- Page 1 EN-202 PCIe 2-Port 10G SFP+ Network Controller Card User’s Manual Ed – 31 May 2019...
- Page 2 This equipment has been tested and found to comply information and technical support. with the limits for a Class A digital device, pursuant to http://www.gbord.com/ Part 15 of the FCC Rules. These limits are designed to Copyright and Trademarks provide...
-
Page 3: Table Of Contents
Table of Contents Chapter 1: Introduction ......................... 4 1.1 Module Physical Features ......................4 1.2 System Requirements ........................5 1.3 Package contents ........................5 Chapter 2: Getting Started ........................6 2.1 Hardware Layout .......................... 6 2.2 Hardware Installation ........................7 2.3 Driver Installation .......................... -
Page 4: Chapter 1: Introduction
Chapter 1: Introduction This PCIe 10G SPF+ Network Card is a cost-effective solution that delivers fast and reliable 10 Gbps network access at longer distances than copper-based networks. Using the SPP+ transceiver of your choice, you can connect your PCI Express-based server or workstation directly to your 10G fiber optic network. -
Page 5: System Requirements
1.2 System Requirements Hardware The following system specs are recommended minimum PCIe slot: Available 4-Lanes PCI-Express slot gen 2.0 or later Processor: Quad Core 3.0GHz or higher RAM: 4GB memory or higher Software Operating systems supported are (both 32 and 64 bits) Windows 7 ... -
Page 6: Chapter 2: Getting Started
Chapter 2: Getting Started 2.1 Hardware Layout... -
Page 7: Hardware Installation
Link/Activity Indicator: When the LED is off, there is no link between the PCIe 10G SFP+ Network Card and the network When the LED is on, a link is established, but there is no traffic on the network When the LED is flashing, there is traffic on the network to which the PCIe 10G SFP+ Network Card is ... -
Page 8: Verifying The Installation
Please click “PCIe Intel” to start the installation. Follow the instructions on screen to install the driver. Installation for Linux Insert the provided CD into your CD-ROM drive. Extract the compressed driver source file to a certain directory by the following command: (Please copy the driver file “ixgbe-x.x.x.tar.gz”... - Page 9 1port 2port Verifying for Linux You can check whether the driver is loading by using following commands: # lsmod | grep # ifconfig –a If there is a device name, ethX, shown on the monitor, the linux driver is load. Then, you can use the following command to activate the ethX.
