- Page 1 & 5000 series showerhead Installation and operating instructions NSTALLERS PLEASE NOTE THESE INSTRUCTIONS ARE TO BE LEFT WITH THE USER 2180460B November 2005...
- Page 2 Riser rail assembly Fig.2 WARNING! Fig.1 Check there are no hidden cables or pipes before drilling holes for wall plugs. Use great care when using power tools near water. The use of a residual current device (RCD) is recommended. Fig.3 Decide the position for the rail on the wall within the shower area.
-
Page 3: Fitting The Hose And Showerhead
Riser rail assembly To remove a trim, push a small screwdriver or Fig.6 similar through the slot in the trim end and carefully pull away from the wall bracket. Slide the soap dish down the rail so that its bracket engages on top of the lower finishing trim. -
Page 4: Adjusting The Showerhead
Riser rail assembly ADJUSTING THE SHOWERHEAD Fig.11 This instruction book covers the operation and cleaning of Triton’s 5000 series electric and gravity showerheads. Your shower is supplied with a five position showerhead, with a rub clean face. Five showerhead patterns are available (fig.11). - Page 5 Riser rail assembly CLEANING Fig.12 Sprayplate WARNING! DO NOT use ‘powerful’ abrasive or solvent cleaning fluids when cleaning the shower as they may damage the plastic fittings. Before cleaning, turn off the unit at the Sprayplate isolation switch to avoid the shower being accidentally switched on.
-
Page 6: Spare Parts
Riser rail assembly SPARE PARTS Ref. Description Part No. − Kit complete (excluding hose, showerhead, riser rail) white 86000850 chrome 86000840 1 5 mode rub clean showerhead white electric 22010980 chrome electric 22011130 gold electric 22011140 white gravity 22011070 chrome gravity 22011110 gold gravity 22011120... - Page 7 Riser rail assembly...
- Page 8 This product must not be taken apart, modified or repaired except by a person authorised by Triton. This guarantee applies only to products installed within the United Kingdom and does not apply to products used commercially.
