- Page 1 MANUAL AND OPERATION INSTRUCTIONS FOR GAS SPACE HEATERS LEO SERIES Installation and operating instructions Manufacturer: www.kratki.com Kratki.pl Marek Bal ul. W. Gombrowicza 4 26-660 Wsola/Jedlińsk...
- Page 2 This manual, together with all photographs, illustrations and trademarks, are protected by copyright. All rights reserved. Neither the manual nor any material contained herein may be reproduced without the written permission of the author. The information contained in this document is subject to change without notice. The manufacturer reserves the right to amend and make changes to this manual without obligation to inform anyone.
-
Page 3: Table Of Contents
INSTRUKCJA MONTAŻU I OBSŁUGI – SERIA LEO wersja 1.0 Table of contents Introduction Description of the device Dimensions (mm) Category, model and version of LEO gas fireplace. Elements of the set Safety Installation of the appliance INSTALLATION REQUIREMENTS. Rules Placing of the appliance Ventilation grates in the housing Connecting the device using a concentric chimney system Runing a concentric flue and air duct through the side wall of the building - type... -
Page 4: Introduction
/ service technician who has the right permissions for the region. Introduction The LEO series are series of a gas fired space heaters and each of them is a closed heating device fueled with combustible gas. This device has CE mark and uses high- class automation for gas control. - Page 5 INSTRUKCJA MONTAŻU I OBSŁUGI – SERIA LEO wersja 1.0 LEO/45/68 LEO/L/45/68 LEO/LP/45/68 LEO/P/45/68 LEO/70 LEO/L/70 LEO/LP/70 LEO/P/70 LEO/76/62 LEO/L/76/62 LEO/LP/76/62 LEO/P/76/62 LEO/100 LEO/L/100 LEO/LP/100 LEO/P/100 LEO/TUNEL/100 LEO/TUNEL/LP/100...
- Page 6 LEO/LP/200 LEO/200 LEO/L/200 LEO/P/200 Fig. 1. LEO series gas fireplaces...
-
Page 7: Dimensions (Mm)
INSTRUKCJA MONTAŻU I OBSŁUGI – SERIA LEO wersja 1.0 Dimensions (mm) Model LEO/45/68 1207 LEO/L/45/68 1207 LEO/LP/45/68 1207 LEO/P/45/68 1207 LEO/70 LEO/L/70 LEO/LP/70 LEO/P/70 LEO/76/62 1147 LEO/L/76/62 1147 LEO/LP/76/62 1147 LEO/P/76/62 1147 LEO/100 1065 1019 222,5 878,5 LEO/L/100 1140 1065,5 222,5 878,5 LEO/LP/100... - Page 8 LEO/L LEO/LP LEO/P Fig. 2. Dimensions of LEO series gas fireplaces...
-
Page 9: Category, Model And Version Of Leo Gas Fireplace
INSTRUKCJA MONTAŻU I OBSŁUGI – SERIA LEO wersja 1.0 Category, model and version of LEO gas fireplace. Pressure and gas Model and version Category Destination Countries type BE, CY, DK, EE, FR, GB, 30 mbar, G30 GR, HU, HR, IT, LT, NL, NO, RO, SE, SI, SK, TR FRONT 3B/P... -
Page 10: Elements Of The Set
Elements of the set Please make sure that the kit of elements have not been damaged during transport. The inspection should be carried out in the presence of the installer. Before installing the fireplace insert, please familiarize yourself with all the elements provided with the device. -
Page 11: Installation Of The Appliance
INSTRUKCJA MONTAŻU I OBSŁUGI – SERIA LEO wersja 1.0 ✓ Do not place flammable materials near the fireplace. ✓ It is forbidden to place flammable materials in the combustion chamber. ✓ If you feel a gas leak, do not start the device. Stop the gas supply as soon as possible, ventilate the room in which the fireplace is located and contact a service technician. -
Page 12: Installation Requirements
INSTALLATION REQUIREMENTS. Fig. 3. Minimum distances of the gas cartridge from non-combustible housing elements The distances indicated above are the minimum distances from a non-flammable housing, unless another provision states otherwise. The main reason for fires associated with the fireplace is the lack of maintenance of the required distances (free air space) from the walls of the housing. - Page 13 Ventilation grates - are required for all LEO series models and must be considered when designing the housing. This allows the heat exchange accumulated inside the fireplace housing to be released into the room, which also helps to keep the fireplace walls and the housing cool.
