This product works with the following
operating system software:
Windows 2000, Windows Me,
Windows 98se
Before You Begin
You must have at least the following:
•
A desktop computer with an available 32-bit PCI slot
•
At least a 300 MHz processor and 32 MB of memory
•
An 802.11a or 802.11b Access Point (for Infrastructure Mode) or another
802.11a or 802.11b wireless adapter (for Ad-Hoc; Peer-to-Peer
networking mode.)
Check Your Package Contents
These are the items included with your DWL-AB520 purchase:
If any of the above items are missing, please contact your reseller.
Insert the D-Link CD-ROM
Into Your Computer
Turn on the computer
AirPro DWL-AB520 Driver CD into the CD-ROM
drive. The step-by-step instructions that follow are
shown in Windows XP. The steps and screens are
similar for the other Windows operating systems.
©2002 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective holders. Software and specifications
Windows XP,
DWL-AB520 Wireless Multimode PCI Adapter
CD-ROM (containing Manual and Warranty)
and
Insert
the
subject to change without notice. DWL-AB520. 09062002
DWL-AB520
Multimode Wireless PCI Adapter
PCI Adapter into your
D- Link
computer before
installing the driver
software on the
D-Link CD!
D-Link AirPro™
Do
NOT
install
the DWL-AB520
