VELVET
FROZEN
USER
INSTRUCTIONS
N° DOC. UM000346
REV. A - 08.04.19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VELVET FROZEN and is the answer not in the manual?

Questions and answers

Related Manuals for Costan VELVET FROZEN

Summary of Contents for Costan VELVET FROZEN

  • Page 1 VELVET FROZEN USER INSTRUCTIONS N° DOC. UM000346 REV. A - 08.04.19...
  • Page 2 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT VELVET FROZEN ORD. DATE ORD. DATE ORIGINAL N° DOC. UM000346 08.04.19 PAGE 2/24 N° CHAP. FIRST ISSUE 17.12.18 MKTG ISSUE INDEX CAP. N° N° PAG. INDEX pag.2 SAFETY ADVICE pag.3...

  • Page 3: Safety Advice

    IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT VELVET FROZEN ORD. DATE ORD. DATE ORIGINAL N° DOC. UM000346 08.04.19 PAGE 3/24 N° CHAP. FIRST ISSUE 17.12.18 MKTG ISSUE SAFETY ADVICE ENSURE THAT AIR SLOTS ON THE CABINET ENCLOSURE ARE FREE FROM OBSTRUCTION.
  • Page 4 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT VELVET FROZEN ORD. DATE ORD. DATE ORIGINAL N° DOC. UM000346 08.04.19 PAGE 4/24 N° CHAP. FIRST ISSUE 17.12.18 MKTG ISSUE IN ORDER TO REDUCE FLAMMABILITY-RELATED RISKS, THIS CABINET MAY ONLY BE INSTALLED BY SUITABLY QUALIFIED PERSONNEL.
  • Page 5 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT VELVET FROZEN ORD. DATE ORD. DATE ORIGINAL N° DOC. UM000346 08.04.19 PAGE 5/24 N° CHAP. FIRST ISSUE 17.12.18 MKTG ISSUE 1. INTRODUCTION 1.1 CLAUSES THIS INSTRUCTION MANUAL IS AN INTEGRAL PART OF THE PRODUCT AND MUST BE KEPT UNTIL THE PRODUCT IS DISMANTLED.
  • Page 6 8. Climate class, temperature and relative humidity of the reference climate class. 9. Insulation blowing gas 10. CE marking and any other marks The plate must remain unchanged over time; it shows the details to provide to COSTAN if the need for assistance arises.
  • Page 7 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT VELVET FROZEN ORD. DATE ORD. DATE ORIGINAL N° DOC. UM000346 08.04.19 PAGE 7/24 N° CHAP. FIRST ISSUE 17.12.18 MKTG ISSUE The A weighted sound pressure level emitted by the meuble is less than 70dB (A).

  • Page 8: General Information

    4.4 COPYRIGHT This manual is the exclusive property of COSTAN. Handing this manual over to third parties must be authorized by COSTAN’s management team. It is strictly prohibited to copy, reproduce with any medium, even partially, drawings and docu- ments contained in this manual.
  • Page 9 It is prohibited to remove any guard or panel if a tool is required to do so. It is forbidden to tamper with or alter the product. Any other use which is not specifically indicated in the manual is considered hazardous and COSTAN cannot be held responsible for any damage caused by improper and unreasonable use.
  • Page 10 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT VELVET FROZEN ORD. DATE ORD. DATE ORIGINAL N° DOC. UM000346 08.04.19 PAGE 10/24 N° CHAP. FIRST ISSUE 17.12.18 MKTG ISSUE 6. HANDLING AND STORAGE (SPECIALIST TECHNICIAN) 6.1 HANDLING The loading and unloading operations must be performed by qualified staff, who will verify the exact weights and lifting points;...
  • Page 11 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT VELVET FROZEN ORD. DATE ORD. DATE ORIGINAL N° DOC. UM000346 08.04.19 PAGE 11/24 N° CHAP. FIRST ISSUE 17.12.18 MKTG ISSUE DON’T PUSH THE CABINET THROUGH THE UPRIGHTS 6.2 STORAGE...
  • Page 12 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT VELVET FROZEN ORD. DATE ORD. DATE ORIGINAL N° DOC. UM000346 08.04.19 PAGE 12/24 N° CHAP. FIRST ISSUE 17.12.18 MKTG ISSUE 7. AMBIENT CONDITIONS FOR INSTALLATION The equipment must be installed in a closed environment, covered and safe from atmospheric agents.
  • Page 13 The systems must comply with the regulations that govern their construction, installation, use and maintenance. COSTAN declines any responsibility towards users and third parties for any damage that may be caused by malfunction or faults in the systems that power the product. It also declines any responsibility for damage which could be caused by the product by causes that are directly dependent on the malfunction of the electrical system.

