Backyard Pro Butcher Series Instruction Manual

Hide thumbs Also See for Butcher Series:

Advertisement

Table of Contents

DEHYDRATORS
INSTRUCTION MANUAL
11/2019
#554BSD6T, #554BSD10T
Read carefully and understand all INSTRUCTIONS before operating. Failure to follow the safety
WARNING
rules and other basic safety precautions may result in serious personal injury. Save these
instructions in a safe place and on hand so that they can be read when required. Keep these
instructions to assist in future servicing.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Butcher Series and is the answer not in the manual?

Questions and answers

Related Manuals for Backyard Pro Butcher Series

Summary of Contents for Backyard Pro Butcher Series

  • Page 1 DEHYDRATORS INSTRUCTION MANUAL 11/2019 #554BSD6T, #554BSD10T Read carefully and understand all INSTRUCTIONS before operating. Failure to follow the safety WARNING rules and other basic safety precautions may result in serious personal injury. Save these instructions in a safe place and on hand so that they can be read when required. Keep these instructions to assist in future servicing.

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE USING YOUR DEHYDRATOR This product is intended for use in dehydrating food products. Do not use this appliance for any other purpose other than intended. TO AVOID RISKS OF ELECTRICAL SHOCK, BURNS OR INJURIES, WARNING ALWAYS MAKE SURE THE PRODUCT IS UNPLUGGED FROM THE ELECTRICAL OUTLET BEFORE DISPLACING, SERVICING OR CLEANING.
  • Page 3 IMPORTANT SAFETY INFORMATION 11. To avoid risk of electrical shock, fire or injuries: DO NOT immerse in or expose appliance, electrical cord or plug to water or other liquid. 12. A short power-supply cord is provided to reduce the hazards resulting from entanglement or tripping over a longer cord.
  • Page 4 PARTS AND OPERATING INSTRUCTIONS For the safest results, read all of the instructions first. 1. Make sure the power switch is turned off. Place the unit on a clean, dry surface. Plug into an undamaged electric outlet. 2. DO NOT block the air vents on the door or at the rear of the Dehydrator. Keep the Dehydrator at least 12”...

  • Page 5: Tools You Need To Get Started

    PARTS AND OPERATING INSTRUCTIONS 9. Display will show Time setting. Press Select again to confirm Time setting. Press Start (▼) to begin dehydration process. 10. Prior to the dehydrating process, heat the unit at 95°F for 45 minutes to remove any moisture. 11.

  • Page 6: Filling The Drying Trays

    PARTS AND OPERATING INSTRUCTIONS The skin of many foods naturally protects the food but it can hamper the dehydration process. During dehydration, moisture escapes best from a cut or broken surface not through the tough skin. Therefore, the larger the cut area, the faster and better the food will dehydrate. For this reason thin stalked vegetables like green beans, asparagus, and rhubarb should be cut in half the long way, or with an extreme diagonal cut to expose as much of the inner parts of the food as possible.
  • Page 7 RECONSTITUTION Dehydration is the process of removing moisture from food. Reconstitution is the replacement of that moisture to bring the food back to its natural states. Although some dried foods such as fruit are excellent in their dehydrated state, you will often want to reconstitute other dried foods before eating them.

  • Page 8: Food Preparation

    FOOD PREPARATION MEAT PREPARATION (Set temperature from 145°F to 155°F / 63°C to 68°C) Meat Preparation Dryness Test Approx. Time (hrs.) Beef Jerky Lean flank or round steak slices about 1 to 1½ Slightly chewy but 6 to 15 inches thick not brittle FRUIT PREPARATION (Set temperature at 135°F / 57°C)
  • Page 9 FOOD PREPARATION VEGETABLE PREPARATION (Set temperature at 125°F / 52°C) Fruit Preparation Dryness Test Approx. Time (hrs.) Artichokes Cut into ⅓ inch strips. Boil about 10 minutes Brittle 6 to 14 Asparagus Cut into 1-inch pieces. Tips yield better Brittle 6 to 14 product Beans...

  • Page 10: Care And Maintenance

    CARE AND MAINTENANCE CLEANING After each use, clean the drying trays and dehydrator lid with warm soapy water. Do not wash trays, lid or base in dishwasher. Stubborn particles may be removed by soaking and/or using a plastic scrubber. Do not use abrasive materials or solvents to clean plastic! To clean the dehydrator’s base (the bottom part with the motor and heating element), unplug and wipe clean with a damp sponge or cloth.
  • Page 11 EQUIPMENT LIMITED WARRANTY Backyard Pro Butcher Series warrants its equipment to be free from defects in material and workmanship for a period of 6 months. This is the sole and exclusive warranty made by Backyard Pro Butcher Series covering your Backyard Pro Butcher Series brand equipment.

This manual is also suitable for:

Butcher 54bsd6tButcher 554bsd10tButcher 554bsd6t
