PULSE V3
Technical Reference Manual
LoRaWAN / Sigfox
Applicable for APP versions >= 2.0.0
adeunis
®
Manage & optimize your assets & services
283, rue louis Néel 38920 CROLLES, France
Tél : +33 (0)4 76 92 07 77 E-mail : sales@adeunis.com
www.adeunis.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PULSE V3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Adeunis RF PULSE V3

  • Page 1 Page 1 / 21 PULSE V3 Technical Reference Manual LoRaWAN / Sigfox Applicable for APP versions >= 2.0.0 adeunis ® Manage & optimize your assets & services 283, rue louis Néel 38920 CROLLES, France Tél : +33 (0)4 76 92 07 77 E-mail : sales@adeunis.com...
  • Page 2: New Documentation / Nouvelle Documentation

    Page 2 / 21 EW DOCUMENTATION OUVELLE DOCUMENTATION ENGLISH FRANCAIS Dedicated to a product Dédié à un produit • • • Cautions & electrical warnings • Recommandations et avertissements électriques • Declaration of conformity • Déclaration de conformité • Product functionalities and modes •...
  • Page 3: Table Of Contents

    Page 3 / 21 ABLE OF ONTENTS NEW DOCUMENTATION / NOUVELLE DOCUMENTATION ......................2 TABLE OF CONTENTS .................................. 3 REGISTERS ..................................4 .................................. 4 ENERIC REGISTERS ................................4 PPLICATIVE REGISTERS ..................................7 ADIO REGISTERS 1.3.1 LoRaWAN Network Registers ............................7 1.3.2 Sigfox Network Registers ............................
  • Page 4: Registers

    Page 4 / 21 1. R EGISTERS 1.1 Generic registers Size Default Range Register Base Description Comments (bytes) Value (Min-Max) PIN code used with ATPIN command. PIN code 0 - 9999 (deactivated) Value 0 disables the PIN code. In PARK mode, product is not using Product 0: PARK Radio.
  • Page 5 Page 5 / 21 Size Default Min-Max Register Base Description Comments (bytes) value Value 43200 History period 1 … 65535 x 2 seconds (24h) Bits 0 to 3: debounce period - channel A • Value 0: deactivated • Value 1: 1 ms •...
  • Page 6 Page 6 / 21 Size Default Min-Max Register Base Description Comments (bytes) value Value Leak threshold Unit: pulses per hour 0 ... 65535 (channel A) 0: deactivated Leak threshold Unit: pulses per hour 0 ... 65535 (channel B) 0: deactivated 0: deactivated Number of daily periods...
  • Page 7: Radio Registers

    Page 7 / 21 1.3 Radio registers 1.3.1 LoRaWAN Network Registers Register Description Encoding Details Spreading Factor (SF) by Decimal Default: 12 (EU) / 10(US915/AS923) default READ ONLY Reserved Hexadecimal Do not use LORA APP-EUI (first part Hexadecimal Default: 0 –...
  • Page 8 Page 8 / 21 Register Description Encoding Details LORA APP_SKEY (third Hexadecimal part - MID LSB) LORA APP_SKEY Hexadecimal (fourth part – LSB) Reserved Decimal Do not use Band number Decimal Default: 0 (US915 only) 0: the device uses all the channels [0-63] in 125 kHz and [64- 71] in 500 kHz 1: the device will use just the Band n°1.
  • Page 9: Sigfox Network Registers

    Page 9 / 21 1.3.2 Sigfox Network Registers Size Range Register Base Description Default Value Comments (bytes) (Min-Max) Sigfox 1440 X 1 minute 0-65535 Downlink period (24h)  Period: 1 min to 45 days Sigfox 0: duty cycle activated Duty Cycle 1: duty cycle deactivated adeunis ®...
  • Page 10: Radio Protocol

