Seneca XVAULT XNVR400 Quick Start Up Manual

PLEASE SToP AND READ ThIS DoCUmENT
SENECA XVAULT XNVR QUICK START GUIDE
XVAULT XnVR400
This product contains software that must be registered for continued use
and to enjoy the benefits of eligibility for updates. Please take the time to
register the operating system and any applications installed on this product.

conTEnTS oF XVAULT XnVR400 PAckAGE

Quantity Item
1 xNVR400 Bay Storage Server
2 Power Cords
1 Bezel with Keys
1 Serial Cable (Ships with 12, 16, and 24 Bay Models)
1 DVI to VGA Adapter Cable (As needed)
Power Supply
Option

MAIn bAck PAnEL connEcTIonS

I/o Port connection Port Usage
NIC Port 0 Camera LAN
NIC Port 1 Viewing and Management LANs
USB Port 1 Mouse
USB Port 2 Keyboard
USB Port 3
noTE: For bIoS set-up use HDMI or DVI. only one monitor can be connected for bIoS set-up.
When the PCIe based graphics card is provided, Do noT use the capped VGA connector for monitor connection.

DEFAULT 1GbE FIXED IP ADDRESSES

Port
NIC 0*
NIC 1*
2 iSCSI/NAS**
3 iSCSI/NAS**
*Fixed non-routable addresses are recommended for Port 0 and Port 1 if DHCP server is not in network
**This is optional; iSCSI non-routable fixed IP addresses and isolated network is a practical requirement.

DRIVE SLoT LocATIonS bY cHASSIS MoDEL

xnVR 2U 4 bAY
SLoT-1 SLoT-2
xnVR 2U 8 bAY
SLoT-5 SLoT-6
SLoT-1 SLoT-2
xnVR 2U 12 bAY
SLoT-9 SLoT-10
SLoT-6
SLoT-5
SLoT-1 SLoT-2

bASE conFIGURATIon noTES

•
RAID Set(s) and associated spares configured per purchase order.
•
Operating system installed on drive C:
•
Video should be stored on Drives D: and higher
SoFTwARE GUIDAncE IS on THE bAck PAGE
IPMI
USB 1 USB 3
USB 2 USB 4
Default Label
Camera LAN
Viewing and Management
iSCSI/NAS 1
iSCSI/NAS 2
SLoT-3 SLoT-4
SLoT-7 SLoT-8
SLoT-3 SLoT-4
SLoT-11 SLoT-12
SLoT-7 SLoT-8
SLoT-3 SLoT-4

CRITICAL INFoRmATIoN:

DEFAULT LoG IN INFoRmATIoN
Username: Administrator
Password: P@ssw0rd
Note: This user has administrative privileges.
RESEAT ALL hoT-SwAP hARD DRIVES PRIoR To
booTING ThE SySTEm.
ALLow UP To 2 mINUTES FoR SySTEm To PoST.
NoThING wILL APPEAR oN ThE SCREEN DURING
ThIS TImE. Do NoT PowER oFF oR UNPLUG ThE
SySTEm DURING ThIS TImE.
Viewing and
Camera Management
LAN LAN
Port 1
Do Not Use
Port 1
I/o Port connection
USB Port 4
HDMI or DVI Port
iSCSI/NAS Port 3
iSCSI/NAS Port 4
SAS Expansion Port
IP Address
192.168.1.253
192.168.1.252
10.0.10.254
10.0.10.253
xnVR 3U 16 bAY
SLoT-13
SLoT-9
SLoT-5
SLoT-1
xnVR 4U 24 bAY
SLoT-21
SLoT-17
SLoT-13
SLoT-9
SLoT-5
SLoT-1
Port Usage
Video Display
Network Storage
(Optional)
Network Storage
(Optional)
Network Storage Direct Attached Storage (DAS)
(Optional)
Mask
255.255.255.0
255.255.255.0
255.255.255.0
255.255.255.0
SLoT-14 SLoT-15
SLoT-10 SLoT-11
SLoT-6 SLoT-7
SLoT-2 SLoT-3
SLoT-22 SLoT-23
SLoT-18 SLoT-19
SLoT-14 SLoT-15
SLoT-10 SLoT-11
SLoT-6 SLoT-7
SLoT-2 SLoT-3
SToP
AND READ
Port 3
Port 4
Gateway
192.168.1.1
192.168.1.1
SLoT-16
SLoT-12
SLoT-8
SLoT-4
SLoT-24
SLoT-20
SLoT-16
SLoT-12
SLoT-8
SLoT-4
XNVR400QS-V2.0.0515
*XNVR400QS-V2.0*
XNVR400QS-V2.0
