Installation and operation guide

3.4.1 Configuration within 20 m of the meters that you intend to read

3.4.1.1 For Ethernet and GSM

1. Insert SIM card or Ethernet cable.
2. Connect the power adapter – all LEDs on the
front turn on solidly for 30 seconds.
3. The power LED blinks for 4-5 minutes. When
the power and dot LEDs are solidly on, the
installation is complete.
4. Ensure that you can see READy Mini Concen-
trator on check.kamstrup.com. Note the time of
the reading.

3.4.1.2 For Wi-Fi installation

See the configuration steps for installations where the READy Mini Concentrator is more
than 20 m away from the meter(s)/sensor(s) that you intend to read. See section 3.4.2 for
further information.

3.4.2 Configuration more than 20 m from the meters that you intend to read

1. When the power and dot LEDs are solidly on, the
configuration can begin. This may take up to 5
minutes.
2. Press the top button on READy Mini Concentrator
(the Wi-Fi LED turns on solidly).
12
Concen r or c n be re d
L s re d 12-07-2018 02:00
See connec ed devices
Tes he new device
