HDMI 2.0 Wall-Plate with USB & RS-232 over
Part Number
EX-4KU-WP
UHB-R
CUSTOMER
SUPPORT
INFORMATION
EX-4KU
HDBaseT™ Kit
Function
Single Gang Decora Wall-Plate Transmitter
Receiver with HDMI, USB, and RS-232
Order toll-free in the U.S. 800-959-6439
FREE technical support: 714-641-6607 or support@hallresearch.com
Hall Research, 1163 Warner Ave. Tustin, CA 92780
www.hallresearch.com
User's Manual
UMA1288 REV N/C
Advertisement
Table of Contents
Related Manuals for Hall Research Technologies EX-4KU
Summary of Contents for Hall Research Technologies EX-4KU
- Page 1 User’s Manual EX-4KU HDMI 2.0 Wall-Plate with USB & RS-232 over HDBaseT™ Kit Part Number Function EX-4KU-WP Single Gang Decora Wall-Plate Transmitter UHB-R Receiver with HDMI, USB, and RS-232 UMA1288 REV N/C CUSTOMER Order toll-free in the U.S. 800-959-6439 FREE technical support: 714-641-6607 or support@hallresearch.com SUPPORT Hall Research, 1163 Warner Ave.
-
Page 2: Table Of Contents
2.0 Package Contents ................ 4 3.0 Setup ....................5 Installation ..................... 5 4.0 Connector and Indicator Functions ......... 6 Model EX-4KU-WP FRONT ..............6 Model EX-4KU-WP REAR ..............7 Model UHB-R FRONT ................. 8 Model UHB-R REAR ................8 5.0 Troubleshooting ................9 Contacting Hall Research .............. -
Page 3: Introduction
HDMI 2.0 Wall Plate with USB 1.0 Introduction The EX-4KU is a kit comprised of a Single Gang Decora style wall plate transmitter (EX-4KU-WP) and a receiver (UHB-R). The transmitter accepts an HDMI input with resolutions up to 4K UHD. It also features a USB 2.0 HOST port, two USB Charging ports, and bi-directional RS-232. -
Page 4: Features
HDCP 2.2 compliant Supports 7.1 channels HD audio format 3 Year warranty 2.0 Package Contents Model EX-4KU-WP (x1) Single Gang HDBaseT™ transmitter (EX-4KU-WP) (x1) Decora faceplate (white) (x1) Phoenix connector (3-pin) Model UHB-R (x1) HDBaseT™ receiver (UHB-R) (x2) Mounting Brackets... -
Page 5: Setup
HDMI 2.0 Wall Plate with USB 3.0 Setup Installation Connect the video source(s) to the EX-4KU-WP transmitter. Connect the USB Host (PC) to the transmitter using a USB A/B cable. Connect the display to the UHB-R receiver. -
Page 6: Connector And Indicator Functions
EX-4KU 4.0 Connector and Indicator Functions Model EX-4KU-WP FRONT HDMI IN: Connect to HDMI source, such as a PC or media player. USB HOST: Connect to a USB Host, such as a PC. USB CHARGE: +5v power for charging USB devices LEDS: POWER: Lights Green when power is applied. -
Page 7: Model Ex-4Ku-Wp Rear
HDMI 2.0 Wall Plate with USB Model EX-4KU-WP REAR HDBaseT OUT: Connect to UHB-R receiver using CAT6 cable. RS-232: Use supplied terminal block to extend RS-232 between transmitter and receiver. © Copyright 2020 Hall Research, LLC. -
Page 8: Model Uhb-R Front
The transmitter receives power via PoC from the receiver. HDBaseT IN: Connect to EX-4KU-WP using CAT6 cable. IR IN / IR OUT: Not supported with EX-4KU-WP transmitter. HDMI OUT: Connect to HDMI display, such as a TV or projector. -
Page 9: Troubleshooting
Contacting Hall Research If you determine that your EX-4KU is malfunctioning, do not attempt to repair the unit. Instead, contact Hall Research Technical Support at 714-641-6607. To return the unit to Hall Research you must first get a Return Authorization (RMA) number. -
Page 10: Specifications
Dimensions EX-4KU-WP - 2.60" H x 1.30" W x 1.80" D (66 mm H x 33 mm W x 45.8 mm D) EX-HDU-R - 0.97" H x 6.77" W x 3.84" D (20 mm H x 172 mm W x 97.5 mm D) Product weight Model Only EX-4KU-WP - 0.7 lb... - Page 11 HDMI 2.0 Wall Plate with USB © Copyright 2020 Hall Research, LLC.
- Page 12 © Copyright 2020. Hall Research, LLC. All rights reserved. 1163 Warner Ave., Tustin, CA 92780 Ph: (714)641-6607...
