Page 19 Making Connections Connect the USB devices such as hard drives, USB sticks and digital cameras for browsing photos, listening music and watching recorded movies. TV JACK USB 1 USB 2 DC 5V 0.5A(MAX) DC 5V 1A(MAX) NOTES When connecting a hard disk or a USB hub, always connect the mains adapter of the connected device to the power supply.
- Page 20 Making Connections Connect a component cable and an audio cable from an external COMPONENT IN A/V Device. The component output ports Y, P and P on the VCD or DVD can sometimes be identified as Y, C and C TV JACK VCR/DVD Player/Recorder/ Set-top box/Satellite Receiver/ Video Camera...
-
Page 21: Remote Control
Remote Control POWER: Switch the TV on or into standby mode INPUT: Select input sources C h a n n e l N u m b e r : D i r e c t c h a n n e l selection or numbers input EPG: Display the Electronic Program Guide (DTV mode) - Page 22 Remote Control Installing Batteries in the Remote Control 1. Slide the back cover to open the battery compartment of the remote control. 2. Insert two AAA size batteries. Make sure to match the (+) and ( - ) ends of the batteries with the (+) and ( - ) ends indicated in the battery compartment.
- Page 23 Turning the TV on for the First Time Turning the TV on for the First Time 1. Connect the mains cable to the mains socket after you have completed all the connections. 2. The first time you turn the TV on, it will go straight into the Installation Guide. It will assist you to specify the Language, Location, Network.
-
Page 24: Specifications
Specifications Features, appearance and specifications are subject to change without notice. 43" Item Width: 38.2 inches (970 mm) Without Stand Height: 22.4 inches (568 mm) Depth: 3.5 inches (88 mm) Dimension Width: 38.2 inches (970 mm) With Stand Height: 24.3 inches (618 mm) Depth: 8.5 inches (215 mm) Without Stand 21.6 lbs (9.8 kg) - Page 25 Specifications Features, appearance and specifications are subject to change without notice. 50" Item Width: 44.4 inches (1129 mm) Without Stand Height: 25.7 inches (654 mm) Depth: 3.3 inches (84 mm) Dimension Width: 44.4 inches (1129 mm) With Stand Height: 28.3 inches (719 mm) Depth: 10.1 inches (256 mm) Without Stand 29.3 lbs (13.3 kg)
- Page 26 Specifications Features, appearance and specifications are subject to change without notice. 55" Item Width: 49 inches (1244 mm) Without Stand Height: 28.4 inches (721 mm) Depth: 3.3 inches (85 mm) Dimension Width: 49 inches (1244 mm) With Stand Height: 30.9 inches (786 mm) Depth: 10.9 inches (278 mm) Without Stand 35.3 lbs (16 kg)
-
Page 27: Other Information
Other Information Recycling/Licenses WEEE (Waste Electronic Electric Equipment) European Directive 2012/19/EU This symbol on the product or on its packaging indicates that this product must not be disposed of with your household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment.
