MacNeil WeatherTech No-Drill MudFlap Installation Instructions

Installation Instructions
Thank you for purchasing the WeatherTech
familiarize yourself with the steps to install the MudFlap on your vehicle. When properly installed, the WeatherTech
No-Drill MudFlap will provide you with years of protection.
Tools Needed
1
Start by thoroughly washing your vehicle. Take care
to remove all dirt, debris, and stains from each
fender in the areas corresponding to where the
MudFlaps will be installed.
Small Chip Guard
3
Locate the fasteners holding Chip Guard to fender lip.
Using the appropriate tool, remove these fasteners and
chip guard. These fasteners will be re-used.
67MF542
MudFlap
No-Drill MudFlap. Please read this installation guide to thoroughly
®
Hardware
Parts Kit (V)
Large Chip Guard
View Easy Installation Video
WeatherTech.com/install
Questions? Call customer service at 630 769 1500
Monday - Friday: 9 a.m. to 5 p.m. Central Time
WARNING
The MudFlap is designed to fit vehicles with standard
size wheels and tires. Installation of MudFlaps on
vehicles with aftermarket wheels or oversize tires
may interfere with the MudFlap, will void the war-
ranty and may damage the MudFlap or the vehicle.
2
Begin driver's side MudFlap installation by parking
the vehicle on level ground with wheels turned
fully to the left.
Bottom of Vehicle
4
Large Chip Guard Only: Remove the plastic rivet by
carefully unscrewing the Philips head screw. When the
screw is removed, the rest of the rivet can be removed.
(Small Chip Guard only skip to Step 5.)
®
