Release date: 20.02.19 rev 1.0 19 SW25
AUTHOR: PASER
CODE: CF0052USDB11
JL AUDIO
45'
uDAB
MM50
KIT052USDB11/JL
USBCOM
USBREC
SCREWS
PLUG AND PLAY
BUTTON
DESCRIPTION
uDAB is the new Paser product that allows, in a few simple opera ons, the best integra on of the
DAB/DAB + digital radio on your vehicle.
It's enough to install the harness, supplied with the KIT, in series to the radio.
This means that no changes to the original wiring are required, thus to avoid cable and / or incorrect con-
nec on risks.
The module connects to the radio via the USB COM wiring, supplied in the KIT.
Thanks to this connec on, uDAB is compa ble with all the radios with USB input on the market.
The USB REC harness, supplied with the KIT, will allow the na ve USB radio func on to be maintained.
By inser ng a USB s ck user can listen to his music as before.
All uDAB features are handled directly by the radio and/or steering wheel controls.
DAB/DAB + radio sta ons will be displayed as mp3 files with TAG names of the radio sta on tuned.
There will also be available folders named as the various MUXs present in the coverage area.
A SCAN folder will be present to manage at best the tuning of available radio sta ons in the area.
Thanks to CRICKET TECHNOLOGY ® developed by Paser (Patent Pending), channel skips do not have sig-
nificant audio buffer delays, the user will have the pleasant feeling of listening to the radio as always, but
with DAB/DAB + audio quality.
Same technology allows to control the volume directly from the head unit.
uDAB incorporates a powerful amplifier that provides 40 W per channel in AB class.
AUDIO quality, simplicity of installa on and use to ensure maximum and high-class sa sfac on.
1
Advertisement
Summary of Contents for Paser KIT052USDB11/JL
- Page 1 BUTTON DESCRIPTION uDAB is the new Paser product that allows, in a few simple opera ons, the best integra on of the DAB/DAB + digital radio on your vehicle. It's enough to install the harness, supplied with the KIT, in series to the radio.
- Page 2 Release date: 20.02.19 rev 1.0 19 SW25 AUTHOR: PASER uDAB INSTALLATION STEPS 1. Connect the power/speakers T harness of the KIT in series to the radio one. 2. Connect the USBCOM and USBREC to the plugs on UDAB module. 3. Connect the SMB plug of the DAB antenna to the related plug on the module.
- Page 3 Release date: 20.02.19 rev 1.0 19 SW25 AUTHOR: PASER uDAB FUNCTIONS MANAGEMENT BUTTON FUNCTION BUTTON FUNCTION LED ON LED ON, LONG PRESSURE UDAB IN FUNCTION. BUTTON: START SCAN. LED ON, SHORT PRESSURE BUTTON. LED OFF, LONG PRESSURE LED GOES OFF: BUTTON: USB FUNCTION FOR LISTENING USB PEN.
- Page 4 Release date: 20.02.19 rev 1.0 19 SW25 AUTHOR: PASER uDAB FUNCTIONS MANAGEMENT From the folders menu in SYSTEM folder, Some seEng op ons are available. Once selected the op on please wait 10 seconds before it start. OPTION 00 A UDAB FW V XX: shows firmware version.
- Page 5 SCAN CRICKET TECHNOLOGY ® CRICKET TECHNOLOGY ® is a solu on designed by Paser to remedy the problem of buffering AUDIO on which USB playback is based. With this technology (patent pending) there is no audio reproduc on delay during sta-...
- Page 6 Release date: 20.02.19 rev 1.0 19 SW25 AUTHOR: PASER uDAB TROUBLESHOOTING uDAB manages its opera on following the USB protocol. Some radios respond to the protocol with similar but not equal parameters. Therefore it is necessary to be able to change certain seEngs in case you encounter some malfunc ons.
- Page 7 Release date: 20.02.19 rev 1.0 19 SW25 AUTHOR: PASER uDAB UPDATE UDAB update is elementary. No special soDware is required. It is sufficient to download the update file, then transfer it to a USB s ck. Now with UDAB powered (red or green LED) insert the USB s ck on the USB port of the module.
-
Page 8: Technical Characteristics
3on the informa3on are correct and reliable. However Paser can not be held responsible for any consequences resul3ng from errors, omissions or incongruence of this manual. Paser reserves the right to improve / change the product or manual without obliga3on to no3-...
