KEY TO COMPONETS
A. 1 ea. Relocation bracket
B. 3 ea. ½-20 Flange nut
Please take a few minutes to read and thoroughly familiarize yourself with the installation procedures outlined in
this manual. Following the steps as outlined will save you time and help reduce mistakes. Once the instructions
are reviewed, if you feel that you are not capable of safely installing the parts seek the help of a qualified
installation expert to help you complete the job. The manufacture is in no way responsible for any personal
injury or vehicle damage that may occur during the installation.
.
California Proposition 65 Warning!
This product may contain one or more chemicals known to the State of California to cause
cancer and birth defects or other reproductive harm.
www.P65Warnings.ca.gov.
TOOLS NEEDED
Socket drive
19mm Wrench
18mm wrench
21mm socket
A
Spare Tire Relocation
Bracket
Installation Ins tructions
PART NUMBER: J130909
FITS Jeep Wrangler JK
B
For more information go to
07-18
Page 1
Advertisement
Table of Contents
Related Manuals for Redrock J130909
Summary of Contents for Redrock J130909
- Page 1 Installation Ins tructions A. 1 ea. Relocation bracket Socket drive B. 3 ea. ½-20 Flange nut 19mm Wrench PART NUMBER: J130909 18mm wrench 21mm socket FITS Jeep Wrangler JK 07-18 Please take a few minutes to read and thoroughly familiarize yourself with the installation procedures outlined in this manual.
- Page 2 FACTORY TIRE REMOVAL Step 1 • Remove spare tire from OE tire carrier. Set hardware aside for later use. INSTALLNG TIRE RELOCATION BRACKET Step 1. • Place supplied tire carrier onto the factory tire carrier fig 3. (image shown as reference) •...
