- Page 1 General User/ Safety Guide OLYMPIC TURNER www.harvesthealthcare.co.uk E sales@harvesthealthcare.co.uk www.harvesthealthcare.co.uk...
-
Page 2: Warnings And Cautions
Intended Use The Olympic Turner is designed to provide assistance when rising from and lowering into a seated position. It can also be used indoors to complete short distance transfers and to ease manoeuvring of users in confined spaces. - Page 3 OVERVIEW Handle Safety Attachement Buttons Knee Pads Platform Figure 1 - User Side Figure 2 - Carer Side Brake Lever Castors Wheels Figure 3 Figure 4 E sales@harvesthealthcare.co.uk www.harvesthealthcare.co.uk...
- Page 4 GENERAL USE 3.0 Assembly The product is packaged in two parts; the handle, with knee pads attached and the standing platform. 3.1 To attach the handle to the platform: 1. Position the handle over the standing platform ensuring the letter ‘F’ is facing the user side, figure 6.
- Page 5 Figure 11 4.1 Using the Olympic Turner to rise to a standing position: 1. Position the transfer aid at the feet of the seated user. Allow the user to place their feet on the platform, figure 11.
- Page 6 19. 2. Manoeuvre the user to the required position Figure 20 by pushing or pulling the Olympic Turner with the handle, figure 20. 3. When the new destination is reached lock the brakes by pushing down on the red section of the brake lever, figure 21.
- Page 7 GENERAL USE 5.0 Using the Safety Belt 3 Sizes of belt are available: HLA003.S - Small Safety Belt HLA003.M - Medium Safety Belt Figure 26 Figure 27 HLA003.L - Large Safety Belt 5.1 To fit the belt for short distance transfers: 1.
- Page 8 If it is to be used to assist the user when rising and lowering, consideration should be given to the number of carers needed to do so. Harvest Healthcare recommend a minimum of two. Figure 33...
-
Page 9: Cleaning And Care
Check the adjustment of the knee pad bracket runs smoothly and securely locks in position. • Store the Olympic Turner on a flat surface with the brakes locked, out of reach of children. • Periodically inspect the product for signs of wear. Any suspected faults or damage should immediately be reported to the supplier and the product taken out of use. - Page 10 NOTES ............................................................................................................................................................................................................................................................................................................................................................................................................ T +44 (0)1709 377172 F +44 (0)1709 377173...
- Page 11 NOTES ............................................................................................................................................................................................................................................................................................................................................................................................................ E sales@harvesthealthcare.co.uk www.harvesthealthcare.co.uk...
- Page 12 DOCUMENT REFERENCE: Olympic Turner- Dec 2018 © Copyright Harvest Healthcare Harvest Healthcare Limited. Company No: 07210261 Our Full Terms & Conditions are available by request or can be found on our Website. Harvest Healthcare reserves the right to alter or amend this document without notice.