-
Page 14: Rules
Adjustable feet - All fireplaces in the LEO series are standard equipped with leveling legs, which can change the height of the device. If necessary, you can also build a platform to raise the firebox higher. Despite this solution, remember that the legs cannot be removed. -
Page 15: Ventilation Grates In The Housing
INSTRUKCJA MONTAŻU I OBSŁUGI – SERIA LEO wersja 1.0 or curtains. Due to the possibility of ignition, it is forbidden to dry clothes, towels, etc. near the gas insert. The fireplace should be installed on a stable non-flammable surface. The gas insert is equipped with special feet with adjustable height and two adjustable mounting brackets enabling the device to be attached to the wall. - Page 16 Fig. 6. Diagram showing minimum requirements for the location of ventilation grilles and inspection doors.
-
Page 17: Connecting The Device Using A Concentric Chimney System
INSTRUKCJA MONTAŻU I OBSŁUGI – SERIA LEO wersja 1.0 Connecting the device using a concentric chimney system Coaxial ducts can be led through the wall or roof of the building. The building regulations in force in the given region must be observed. Remember to check the flue gas pipe with the terminal for blockage. - Page 18 In the event of condensation in the chimney flue, the installer should use a drainage element (droplet separator). Each elbow used for the exhaust air exhaust system is counted as a meter length and this should be taken into account when calculating the total length of the exhaust air duct.
- Page 19 INSTRUKCJA MONTAŻU I OBSŁUGI – SERIA LEO wersja 1.0 Unless otherwise provided by local regulations, the horizontal or vertical terminal should be installed according to the following guidelines. Fig. 7. Possible variants of the concentric air exhaust system output for the LEO series devices In the case of a chimney system outlet near a roof window (A - B), the air intake must be installed a minimum of 0.6 m above the top of the window.
- Page 20 A - B Roof window H Roof window C Height above ground level D - E Distance below the balcony and from the roof edge F Distance from obscuring breaks G Distance from doors and windows...
- Page 21 INSTRUKCJA MONTAŻU I OBSŁUGI – SERIA LEO wersja 1.0 It is allowed to lead the horizontal terminal below 2.5 m above ground level, but not less than 0.5 m if there is no playground or other recreational places within 8 m. The distance between the cable outlets should not be less than 3 m, and the distance of these outlets from the nearest edge of the opening windows / doors (G) and screening projections (F) not less than 0.5 m (C and G).
-
Page 22: Runing A Concentric Flue And Air Duct Through The Side Wall Of The Building - Type C11
Running a concentric flue and air duct through the side wall of the building - type C11: The discharge of the flue and air duct through the building wall should begin with the use of a 1 meter long vertical section. The maximum length of the straight section of the air-fuel pipe run horizontally is 3 meters. -
Page 23: Runing A Concentric Flue And Air Duct Through The Side Wall Of The Building - Type C31
INSTRUKCJA MONTAŻU I OBSŁUGI – SERIA LEO wersja 1.0 Running a concentric flue and air duct through the side wall of the building - type C31: Moving through the roof can be carried directly vertically. The minimum length of the vertical section without a knee is 1 meter, while the maximum length may not exceed 10.0 meters (Figure 9). - Page 24 ✓ A rosette must be used at the transition of the concentric system through the wall. ✓ The chimney output of the existing chimney in connection with the terminal should be protected against flooding or blocking, and the terminal installed in a way that guarantees its correct operation.