    Page 10 / 21 2. R ADIO PROTOCOL Data with size greater than 1 byte will be transmitted MSB first. In LoRaWAN, frames are sent on port 1. 1.4 Status byte All frames sent by the product contain a status byte. Its format is identical for all IoT Adeunis products. Alarm Status Bit 7 Bit 6...
  • Page 11 Page 11 / 21 Decoding example: Offset Data Description (in byte) 0x10 Frame code Frame counter: 0 0x00 Bit1@0: configuration consistent 0x01 mode PRODUCTION activated S301=0x0002 = 2 (decimal): 1 sending every 2 3 – 4 0x0002 historizations/savings. : input configuration (Channels A and B): •...
  • Page 12 Page 12 / 21 Decoding example: Offset Data Description (in byte) 0x10 Frame code Frame counter: 0 0x00 Bit1@0: configuration consistent 0x01 mode PRODUCTION activated S301=0x0002 = 2 (decimal): 1 sending every 2 3 – 4 0x0002 historizations/savings. Input configuration (Channels A and B): •...
  • Page 13: Network Configuration (0X20)

    Page 13 / 21 In order to optimize the sending of start frames, the 0x12 frame is only sent if the leak or fraud alarm is active or if there is redundancy. If at least one of the following conditions is checked, the frame is sent: S330! = 0 •...
  • Page 14: Keep Alive Frame (0X30)

    Page 14 / 21 Bits 5 to 7: Reserved S221 Provisioning mode (0: ABP, 1: OTAA) Decoding example: Offset Data Description (in byte) 0x20 Frame code Frame counter: 1 0x20 Bit1@0: no Low Bat Duty cycle activated 0x05 ADR ON 0x01 OTAA 1.5.2.2...
  • Page 15: Periodic Data Without Historisation (0X46)

    Page 15 / 21 Decoding example: Offset Data Description (in byte) 0x30 Frame code Frame counter: 1 0x22 Bit1@1: Low Bat detected (00011001) binary which gives: • Bit 0 = 1 – Exceeding flow on channel A • Bit 1 = 0 – No exceeding flow on channel B •...
  • Page 16: Periodic Frame With Historisation (0X5A / 0X5B)

    Page 16 / 21 Decoding example: Offset Data Description byte) 0x47 Frame code Frame counter: 5 0xA0 Bit1@0: Low Bat not detected 2 - 3 0x2904 = 10,500 pulses per hour 4 - 5 0x206C = 8,300 pulses per hour 1.5.6 Periodic frame with historization (0x5A / 0x5B) These frames (0x5A et 0x5B) are sent, if the corresponding channels are activated (S320), at the period defined by registers S321 x S301.
  • Page 17: Response To Get Register Request (0X31)

    Page 17 / 21 1.5.7 Response to Get register request (0x31) Following reception of a downlink frame with the code 0x40, the frame 0x31 is transmitted. It contains all the values of the registers requested in the downlink frame 0x40. Offset Data Description...
  • Page 18: Transmit Conditions

    Page 18 / 21 Decoding example: Offset Data Description (in byte) 0x33 Frame code Frame counter: 4 0x80 Bit1@0: Low Bat not detected 0x04 invalid register 0x013F 319: register S319 does not exist (should be S3XX) 1.5.9 Transmit conditions Frame Description Network Sending conditions...
  • Page 19: Downlink Frame Format

    Page 19 / 21 1.6 Downlink Frame format 1.6.1 Get applicative configuration (0x01) Offset Data Description (in byte) 0x01 Frame code When the device receives the downlink, it will generate a product configuration frame (0x10). 1.6.2 Get network configuration (0x02) Offset Data Description...
  • Page 20: Get Registers (0X40)

    Page 20 / 21 Offset Data Description (in byte) 0x04 Frame code Offset - Offset - channel B: numbers of pulses to add to current 1 - 4 channel B index of the meter (channel B) (unsigned 32-bits, MSB first) Coding example: Offset Data...
  • Page 21: Set Registers (0X41)

    Page 21 / 21 1.6.5 Set registers (0x41) This frame (0x41) allows you to change the value of requested S3XX registers. Offset Data Description (in byte) 0x41 Frame code Index of the register to be changed. CONFID1 The corresponding register is “300 + CONFID1“ Value of Value to set CONF ID 1...
