Biological Microscope
ATTENTION: The operators must carefully read and completely understand the present
manual before using the product.
31002
Fabbricante
Manufacturer
Teme l'umidità
Keep dry
Alltion (Wuzhou) Co., Ltd.
Alltion Building, NO.10, 3rd Road, Wuzhou Industrial Park,
Wuzhou, Guangxi, China
Made in China
Gima S.p.A.
Via Marconi, 1 - 20060 Gessate (MI) Italy
gima@gimaitaly.com - export@gimaitaly.com
www.gimaitaly.com
Conservare al riparo della luce solare diretta
Keep away from sunlight
USE AND MAINTENANCE BOOK
Advertisement
Related Manuals for Gima 31002
Summary of Contents for Gima 31002
- Page 1 Gima S.p.A. Via Marconi, 1 - 20060 Gessate (MI) Italy gima@gimaitaly.com - export@gimaitaly.com www.gimaitaly.com Biological Microscope USE AND MAINTENANCE BOOK ATTENTION: The operators must carefully read and completely understand the present manual before using the product. Teme l’umidità Conservare al riparo della luce solare diretta...
- Page 4 Biological Microscope 01 Eyepiece 02 Nosepiece 03 Objective 04 Condenser 05 Aperture Iris Diaphragm adjustment 06 Illumination 07 Main body 08 Main Switch 09 Bulb 10 Screw 11 Interpupillar Distance Indicator 12 Binocular viewing head 13 Stage 14 Portrait Adjustment Knob 15 Lateral Adjustment Knob 16 Right Fine Focus Knob 17 Right Coarse Focus Knob...
- Page 5 7. Always use the power cord provided by Gima. 8. The electrical equipment of the microscope should be discard as electronic waste.
- Page 6 ENGLISH Assembly procedure Before installing, be sure every components is clean, do not score any parts or glass surface. Keep well with hexagon wrench provided. When changing the components, you will need it again. Installing binocular viewing head Insert the binocular viewing head 12 into the microscope head and turn it to a proper position, then tight it.
- Page 7 ENGLISH Installing the objective 1. Adjusting the coarse focus knob until the support device of the mechanical stage reaches its low limit position. 2. Screw the lowest magnification objective 03 into the nosepiece 02 from the left or the right side, then revolve the nosepiece 02 clockwise and mount other objectives by the sequence of low to high magnification Installing objective this way will make the change...
- Page 8 ENGLISH Replacing the fuse Do remember to set the main switch 08 to the state “0” (OFF) and unplug the power cord before replacing the fuse. Rotate the fuse out of the holder 27, replace with a new fuse, then rotate it back to the holder again.
- Page 9 ENGLISH Focusing the Specimen 1. Focus the specimen with 10x objective. To avoid the objective touching the specimen during focusing, you should raise the mechanical stage to let the specimen close to the objective at first, then slowly separate them to bring the specimen to focus. Turn the coarse focus knob 25 conversely to lower the specimen and search images in the 10×ocular simultaneously, and thenuse the fine knob 24 to focus.
- Page 10 ENGLISH Adjusting the Interpupillary Distance The interpupillary distance range: 55mm ~ 75mm While looking through the eyepieces, move both eyepieces round until the left and right fields of view coincide completely. Adjusting the Diopter 1. Turn the eyepiece 01 to adjust the diopter while looking through it. The diopter range of the eyepiece is±5 diopter.
- Page 11 ENGLISH Technical Specifications Main Specifications Optical System Limited optical system/Infinite optical system Viewing Head Seidentopf Binocular Head, 30°Inclined,Interpupillary Distance 48- 75 mm Eyepiece WF 10X/18 WF 10X/20 Nosepiece Backward Quadruple Nosepiece Objective Achromatic Objective/Infinite Semi-plan Objective 4×, 10×, 40×, 100× Focusing Coaxial Coarse and Fine Adjustment, Moving Range 0.002mm <,Fine Division 20mm Condenser Abbe Condenser, NA1.25 Stage...
-
Page 12: Troubleshooting Guide
ENGLISH Troubleshooting Guide Optical System TROUBLE CAUSE SOLUTION 1. The edge of the The nosepiece is not in the located Locate the nosepiece properly field of view is dark position (objective and light path not where it clicks or the brightness is coaxial) not uniform The surface of the lamp becomes black Change a new lamp bulb A lens (the objective, condenser, Clean it thoroughly... - Page 13 The warranty is valid for 12 months from the date of supply of GIMA. During the period of validity of the warranty, GIMA will repair and/or replace free of charge all the defected parts due to production reasons. Labor costs and personnel traveling expenses and packaging not included.
