Parts & Assembly - Igloo IWCTL352CHWH Instructions And Recipes Manual

• Adjustable front leveling legs
• Hot and cold dispensers with a hot-button safety lock
• Over heating protection for hot tank
• Removable drip tray for easy clean up
• Dispensing area suitable for up to 8.5" bottle
• Hot water tank capacity: 1L/ Cold water tank capacity: 3.2L
• Water temperature: Hot 203°F/ Cold 40°F
• Hot and Cold On/Off switches
PARTS & ASSEMBLY
PARTS
5
12
11
1
2
3
4
1- Hot Water Indicator Light
5
2- Cold Water Indicator Light
3- Cold Water Spigot
4- Hot Water Spigot
5- Removable Drip Tray
6- Adjustable Feet
7- Hot Water Push Button Dispenser/Safety Lock
8- Cold Water Push Button Dispenser
9- Cold Water On/Off Switch
10- Hot Water On/Off Switch
11- Water Guard Base
12- Water Guard
6
7 8
9 10
