Jantar REX F-0-9 Manual page 2

AS A STANDALONE CONTROLLER
The entire set-up procedure is carried out with the master
fingerprint. You can register two master fingerprints.
The master fingerprints cannot be replaced or duplicated.
You cannot change any setting without them and neither
can we.
Programming with the master fingerprint
First connection to the power supply and registration of the
master fingerprints
Register master fingerprints:
Turn on the power supply (2 beeps indicate power on) and place
your fingerprint on the sensor, which you have chosen to be the
master fingerprint. After the triple beep remove the fingerprint.
LEDs will begin to flash rapidly, indicating recording fingerprint. At
the end of the recording, when the controller starts beeping
rapidly, once again place the fingerprint on the sensor. If the
fingerprint is identical to the first one, controller confirms the
successful registration with a double beep and with the flashing
green LED diode. If the registration has failed the controller signals
with a longer beep. If the registration is successful repeat the
process for the second master fingerprint.
If you want to register only one master fingerprint, then
register the same fingerprint twice.
Usage of master fingerprint
With the master fingerprint you choose the programming function.
Functions can be confirmed either with user fingerprint.
Master fingerprint:
Every time you place the master fingerprint on the sensor you hear
one beep (successfully read) and a double beep (programming
function). To select the different programming functions you need
to remove your master fingerprint after the double-beep and place
it again on the sensor within 2 seconds. The number of double
beeps indicates the programming function.
PROGRAMMING FUNCTIONS WITH MASTER FINGERPRINT
Function Description
1 Register or delete user fingerprints
2 Pulse time/ Duration of active output or toggle mode
3 Door status switch input/ Time till pre-alarm
4 Duration of pre-alarm
5 Negate / Switch output state
6 Delete fingerprint
7 Delete fingerprint
9 Switch to Wiegand 26-bit or access controller
13 Delete all
15 Sound (off/on), alarm output (off/on), door status
switch input NC or NO, set time in minutes or
seconds
16 Reset
Description of programming functions
Function 1) User fingerprints
Register or delete user fingerprints. With a registered fingerprint,
output (O0, wire 3) for an el. strike is triggered for the time set in
the function 2. In the controller, registered fingerprints are
arranged in order of their registration. Every registered fingerprint
is saved to its own position.
Register user fingerprint with master fingerprint:
Place the master fingerprint on the sensor and remove it (1 double
beep). Within a period of 10 seconds place a user fingerprint on the
sensor. Remove it after the beep. LEDs will begin to flash rapidly,
indicating recording fingerprint. At the end of the recording, when
the controller starts beeping rapidly, once again place the
fingerprint on the sensor. If the fingerprint is identical to the first
Black line
REX F-0-9– Standalone or Access Controller
one, controller confirms the successful registration with a lit green
LED and activated output. If the registration has failed the
controller signals with a longer beep. If the registration is
successful, the user fingerprint is registered and with it, the user
can open output on the controller. If you repeat the process with
the same fingerprint, this fingerprint will be deleted. Next
registered fingerprint will take the first available position on the list
or position of the deleted fingerprint. If you would like to delete the
fingerprint of the user that no longer exists, you must maintain a
list of registered fingerprints, arranged in order of registrations-
positions (functions 6 and 7).
Function 2) Pulse time/ Duration of active output or toggle
mode
Set the duration of active output/ the time in which you can open
the door or set output to toggle mode. The time can be set in
seconds or minutes. Switching time from seconds to minutes and
back, can be adjusted by using the function 15. Toggle mode
means, if a user fingerprint is registered, output will remain opened
(if it was closed) or closed (if it was open) till next registration.
Set the duration of active output with master fingerprint:
Place the master fingerprint two times on the sensor and remove it
(2 double beeps). The controller will start to beep every second.
Each beep indicates 1 second or 1 minute of active output.
Duration of active output can be max 120 seconds or 60 minutes.
When you hear the required number of beeps, place a user
fingerprint on the sensor for confirmation.
Set toggle mode with master fingerprint:
Place the master fingerprint two times on the sensor and remove it
(2 double beeps). Place a user fingerprint on the sensor before the
first beep.
Function 3) Door status switch input
Set the time till pre-alarm / time in which the door can stay open,
without triggering the pre-alarm and consequently the alarm. This
function is used when the door status switch on el. strike is
connected to Input0/I0/wire 5 on the controller. The input is
normally opened (NO) by default. It can be changed to normally
closed (NC) by using the function 15. The time can be set in
seconds or minutes. Switching time from seconds to minutes and
back, can be adjusted by using the function 15.
Set the time till pre-alarm with master fingerprint:
Place the master fingerprint three times on the sensor and remove
it (3 double beeps). The controller will start to beep every second.
Each beep indicates 1 second or 1 minute till pre-alarm. Duration
of the time till pre-alarm can be max 120 seconds or 60 minutes.
When you hear the required number of beeps, place a user
fingerprint on the sensor for confirmation.
Function 4) Pre-alarm and alarm
Set the pre-alarm time. This is the time in which the controller,
with short beeps, alerts you that the door was left open. If you
don't close the door in the pre-alarm time, the alarm will be
triggered and signaled with long beeps by the controller. The time
can be set in seconds or minutes. Switching time from seconds to
minutes and back, can be adjusted by using the function 15.
Set the pre-alarm time with master fingerprint:
Place the master fingerprint four times on the sensor and remove it
(4 double beeps). The controller will start to beep every second.
Each beep indicates 1 second or 1 minute of the pre-alarm time.
Duration of the pre-alarm time can be max 120 seconds or 60
minutes. When you hear the required number of beeps, place a
user fingerprint on the sensor for confirmation.
Function 5) Negate / Switch output state
This function is used, when you connect an electric strike or electric
magnet which needs power supply to remain in locked state.
Switch output state with master fingerprint:
Place the master fingerprint five times on the sensor and remove it
(5 double beeps). Within a period of three seconds place a user
fingerprint on the sensor. The output state will be switched from
the current one.
