IPPWR1
IP Camera Video & Power Surge Protector
The IPPWR1 must be properly installed to insure
maximum protection. The function of the IPPWR1 is to
allow a surge to be routed to ground and to clamp the
protected equipment inputs to a minimum voltage.
First provide a low impedance connection between the
IPPWR1 and your protected equipment. This is best done
by keeping the PROTECTED cable connection as short
as possible, ideally 3 feet or less.
Second, the system should use a single ground point.
Connect the Ground of the IPPWR1 to a single ground
point. The IP camera should be left ungrounded, but if it
is grounded it must be tied to the same ground as the
IPPWR1.
Finally, the UNPROTECTED cable should not be crossed
with the PROTECTED cable. Crossing cables could
provide a path for surge currents to bypass the IPPWR1
protection circuits.
