Setup
WEAPON REDMOTE Link
The WEAPON REDMOTE Link allows the camera to communicate directly with the
REDMOTE via a wired connection.
Attach the WEAPON REDMOTE Link to the back of the REDMOTE.
Connect the supplied Link Cable to the CTRL connector and the V-Loc plate's D-
Tap output.
Before attaching the housing Rear Shell, Connect the Link Cable to the
WEAPON REDMOTE Link module.
The WEAPON
REDMOTE Link will
snap onto the back of
the REDMOTE.
Page 7
