Installation Instructions for
IMPORTANT INFORMATION
- This product is wall mounted only.
- This instruction shows a typical installation
- The RGB LEDs are controlled by a wireless controller
(included) for light intensity, show & color modes.
SAVE THESE INSTRUCTIONS!
Install the Backplate
A
MIRROR
PHILLIPS SCREW
NOTE: It is recommended that one person holds the backplate
while the electrician installs it.
3: Align the backplate center hole with the electrical box. Level
the backplate horizontally and mark the four key holes onto
the wall.
4: Remove the backplate.
1718 W. Fullerton Ave
Chicago, IL 60614
Tel: 773-770-1195
Fax: 773-935-5613
www.edgelighting.com
info@edgelighting.com
Marilyn Moods Round RGB
1
BACKPLATE
1
MAR-RD-22-RGB-CH
1: Remove the two Phillips screws from the sides of the
backplate.
2: Carefully lift the mirror.
B
ELECTRICAL
BOX
3
BACKPLATE
CENTER HOLE
BACKPLATE
3
3
3
904-MARILYN-04
