- Page 1 T R A N S F O R M I N G T E C H N O L O G I E S , L L C O U T S T A N D I N G A L T E R N A T I V E S S T A T I C C O N T R O L BFN™...
-
Page 2: Table Of Contents
Description Series Ionizers ® Dependable, Balanced and Fast. BFN® AC ionizers, from Transforming Technologies, are built to last. Re- liable AC ionization technology is combined with supe- rior mechanical design to assure years of optimal static neutralizing performance. A full 1 year warranty. -
Page 3: Features
All BFN series AC ionizing blowers are designed for safe operation under normal use. Safety switches under the front and rear removable finger guards shut off the unit, protecting the operator during maintenance. Do not operate BFN series products in flammable ... - Page 4 Product Specifications Power Input Effective Coverage 120 V AC, 60 Hz., 36W 1’x5’ area coverage 220 V AC, 50Hz. Balance Dimensions 0 +10 volts 7.0” W x 10.25” H x 3.75” D (17.8W x 26.0H x 9.5D cm) Decay Time <...
-
Page 5: Operation Guide
Note: Failure to loosen the bracket knobs sufficiently may result in damage to the bracket mounting system. The only maintenance required for BFN series ion- izers is the periodic cleaning of the emitter points, inlet and outlet finger guards and the fan assembly. -
Page 6: Disassembly
Emitter point cleaning: All BFN series ionizing blowers include an integrated emitter point cleaning brush on the inlet fan guards. Turn the emitter point cleaners clockwise, then counter clockwise several times, until points are clean. When finished, return the point cleaning brush to its resting position. - Page 7 Note: The frequency of cleaning required for optimal performance from BFN ionizers depends on the environ- ment in which the BFN series ionizer operates. When finished cleaning, replace both front and rear fan guards.
- Page 8 Air Outlet Assembly A. Slide the slot on the upper back side of the front fan guard onto the metal case. B. Push upward from the bottom of the front fan and gently press into the metal casing, until attached. C.
-
Page 9: Periodic Verification
Caution: BFN series products have safety relay switches where the front and rear fan guards at- tach to the unit. These relays disable the fan/ ionizer operation when either fan guard is re- moved. Take care when attaching the fan guards to assure proper functioning of the product. - Page 10 Service and Warranty Transforming Technologies, LLC provides a limited warranty for the BFN Series Ionizers. All new products are guaranteed to be free from de- fects in material and workmanship for a period of one (1) year from the date of shipment. Liability...
- Page 11 Transforming Technologies offers a wide range of unique and outstanding products to detect, pro- tect, eliminate and monitor electrostatic charges.
- Page 12 TR A N S F OR MI N G T EC H N OL OGI ES, L LC 3719 King Rd. Toledo, Ohio 43617 Phone: 419-841-9552 Fax: 419-841-3241 E-mail: info@transforming-technologies.com...
