- Page 1 UNBMXFIXBT Andrew riser rail assembly Installation Instructions nstallers please note these InstructIons are to be left wIth the user 2180535B December 2007 p41502 a ndrew...
- Page 2 ANdrew rISer rAIL ASSeMBLY wArNINg! Fig.1 Lower bracket Check there are no hidden cables or pipes before drilling holes for wall plugs. Use great care when using power tools near water. The use of a residual current device (rCd) is recommended.
- Page 3 ANdrew rISer rAIL ASSeMBLY Slide the soap dish and hose retainer onto the Fig.5 riser rail, below the showerhead holder (fig.5). Locate the riser rail assembly to the upper bracket. Align the upper hole in the riser rail with hole ‘A’ in the bracket and secure using one of the long screws supplied (fig.6).
- Page 4 SpAre pArTS ref. description spares no. − Kit (without riser rail) 88900007 Bracket & trim 83309680 Riser rail 88800007 Showerhead holder 83309490 Soap dish 83308370 Hose retaining ring 83308380 – Flexible hoses available in the following sizes: 1.00 m in white, chrome and gold 1.25 m in white, chrome and gold 1.75 m in chrome only please refer to shower installation and operating instructions for service details...
