INSTALLING THE EK-LOOP CONNECT 51 IN TO THE CHASSIS
STEP 1
Remove the desired 2.5" SSD tray
STEP 1
STEP 2
M3x5
Install the EK-Loop Connect on to the metal plate using M3X5
DIN7985
DIN7985 Screws.
Screw
2.5" SSD
tray
EK- Loop Connect
