INSTALLATION MANUAL
Z-KEY-WIFI
Gateway Module /Serial Device Server with WIFI
EN
SENECA s.r.l.
Via Austria, 26 – 35127 – PADOVA – ITALY
Tel. +39.049.8705355 - 8705359 - Fax +39.049.8706287
For manuals in other languages and the configuration software, visit www.seneca.it/products/z-key-wifi
MI00544-0-EN
1/8
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Seneca Z-KEY-WIFI
Summary of Contents for Seneca Z-KEY-WIFI
- Page 1 INSTALLATION MANUAL Z-KEY-WIFI Gateway Module /Serial Device Server with WIFI SENECA s.r.l. Via Austria, 26 – 35127 – PADOVA – ITALY Tel. +39.049.8705355 - 8705359 - Fax +39.049.8706287 For manuals in other languages and the configuration software, visit www.seneca.it/products/z-key-wifi MI00544-0-EN...
- Page 2 WARNING: The full content of this manual must be read before any operation. The module must only be used by qualified electricians. Specific documentation is available at www.seneca.it/products/z-key-wifi The module must be repaired and damaged parts replaced by the Manufacturer. The product is sensitive to electrostatic discharges.
- Page 3 TECHNICAL SPECIFICATIONS Safety: EN60950, EN62311 Radio equipment device: EN301489-1 V2.1.1, EN301489-17 V3.1.1, EN300328 V2.1.1 STANDARDS Additional notes: a 1 A delayed fuse must be installed near the module, in series with the power supply connection. WIFI RS485 Comm. INSULATION (IDC10) Comm.
- Page 4 USB connector on the front panel and can be configured using applications and/or software programs. The USB serial port uses the following communication parameters: 115200,8,N,1 The USB communication port responds exactly like the serial ports, with the exception of the communication parameters. For more information, visit www.seneca.it/products/z-key-wifi Configurazione Configurazione Android APP...
- Page 5 ELECTRICAL CONNECTIONS Power supply and Modbus interface are available using the Seneca DIN rail bus, via the IDC10 rear connector, or the Z-PC-DINAL-17.5 accessory. Back connector (IDC 10) Power Suppl y AC / + RS485 GND The illustration shows the meanings of the various...
- Page 6 Easy Setup software. Micro SD card slot Z-KEY-WIFI has a micro SD card slot on the side of the case. To insert the SD card in the corresponding slot, make sure the metal contacts are facing right (as shown in the side figure).
- Page 7 The product programming tools can be downloaded free of charge from www.seneca.it, in the Z- KEY-WIFI section. To access the configuration, connect with a browser to the maintenance page at the IP address of the Z-KEY-WIFI, for example: http://192.168.90.101 and, when requested, enter the following credentials: Username: admin Password: admin.