-
Page 25: Runing A Concentric Flue And Air Duct Through The Side Wall Of The Building - Type C61
Maximum lengths of the concentric flue gas system Fig. 11. LEO Series - Scheme of all allowed concentric flue system runs. -
Page 26: Exhaust Gas Restrictors
(exhaust outlet on the device). Exhaust gas restrictors In LEO series gas fireplaces it is necessary to adapt the exhaust gas restrictors (covers / deflectors) depending on the way the air-flue system is routed. LEO45/68, LEO76/62 If a vertical terminal is used, the LEO45 / 68 and LEO76 / 62 devices do not require modification. - Page 27 INSTRUKCJA MONTAŻU I OBSŁUGI – SERIA LEO wersja 1.0 Fig. 13. Disassembly of LEO100 and LEO200 deflectors LEO70 In the LEO70 series, depending on how the chimney system is routed, the deflector assembly must be adapted by using appropriate covers (Fig. 14). In each diaphragm there are special cuts enabling breaking of its individual elements.
- Page 28 Table 1. LEO70 - Type of shutters used in deflectors depending on how the air-flue system is routed Variant 10 m Type Type Type Type Type Type Type Type Type Type Type Type Type Type Type Type Type Type Type Type Type Type...
-
Page 29: Installation Of The Control System
INSTRUKCJA MONTAŻU I OBSŁUGI – SERIA LEO wersja 1.0 Installation of the control system ATTENTION!!! The device together with the gas control system can only be installed in the factory settings. Do not install the battery at this stage. Connecting a power source beforehand can damage the system electronics. -
Page 30: Receiver Antenna
Fig. 17. Connection diagram for individual gas control system components Receiver Antenna The antenna is part of the kit directly connected to the B6R-R8U gas remote control receiver. It allows wireless control of the fireplace using a remote control. When connecting the receiver to the gas control system, pay special attention not to mount the antenna too close to the ignition cable. - Page 31 Next, remove the bottom cover and unscrew the remaining strips pressing the glass. After completing the above steps, you can easily remove the glass. Depending on the model of the LEO series the method of dismantling the glass may be slightly different from the one shown.
- Page 32 Failure to follow the instructions can result in fire or explosions, causing serious damage, damage to health, and even death.. Technical specification of the gas control system used in the LEO series: FULFILLED DIRECTIVES 2009/142/EC and DIN EN 298, DIN EN 126, DIN EN...
- Page 33 INSTRUKCJA MONTAŻU I OBSŁUGI – SERIA LEO wersja 1.0 The gas control system used in the LEO series meets the requirements for appliances burning gaseous fuel contained in GAR Regulation 2016/426 and standards EN 298, EN 126, EN 13611. The system can be powered by gas fuels of the second and third families according to the EN 437 standard and the EN product standard 613.
-
Page 34: Control Flame Height
Control flame height By default, the control flame height is set to the maximum and does not require manual adjustment. The thermocouple head should be within reach of the control flame. Gas outlet pressure regulation 1. Connect a pressure gauge to the outlet pressure measuring point (diameter 9 mm). -
Page 35: Checking For Leaks
INSTRUKCJA MONTAŻU I OBSŁUGI – SERIA LEO wersja 1.0 Attention!!! The pressure regulator is blocked by tightening its adjusting screw to its maximum Adjusting the minimum height of the main burner flame 1. Turn the main valve knob to the "OFF" position. Then turn them clockwise until the valve opens. -
Page 36: Installation Of The Device
Attention!!! The manufacturer recommends using decorative elements optionally supplied with the device. The Kratki.pl Marek Bal company is not liable for damages resulting from the use of decorations other than those recommended. Depending on the user's preferences, the combustion chamber can be lined with one of several available sets of decorative elements. - Page 37 INSTRUKCJA MONTAŻU I OBSŁUGI – SERIA LEO wersja 1.0 Arrangement of decorative elements for the LEO 45/68 and LEO 76/62 series Fig. 23. The correct arrangement of decorative elements for the LEO 45/68 series Fig. 24. The correct arrangement of decorative elements for the LEO 76/62 series...
- Page 38 Arrangement of decorative elements for the LEO 100 and LEO 200 series Fig. 25. Correct arrangement of decorative elements Fig. 26. Correct arrangement of decorative elements - stones with logs...
