Summary of Contents for EK Loop Connect 51
- Page 1 EK-Loop Connect CONTROLLER INSTALLATION MANUAL...
- Page 2 This product is intended for installation only by expert users. Please consult with a qualified technician for installation. Improper installation may result in damage to your equipment. EK Water Blocks assumes no liability whatsoever, expressed or implied, for the use of these products, nor their installation.
-
Page 3: Table Of Contents
TABLE OF CONTENT INSTALLING THE EK-LOOP CONNECT 51 IN TO THE CHASSIS CONNECTING THE FAN-S CONNECTING THE D-RGB LED TEMPERATURE SENSOR CONNECTING THE USB CABLE CONNECTING THE POWER ADAPTER SOFTWARE SUPPORT AND SERVICE SOCIAL MEDIA - 3 -... -
Page 4: Installing The Ek-Loop Connect 51 In To The Chassis
INSTALLING THE EK-LOOP CONNECT 51 IN TO THE CHASSIS STEP 1 Remove the desired 2.5” SSD tray STEP 1 STEP 2 M3x5 Install the EK-Loop Connect on to the metal plate using M3X5 DIN7985 DIN7985 Screws. Screw 2.5” SSD tray... -
Page 5: Connecting The Fan-S
STEP 3 Final Installation Attach the metal plate with pre-assembled EK-Loop Connect on to the case. STEP 3 CONNECTING THE FAN-S The controller is compatible with 4-pin PWM Fans, 3-pin Fans may be used however it will not be possible to adjust the speed. Insert the 4-pin Fan connectors as shown below to the 6 Fan headers marked F1-F6. -
Page 6: Connecting The D-Rgb Led
CONNECTING THE D-RGB LED There are 6 Lighting headers marked with L1-L6, these headers EK - Loop Connect are compatible only with 5V D-RGB products and LED strips! Make sure that the arrows are aligned. D-RGB Splitters may be used to connect multiple D-RGB products 3-Pin to a single header. -
Page 7: Connecting The Usb Cable
CONNECTING THE USB CABLE EK-Loop Connect must be linked to the motherboard using the supplied Internal USB 2.0 cable. Connect the 9-pin end to a USB2.0 header on the motherboard, pay attention to the orientaiton of the missing pin. 9-Pin USB Connector USB 2.0 Internal Header... -
Page 8: Connecting The Power Adapter
Molex connector directly from your PSU or the supplied 2x SATA Power adapter. Molex power header Molex power connector SOFTWARE Now that physicall installation of the EK-Loop Connect is complete you may install software and continue confirguring all connected components. - 8 -... -
Page 9: Support And Service
SUPPORT AND SERVICE For assistance please contact: http://support.ekwb.com/ EKWB d.o.o. Pod lipami 18 1218 Komenda Slovenia - EU SOCIAL MEDIA EKWaterBlocks @EKWaterBlocks ekwaterblocks EKWBofficial ekwaterblocks...
