ActionTec ECB6250 KIT Quick Start Manual

Moca 2.5

E C B 6 2 5 0 K I T

Quick Start Guide

MoCA 2.5 Network Adapters

This Quick Start Guide will walk you through the easy

steps to connect your MoCA Network Adapters.

Package Contents:

(2) MoCA Network

Adapters

(2) Ethernet Cables

(2) Power Adapters

(External, 5V DC, 2A

made by APD,

Model #WB-10E05FU)

(2) Coaxial Cables

(2) Coaxial Splitters

Table of Contents

Do you have a question about the ECB6250 KIT and is the answer not in the manual?

Page 1 E C B 6 2 5 0 K I T Quick Start Guide MoCA 2.5 Network Adapters This Quick Start Guide will walk you through the easy steps to connect your MoCA Network Adapters. Package Contents: (2) MoCA Network (2) Power Adapters (2) Coaxial Cables Adapters (2) Coaxial Splitters...
Page 2 Step 1 : Connect to your Modem/Rout- Get one MoCA Network Adapter. Connect one Ethernet Cable from the Network Adapter to the Modem/Router. Connect one Splitter to the Coax Cable coming from the Coax Outlet on the wall. Connect one Coax Cable from the Splitter to the Coax In port on the Network Adapter.
Page 3 Step 2: Connect to your Device Get one MoCA Network Adapter. Locate the device or access point (laptop, etc.) that needs to connect to the Internet. Connect one Ethernet Cable from the Network Adapter to the Device. Connect one Splitter to the Coax Cable coming from the Coax Outlet on the wall.