-
Page 39: First Start
INSTRUKCJA MONTAŻU I OBSŁUGI – SERIA LEO wersja 1.0 First Start Before starting the fireplace for the first time, make sure that all connections of individual system components have been made in accordance with this manual. Incorrect connection of individual elements of the gas control system may damage them. -
Page 40: Control
Control ATTENTION!!! NOTE!!! The remote control should always be kept out of the reach of children and other person unaware, not capable of assessing the consequences of their actions. The user gets the device along with the included remote control, type B6R-H9 (Fig. 36). - Page 41 INSTRUKCJA MONTAŻU I OBSŁUGI – SERIA LEO wersja 1.0 Figure 37. „RESET“ button - receiver INFORMATION To view the current version of the software used by the remote control, simultaneously press the . Simultaneous pressing the button and the button will display the remote control model.
- Page 42 USER MANUAL OF THE 6-SYMBOL B6R-H9 CONTROL UNIT SETTING OF THE TEMPERATURE UNIT. To change the temperature unit, simultaneously press the buttons. You can choose between Celsius and Fahrenheit degrees. Choosing °F will automatically set the clock in a 12-hour format, while the choice of °C sets the clock in a 24-hour format.
- Page 43 INSTRUKCJA MONTAŻU I OBSŁUGI – SERIA LEO wersja 1.0 1. To be able to adjust the day of the week, press the button and the button. 2. Press to select a number corresponding to the day of the week (1 - Monday, 2 - Tuesday 3 - Wednesday 4 - Thursday, 5 - Friday, 6 - Saturday, 7 Sunday) 3.
- Page 44 Standby or off mode To make the unit switch to the standby mode, hold the button until the main burner is extinguished. To turn the device off, press . The control flame will be extinguished. Before attempting to re-start the fireplace, wait 5 seconds. Adjusting the height of the flame To make the unit switch to the standby mode, hold the button until...
- Page 45 INSTRUKCJA MONTAŻU I OBSŁUGI – SERIA LEO wersja 1.0 SLEEP TIMER Enabling/Settings 1. Press and hold  until you see the  icon. The hours’ box will flash. 2. Enter a value using the  and  buttons. 3. To confirm, press  . The minutes’ box will flash. 4.
- Page 46 Eco mode The flame height is adjustable between its extremes. If the room temperaturę is lower than the temperature preset on the thermostat, the flame height reaches its maximum value and remains at a high level for a longer period of time. If the room temperature is lower than the preset, the flame height is reduced to a minimum for a long period of time.
- Page 47 INSTRUKCJA MONTAŻU I OBSŁUGI – SERIA LEO wersja 1.0 Disabling the programmed mode 1. Press the button or the button, or the button to go to the manual mode. 2. Press the button, to go to the Thermostat mode. Information: Entering the switch-on temperature of the thermostat will automatically set the same value for the switch-on temperature of the programmed mode.
- Page 48 Switching on time settings (Program 1) „ALL” option selected 7. The display shows , 1, „ON”, then for a while you will see the „ALL” symbol. Subsequently, the hour will begin to flash. 8. Set the hour using the buttons. 9.
-
Page 49: Technical Parameters Of The Gas
INSTRUKCJA MONTAŻU I OBSŁUGI – SERIA LEO wersja 1.0 Replacement of batteries Batteries in the receiver, remote control or the power supply module can overheat, spill or even cause an explosion. Do not use batteries that have been exposed to the sun, moisture, heat or vibration. - Page 50 LEO 45/68 Reference G25.3 Device 3B/P category 30 37 30 37 35 45 57,5 35 45 57,5 mbar 20 25 42,5 25 25 42,5 Fully open Fully open 18,3 21,0 10,7 12,2 0,615 0,631 0,126 0,150 0,396 0,414 0,096 0,118 Ø...
- Page 51 INSTRUKCJA MONTAŻU I OBSŁUGI – SERIA LEO wersja 1.0 LEO 76/62 Reference G25.3 Device 3B/P category 30 37 30 37 35 45 57,5 35 45 57,5 mbar 20 25 42,5 25 25 42,5 Fully open Fully open 18,3 21,0 10,7 12,2 0,909 0,927...
