- Page 1 QuadraFlare ® Model QL73LEDSCENE 7x3 LED Scene Light Installation and Maintenance Instructions 25500209 Rev. B1 0320 Printed in U.S.A. © Copyright 2015-2020 Federal Signal Corporation...
- Page 2 A copy of this limited warranty can also be obtained by written request to Federal Signal Corporation, 2645 Federal Signal Drive, University Park, IL 60484, email to info@fedsig.com or call +1 708-534-3400.
-
Page 3: Table Of Contents
Contents Safety Messages to Installers ............... 4 Overview of the Light ................5 Unpacking the Light ................6 Precautions for Installing the Light ............6 Mounting the Light ................. 7 Wiring the Light ..................11 Cleaning the Lenses................12 Safety Message to Operators .............. 13 Ordering Replacement Parts ............... -
Page 4: Safety Messages To Installers
Safety Messages to Installers Safety Messages to Installers People’s lives depend on your safe installation of our products. It is important to read, understand, and follow all instructions shipped with the products. Listed below are some other important safety instructions and precautions you should follow: •... -
Page 5: Overview Of The Light
Overview of the Light The 7x3 QuadraFlare LED Scene Light is a selfcontained, high ® intensity LED light designed for mounting to the exterior of a vehicle. The Model QL73LEDSCENE QuadraFlare LED scene light is designed for operation on 12 Vdc. With the latest in Solaris ®... -
Page 6: Unpacking The Light
Unpacking the Light Unpacking the Light After unpacking the light, inspect it for damage that may have occurred in transit. If it has been damaged, do not attempt to install or operate it. File a claim immediately with the carrier, stating the extent of damage. -
Page 7: Mounting The Light
Mounting the Light Mounting the Light AIRBAG DEPLOYMENT: Do not install equipment or route wiring in the deployment path of an airbag. Failure to observe this warning will reduce the effectiveness of the airbag or potentially dislodge the equipment, causing serious injury or death. Before proceeding, determine the approximate location of the light assembly and plan all cable/wire routing. - Page 8 Mounting the Light 6. Align the mounting gasket and the light as sembly with the screw grommets, and secure it with the provided #8 by 11/2 inch stainless steel screws. Be sure to have the lens mounted to the assembly with the top side of the lens at the top of the light.
-
Page 9: Table 2 Legend For Figure 1
Mounting the Light Figure 1 Exploded view of scene light 290A7964 Table 2 Legend for Figure 1 No. Description No. Description Mounting Screw, Vent #8 X 1-1/2 in, S.S. Reflector Grommet Control PC Board Assy. Wire Harness LED PC Board Assy. Reflector Mounting Screw Base Lens Gasket... -
Page 10: Figure 2 Dimensions Of Mounting Holes On Vehicle
Mounting the Light Figure 2 Dimensions of mounting holes on vehicle 6.56 " (2X) 1.00" 3.28 (2X) 0.25" (4) Places 1.19" (2X) 2.38" (2X) Figure 3 Interior of scene light base 290A7965 Vent Hole 290A7966 Model QL73LEDSCENE Federal Signal www.fedsig.com... -
Page 11: Wiring The Light
Wiring the Light Wiring the Light The light assembly operates on 12 Vdc. Two 12 inchlong lead wires are supplied for making electrical connections to the light assembly. Use 18 AWG (minimum) wire. Ensure that all wires are properly connected and insulated ap propriately. LIGHT HAZARD: This product contains high intensity LED devices. -
Page 12: Cleaning The Lenses
Cleaning the Lenses Cleaning the Lenses CRAZING/CRACKING Crazing (fine cracks) of lenses causes reduced effectiveness of the light. Do not use cleaning agents (which cause crazing) such as strong detergents, solvents, or petroleum products. If crazing of the lenses does occur, the reliability of light for emergency signaling purposes may be reduced until the lenses are replaced. -
Page 13: Safety Message To Operators
Safety Message to Operators Safety Message to Operators Peoples’ lives depend on your safe use of our products. Listed below are some important safety instructions and precautions you should follow: • This light does not comply with warning light standards. Do not use this light as a warning light. -
Page 14: Ordering Replacement Parts
Ordering Replacement Parts Ordering Replacement Parts To order replacement parts, please contact your local dealer/ distributor or: Customer Support Federal Signal Corporation Phone: 18002643578, 17085343400 Monday Friday, 7:00 a.m. to 5:00 p.m. CST http://www.fedsig.com Table 3 Replacement parts Description... -
Page 15: Getting Technical Support And Service
Ordering Replacement Parts Getting Technical Support and Service For technical support and service, please contact: Federal Signal Corporation Service Department Public Safety Systems Phone: 18004339132 Fax: 18003439706 Email: empserviceinfo@fedsig.com Getting Repair Service The Federal Signal factory provides technical assistance with any problems that cannot be handled locally. - Page 16 2645 Federal Signal Drive University Park, Illinois 60484 www.fedsig.com Customer Support Police/Fire-EMS: 800-264-3578 • +1 708 534-3400 Work Truck: 800-824-0254 • +1 708 534-3400 Technical Support 800-433-9132 • +1 708 534-3400...
