SAFETY MESSAGE TO INSTALLERS
People's lives depend on your safe installation
of our products. It is important to read, under-
stand and follow all instructions shipped with the
products. In addition, listed below are some other
important safety instructions and precautions you
should follow:
• To properly install this light: you must have a
good understanding of automotive electrical
procedures and systems, along with proficien-
cy in the installation and use of safety warning
equipment.
• When drilling into a vehicle structure, be sure
that both sides of the surface are clear of any-
thing that could be damaged.
• In order for the light to function properly, a
separate ground connection must be made. If
practical, it should be connected to the fusible
link at the front fender between the negative
(-) battery terminal and chassis ground. At a
minimum, it may be attached to a solid metal
body or chassis part that will provide an effec-
tive ground path as long as the light system is
to be used.
• Locate light control so the VEHICLE and CON-
TROL can be operated safely under all driving
conditions.
• Do not attempt to activate or deactivate light
control while driving in a hazardous situation.
• This product contains high intensity LED de-
vices. To prevent permanent eye damage, DO
NOT stare into the light beam at close range.
• You should frequently inspect the light to en-
sure that it is operating properly and that it is
securely attached to the vehicle.
• File these instructions in a safe place and refer
to them when maintaining and/or reinstalling
the product.
Failure to follow all safety precautions and instruc-
tions may result in property damage, serious injury, or
death to you or others.
I. GENERAL.
The Federal SignalMaster is an economical, low wattage,
directional light assembly that is designed for use in a flashing
mode. Lens colors available are: amber (standard), red, blue, green,
and clear.
These models provide two distinctive directional signals: left
arrow and right arrow. In addition, an alternating flash pattern
produces a warning signal for use when a directional signal may
not be appropriate. When a directional signal is selected, the lamps
INSTRUCTION SHEET
SIGNALMASTER™ MODELS 321102, 321112, 321702, AND 321712
FOR
are individually illuminated in a sequential sweeping motion until
all eight lamps are illuminated.
II. SPECIFICATIONS.
Input Voltage
Polarity
Operating Temperature
Range
Standby Current
+BAT Fuse
Output Drive
Capability (Total)
Flash Rate:
Directional
Warn
Dimensions:
Height
Length
Depth
Cable Length
These lights are intended for secondary warning
only. They are not intended for use as a primary
warning system.
III. INSTALLATION.
The SignalMaster's circuitry can be damaged, or de-
stroyed, by static discharge. To prevent ESD, observe
anti-static procedures during installation.
A. SignalMaster Light Assembly.
Install the light assembly as described in the instruc-
tions packed with the mounting kit.
B. Control Head.
When installing equipment inside air bag equipped
vehicles, the installer MUST ensure that the equip-
ment is installed ONLY in areas recommended by
the vehicle manufacturer.
Failure to observe this warning will reduce the
effectiveness of the air bag, damage the air bag,
or potentially damage or dislodge the equipment,
causing serious injury or death to you or others.
Assemble the control head as shown in figure 1. For
proper operation of the unit, the switches must be installed as
shown. To install the control head, proceed as follows:
11VDC to 16VDC (12V models).
22VDC to 28VDC (24V models).
Negative ground only.
-30° C to +65° C.
Zero amperes.
25 amperes (12V).
15 amperes (24V).
8, 27 watt lamps (12V models).
8, 20 watt lamps (24V models).
35 patterns/min.
60 patterns/min.
51" 42"
2.6" 2.6"
50.9" 42.0"
3.4" 3.4"
35' 15'
