MM-1000
Ethernet Optical/
Media Converters
Electrical Converter
Features
• Industry's smallest miniature design
• 1 x 10/100/1000 (Gigabit Ethernet) RJ45 Network port
• 1 x 1000BASE-LX SC duplex multi-mode port
• Extends 10/100/1000 Ethernet up to 2km / 1.25mi over multi-mode fiber
• Compliant with IEEE802.3 standards
• Autosensing MDI/MDIX crossover on network port
• LED indicators for network signals, link status and power
• Made in the U.S.A.
Nitek International LLC
Nitek Europe BV
5410 Newport Drive
De Aar 99
Rolling Meadows, IL
8253 PN Dronten
60008 U.S.A.
The Netherlands
IEC/UL 62368-1
800 528 4343
00 31(0) 321 310 043
www.nitek.net
www.nitek.net
Advertisement
Related Manuals for Nitek MM-1000
Summary of Contents for Nitek MM-1000
- Page 1 • Compliant with IEEE802.3 standards • Autosensing MDI/MDIX crossover on network port • LED indicators for network signals, link status and power • Made in the U.S.A. Nitek International LLC Nitek Europe BV 5410 Newport Drive De Aar 99 Rolling Meadows, IL 8253 PN Dronten 60008 U.S.A.
- Page 2 MM-1000 Technical Specifications Network Port: RJ45 Connector Optical Port: Duplex SC 1310nm for use with multi-mode fiber Ethernet: 10/100/1000Mb on copper port, full or half duplex Ethernet on Optical Link: 1000Mb full duplex Max operating distance electrical: up to 100m / 330ft on Network Port (10/100/1000 copper) Max operating distance optical: up to 2km / 1.25mi using SC duplex multi-mode 62.5um fiber...