  • Page 14: First Cleaning

    IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT VELVET FROZEN ORD. DATE ORD. DATE ORIGINAL N° DOC. UM000346 08.04.19 PAGE 14/24 N° CHAP. FIRST ISSUE 17.12.18 MKTG ISSUE You are reminded that: • It is obligatory to consult the wiring diagrams before making the connection.

  • Page 15: Loading The Product

    IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT VELVET FROZEN ORD. DATE ORD. DATE ORIGINAL N° DOC. UM000346 08.04.19 PAGE 15/24 N° CHAP. FIRST ISSUE 17.12.18 MKTG ISSUE 10. USE OF THE CABINET (OPERATOR) 10.1 PERFORMANCE The Cabinet is suited exclusively to displaying frozen food.
  • Page 16 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT VELVET FROZEN ORD. DATE ORD. DATE ORIGINAL N° DOC. UM000346 08.04.19 PAGE 16/24 N° CHAP. FIRST ISSUE 17.12.18 MKTG ISSUE • Don’t obstruct “B” slot of refrige- rated air exit.

  • Page 17: Lighting Switch

    IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT VELVET FROZEN ORD. DATE ORD. DATE ORIGINAL N° DOC. UM000346 08.04.19 PAGE 17/24 N° CHAP. FIRST ISSUE 17.12.18 MKTG ISSUE 10.3 ACCESSORIES 10.3.1 FRONT ANTI-MIST The cabinets avail of an anti-condensation ventilation system for the front glass. If the excess...

  • Page 18: Internal Cleaning

    IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT VELVET FROZEN ORD. DATE ORD. DATE ORIGINAL N° DOC. UM000346 08.04.19 PAGE 18/24 N° CHAP. FIRST ISSUE 17.12.18 MKTG ISSUE 11.1 ESTERNAL CLEANING Clean all the external parts of the cabinet on a weekly basis, using exclusively warm water and soap or neutral detergent for domestic use diluted in water.
  • Page 19 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT VELVET FROZEN ORD. DATE ORD. DATE ORIGINAL N° DOC. UM000346 08.04.19 PAGE 19/24 N° CHAP. FIRST ISSUE 17.12.18 MKTG ISSUE Remove the EVAPORATOR-COVER “A” Be careful not to cut yourself with the thin evaporator fins or with edges or corners of adjacent sheets.
  • Page 20 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT VELVET FROZEN ORD. DATE ORD. DATE ORIGINAL N° DOC. UM000346 08.04.19 PAGE 20/24 N° CHAP. FIRST ISSUE 17.12.18 MKTG ISSUE 12. MAINTENANCE (SPECIALIST TECHNICIAN) The activities described in this chapter must be performed by a specialist technician.
  • Page 21 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT VELVET FROZEN ORD. DATE ORD. DATE ORIGINAL N° DOC. UM000346 08.04.19 PAGE 21/24 N° CHAP. FIRST ISSUE 17.12.18 MKTG ISSUE W/o electrical With electrical AKCC550A Unit VLT HFC...
  • Page 22 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT VELVET FROZEN ORD. DATE ORD. DATE ORIGINAL N° DOC. UM000346 08.04.19 PAGE 22/24 N° CHAP. FIRST ISSUE 17.12.18 MKTG ISSUE 13. DISPOSAL (SPECIALIST TECHNICIAN) All countries have different legislations; therefore, the specific prescriptions enforced by the legislation and local authorities of the country where the equipment is demolished must be observed.

  • Page 23: Rohs Declaration

    COSTAN. Rohs Declaration The undersigned COSTAN with registered office in Solesino Viale delle Industrie n , Padova, Italy declares under its full responsibility that the object of this manual, namely the refrigerated cabinet equipped with incorporated refrigeration unit, satisfies the requirements of directive 2002/95/CE (RoHS).
