- Page 1 Quick start guide to the devices of the EuroProt+ product line Document ID: VERSION 1.0 Budapest, November 2010.
- Page 2 Quick start guide to the devices of the EuroProt+ product line User’s manual version information Version Date Modification Compiled by Preliminary 24.11.2009. Preliminary version Petri Version 1.0 11.11.2010. First edition Petri VERSION 1.0 2/14...
-
Page 3: Table Of Contents
Quick start guide to the devices of the EuroProt+ product line CONTENTS Application ...........................4 Meeting the device ......................4 Power supply ........................4 2.1.1 The power supply module ..................4 2.1.2 The hardware modules of the device ..............5 2.1.3 Fast startup ......................5 The front panel of the device ..................6 2.2.1 The structure of the human-machine interface of the device .......6 2.2.2... -
Page 4: Application
Quick start guide to the devices of the EuroProt+ product line 1 Application The EuroProt+ type complex protection in respect of hardware and software is a modular device. The modules are assembled and configured according to the requirements, and then the software determines the functions. -
Page 5: The Hardware Modules Of The Device
Quick start guide to the devices of the EuroProt+ product line Figure 2-1 The standard power supply modules 2.1.2 The hardware modules of the device For technical details of the modules of the EuroProt+ type complex protection please see the document “Hardware description”. -
Page 6: The Front Panel Of The Device
EOB device. The EOB device has an RJ45 EOB connector type connector supporting 10Base-T Ethernet connection to the user computer. This is a proprietary and patented solution from Protecta ltd. Table 2-1 The elements of the front panel VERSION 1.0 6/14... -
Page 7: Using The Menu Provided By The Touch-Screen
Quick start guide to the devices of the EuroProt+ product line 2.2.2 Using the menu provided by the touch-screen The main screen of the local LCD together with the “Change screen button” and the “Operation buttons” are shown in Figure 2-3 Figure 2-3 The main screen Touchscreen - The main control area where the user will enable functions and input values by touching the screen. - Page 8 Quick start guide to the devices of the EuroProt+ product line Figure 2-4 Some screens displayed on the LCD Touch the navigation icons or the displayed text lines to perform any actions via the LCD screen. For further details see the document “LCD touch-screen interface description”. VERSION 1.0 8/14...
-
Page 9: Using The Embedded Web Server
Quick start guide to the devices of the EuroProt+ product line 2.3 Using the embedded WEB server 2.3.1 Properties of the Ethernet communication The built-in 5 port Ethernet switch allows EuroProt+ to be connected to IP/Ethernet based networks. The following Ethernet ports are available: On the front panel of the device: EOB (Ethernet over Board) 10 Base-Tx user interface Figure 2-5... -
Page 10: The Ethernet Connection
Quick start guide to the devices of the EuroProt+ product line Interface types: On the front panel of the device: EOB interface: attachable to the front panel by a proprietary magnetic connector, the connector box ends in RJ45 8/8 plug. It is 10Base-T Full duplex interface. Figure 2-5 Table 2-2 On the rear side of the CPU unit (See... - Page 11 Quick start guide to the devices of the EuroProt+ product line 2.3.2.2 Using the RJ-45 connection The CPU version 0001 (see above) also has an RJ-45 socket. Using a UTP cross-cable with Figure RJ-45 connector at both ends, the device can be connected directly to a computer: .
- Page 12 Quick start guide to the devices of the EuroProt+ product line 2.3.2.3 Using the ST type fiber optic connection The ST type fiber optic connector of the 100Base-FX Ethernet provides connection to an Ethernet switch with identical fiber optic input. Using this connection all IED-s on the network Figure 2-9 with client functionalities, e.g.
- Page 13 Quick start guide to the devices of the EuroProt+ product line Cross-cable pinout Figure 2-10 Pinout of the cross-cable VERSION 1.0 13/14...
-
Page 14: Settings Needed For Ethernet Connection
Quick start guide to the devices of the EuroProt+ product line 2.3.3 Settings needed for Ethernet connection The EuroProt+ devices can be accessed over Ethernet based protocols only. That's why it is extremely important to set up the network before accessing the device. IP settings: The device operates with fixed IPv4 addressing.