- Page 52 LEO 200 Reference G25.3 Device 3B/P category 30 37 30 37 35 45 57,5 35 45 57,5 mbar 20 25 42,5 25 25 42,5 18,1 22,4 27,3 29,0 19,9 21,0 16,0 15,0 14,0 12,5 12,0 10,5 1,646 1,680 0,408 0,477 0,890 0,926 0,348...
-
Page 53: Service And Maintenance Of The Device
INSTRUKCJA MONTAŻU I OBSŁUGI – SERIA LEO wersja 1.0 Service and maintenance of the device All maintenance work should be carried out on a cooled fireplace with the gas supply cut off and the power supply disconnected. The gas insert can be serviced and the technical condition of the air-flue system can only be checked by a qualified technician with a valid qualification certificate. - Page 54 Check that all panes provided with the device are not damaged. Windows with cracks and deep scratches should be replaced immediately. Remove the front window. Remove the sealing cord from the glass and clean its inside surface. Carefully remove the decorative elements from the combustion chamber. If necessary, use a vacuum cleaner to remove debris from decorative elements.
-
Page 55: Battery Replacement
INSTRUKCJA MONTAŻU I OBSŁUGI – SERIA LEO wersja 1.0 FINAL STEPS Make sure the fireplace is cool. Place the inspection element in the base of the burner. Place the elements decorative in the combustion chamber. Check that the decorative elements are not in contact with the glass. Check that the control burner is not obstructed by decorative elements. -
Page 56: Possible Problems And Solutions
Possible problems and solutions There are many factors that can affect the gas cartridge to malfunction. To exclude a possible malfunction of the device or the automatic gas control system, make sure that the fireplace has been connected in accordance with these instructions. The table below shows how to deal with individual symptoms. - Page 57 INSTRUKCJA MONTAŻU I OBSŁUGI – SERIA LEO wersja 1.0 After lighting up the Check the correct connection between the chopper and the control flame, a spark controller. appears on the electrode If the electronic amplifier is damaged, replace the receiver. Check that the thermocouple sensor is functional and correctly The control flame goes connected to the gas control module.
-
Page 58: Failure Codes
Failure codes The remote controls used in Kratki.pl gas appliances are equipped with a display that facilitates automation control. In case of problems with the fireplace, a message in the form of an error code is displayed on the remote control. -
Page 59: Environmental Protection
INSTRUKCJA MONTAŻU I OBSŁUGI – SERIA LEO wersja 1.0 Environmental Protection All packaging elements in which the gas insert has been delivered should be disposed of in an appropriate manner. Due to the content of heavy metals, batteries are classified as hazardous chemical waste, so after use, they should be thrown into special containers for hazardous waste. -
Page 60: Terms Of Warranty
Complaints can be submitted via the form on the website in the "knowledge and help" tab or by e-mail to the address reklamcje@kratki.com Submission of the aforementioned documentation is necessary to consider all claims. The complaint will be considered within 14 days from the date of its submission. All modifications, modifications and structural changes of the insert cause immediate loss of the manufacturer's warranty. - Page 61 Warranty duplicates are not issued !!! In order to continually improve the quality of its products, Kratki.pl Marek Bal reserves the right to modify devices without prior notice.
- Page 62 THE INSTALLATION OF THE LEO SERIES HEATER PROTOCOL Type of the appliance: Details and signature of the seller: ________________________________ Model: ________________________________ Appliance serial number: Date of sale: _________________________ ________________________________ Date of installation: Installer details and type, number and expiry date of the relevant licenses:...
- Page 63 INSTRUKCJA MONTAŻU I OBSŁUGI – SERIA LEO wersja 1.0 THE INSPECTION OF THE LEO SERIES HEATER PROTOCOL Number and date of the inspection: Serviceman details, type, number and expiry date of the applicable licenses: ________________________________ Comments: Legible signature ________________________________...
- Page 64 Kratki.pl Marek Bal ul. Gombrowicza 4, Wsola, 26-660 Jedlińsk, Poland tel. 00 48 48 389 99 00, 00 48 48 384 44 88, fax 00 48 48 384 44 88 wew. www.kratki.com www.facebook.com/kratkipl www.youtube.com/kratkipl www.instagram.com/kratkipl...
