GENERAL NOTES
1. ALWAYS PROTECT THE UNIT DURING INSTALLATION.
2. LINEA BENCHES INSTALLATION
LINEA BENCHES HARDWARE
820158
531484
BLKCAP
CONNECTOR BOLT
1 WHEN ATTACHING BENCHES WITH NO BACK PANELS, INSERT DOWELS AS SHOWN (DETAIL A)
INTO CENTER ALIGNMENT HOLES.
SEE DETAIL
A
2 INSERT CONNECTOR BOLT & MATING BLKCAP INTO REMAINING 4 HOLES (FROM INSIDE THE BOX)
(DETAIL B, TOP REMOVED FOR CLARITY) & TIGHTEN.
ASSEMBLY INSTRUCTIONS
LINEA BENCHES
HBF-530396
820126
GANG PLATE
DOWEL
DETAIL B
SCALE 0.100
531217
GLIDE
SCREW
10X1 PH
DETAIL A
SCALE 0.080
E1013-0001-00
PAGE 1
19962-0001-00
GLIDE (4 PACK)
(HUBS ONLY)
