CONNECTING THE USB CABLE

EK-Loop Connect must be linked to the motherboard using the
supplied Internal USB 2.0 cable. Connect the 9-pin end to a USB2.0
header on the motherboard, pay attention to the orientaiton of the
missing pin.
9-Pin USB Connector
USB 2.0 Internal Header
The other end of the USB cable should be plugged into the Connects
USB port.
4-Pin USB Connector
USB Header
- 7 -
