- Page 1 OPS-A150, OPS-A500 ® Oriel Arc Lamp Power Supplies Quick Start Guide Family of Brands – ILX Lightwave • New Focus™ • Ophir • Corion • Richardson Gratings™ • Spectra-Physics ® ® ® QSOPS-A, Rev A 02/25/2016...
- Page 2 OPS-A Arc Lamp Power Supplies Page 2 1 GENERAL INFORMATION ..................3 1.2 GENERAL WARNINGS ......................4 1.3 ELECTRICAL HAZARDS ......................5 1.4 FIRE HAZARDS ......................... 5 1.5 LAMP HANDLING ........................5 1.6 LIGHT HAZARDS ........................5 2 INTRODUCTION ......................6 2.1 ARC LAMP COMPATIBILITY ....................
-
Page 3: General Information
The safety of any system incorporating the OPS power supply is the sole responsibility of the assembler of the systems. If the equipment is used in a manner not specified by Newport Corporation, the protection provided by the equipment may be impaired. -
Page 4: General Warnings
OPS-A Arc Lamp Power Supplies Page 4 1.2 GENERAL WARNINGS Read all warnings and operating instructions for this system prior to setup and use. Do not use this equipment in or near water. To prevent damage to the equipment, read the instructions in the equipment manual for proper input voltage. - Page 5 Each compatible Newport brand lamp housing is equipped with a condenser lens. The re-focused output of this lens can cause ignition of flammable targets including but not limited to walls, certain chemicals.
- Page 6 2 INTRODUCTION 2.1 ARC LAMP COMPATIBILITY Newport Corporation offers all the components required to assemble a complete illumination system. The minimum components include a lamp, lamp housing, power supply, and possibly a socket adapter. The table below explains which components are compatible with each other to create an illumination system.
-
Page 7: System Setup
OPS-A Arc Lamp Power Supplies Page 7 OPS-A500 Lamp Compatibility Table Compatible Oriel Lamp Housings Q Housing Research Lamp Housings Power Lamp Lamp Rating, [Socket Supply Description Adapter] [Socket Adapter] 66901, 66902, 66904, 66905, 66912, 67001, 67005 6283NS Hg 200W [66144] 66901, 66902, 66904, 66905, 66912, 67001, 67005... -
Page 8: Choosing A Location
Inspect the contents for damage. If any item is missing or damaged, immediately contact Oriel Instruments or the Newport representative from whom the system was purchased. It is suggested to save the packaging material and shipping container, in case the equipment needs to be relocated at a future date. -
Page 9: Power Supply Connections
OPS-A Arc Lamp Power Supplies Page 9 3.4 POWER SUPPLY CONNECTIONS 3.4.1. Front Panel Controls/Connections Figure 1 OPS-A Power Supply Front Panel Connections. A. USB. The USB connector on the front panel is used to install firmware and LCD GUI updates to the power supply. - Page 10 OPS-A Arc Lamp Power Supplies Page 10 F. LAMP. The LAMP button is for manual control of the lamp. When pressed, the lamp will ignite/power down. G. Control knob. The control knob is for setting the parameters specific to each power supply feature. H.
- Page 11 OPS-A Arc Lamp Power Supplies Page 11 Connect the power cord to the back of the OPS before plugging it into an AC electrical outlet. ELECTRICAL SHOCK HAZARD To avoid electric shock, connect the instrument to a properly earth- grounded, 3-prong receptacle only. Failure to observe this precaution can result in severe injury or death.
- Page 12 Do not press the Lamp On button until the output flange is directed in such a way that people, animals and equipment will not be harmed by the light. If there are any questions or concerns, contact Oriel Instruments or the regional sales representative for Newport.
-
Page 13: Initial Start-Up Screen
OPS-A Arc Lamp Power Supplies Page 13 3.5 INITIAL START-UP SCREEN Upon powering up the OPS-A Model Power Supply the following screen will appear on the power supply’s LCD: Figure 3 The LCD display of the OPS-A Model Power Supply. A. - Page 14 A lamp interconnection cable must be purchased for use with an arc lamp housing, based on the type of lamp being utilized. Replacement cables may also be purchased if needed. Interconnection cables are available on Newport.com. Lamp Housing Interconnection Cables (6 foot,...
- Page 15 OPS-A Arc Lamp Power Supplies Page 15 Figure 4 The output connector on the rear panel of the OPS-A150/OPS-A500 Power Supply for interface with Oriel Lamp Housing. The 70050 (Black) and 70051 (Grey) Lamp Housing Interconnection Cables are also shown. If a replacement cable is needed, please contact Oriel Instruments.
- Page 16 OPS-A Arc Lamp Power Supplies Page 16 4.1 CONNECTION TO A Q SERIES TYPE HOUSING For connecting the OPS-A Series Power Supply to a Q Series Type Housing, use the proper cable to suit the type of DC arc lamp used as designated in the table on the previous page and the Arc Lamp Interface with Ignitor that has been coupled to the housing.
-
Page 17: Safety Interlock
Page 17 4.3 SAFETY INTERLOCK Newport’s Oriel Power Supplies have a safety interlock feature which must be satisfied before the power supply will power the lamp and which, if broken during operation, will disable the power supply. Overheating of the housing or accidental opening of the door will automatically shut down the power supply. - Page 18 Be aware that Pmax cannot be changed when the lamp is ignited. Note. If using a lamp purchased from Newport Corporation, set Pset to the desired operating power. Pmax is typically set at 10% higher than the lamp rating. If not using a lamp purchased from Newport Corporation, it is best to follow operation power and maximum power supply guidelines determined by the lamp manufacturer.
- Page 19 OPS-A Arc Lamp Power Supplies Page 19 If the “Warning Imax Setting” message appears on the screen as shown below while the power supply is being operated in Power Mode, this indicates that the Imax setting in Current Mode is set too low for the lamp to reach the desired Pset.
- Page 20 OPS-A Arc Lamp Power Supplies Page 20 5.2 CURRENT OPERATION MODE In current mode, the lamp is operated at a constant current setting. As the voltage cannot be changed, the power is raised or lowered to maintain the current at the same level. As the lamp ages, the power is increased.
- Page 21 Page 21 Note. If a lamp that was not purchased from Newport Corporation is being used, use the manufacturer’s current specifications for operation. If the lamp operating power and voltage are known but the operating current is not, determine the current setting by using Ohm’s Law: Amperes = Power ÷...
- Page 22 OPS-A Arc Lamp Power Supplies Page 22 6 OPS-A SERIES OVERVIEW OPS-A150 OPS-A500 50 – 150 W 200 – 500 W Approved Lamp Wattage Power Factor >0.99 95 – 264 VAC Input Voltage Input Current Max 47 – 63 Hz Input Frequency Output Current Range 1.5 –...
- Page 23 The Newport programs and all materials furnished or produced in connection with them ("Related Materials") contain trade secrets of Newport and are for use only in the manner expressly permitted. Newport claims and reserves all rights and benefits afforded under law in the Programs provided by Newport Corporation.
- Page 24 Page 24 operations, visual display, or output reports of the Programs; 3) previously in the possession of Customer or subsequently developed or acquired without reliance on the Newport Programs; or (4) approved by Newport for release without restriction. First printing 2014 ©...
