Climax TSP-3 User Manual

Touchscreen
Hide thumbs
Table of Contents

Advertisement

Quick Links

TSP-3
Touchscreen Keypad
User Manual
June, 2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TSP-3 and is the answer not in the manual?

Questions and answers

Related Manuals for Climax TSP-3

Summary of Contents for Climax TSP-3

  • Page 1 TSP-3 Touchscreen Keypad User Manual June, 2020...

  • Page 2: Table Of Contents

    Table of Contents INTRODUCTION _____________________________________________________________________ - 1 - SYSTEM OVERVIEW _______________________________________________________________ 2 1.1. ___________________________________________________________ 2 ARTS DENTIFICATION 1.2. ________________________________________________________________ 3 OWER UPPLY GETTING STARTED _______________________________________________________________ 3 2.1. ____________________________________________________________ 3 QUIPMENT REQUIRED 2.2. _______________________________________________________________________ 3 ETUP 2.3. _________________________________________________________ 6 ARDWARE NSTALLATION 2.4.

  • Page 3: Introduction

    Introduction The Touchscreen Keypad provides easy-to-use, on-premises security system control for enhanced flexibility and convenience. When connected to the system Control Panel via Wi-Fi network, the Touchscreen Keypad enables quick access to the Control Panel, allowing users to easily arm, disarm, or home arm their security system and control home devices.

  • Page 4: Getting Started

    2. Getting Started 2.1. Equipment required The following equipment is required to use your Touchscreen Keypad:  A router supporting 2.4 GHz Wi-Fi network. The hub should be connected to this router with access to internet. 2.2. Setup To set up your Touchscreen Keypad for accessing hub: Step 1.
  • Page 5 <NOTE>  The Touchscreen Keypad is compatible with Climax Video Door Phone and IP Camera. Up to 6 IP Cameras and VDPs are supported. Ensure to update device and panel firmware to the latest version for compatibility.

  • Page 6: Hardware Installation

    2.3. Hardware Installation 2.3.1 Installation Instructions There are two mounting options available for installing the Touchscreen Keypad. Users can choose to install their device anywhere in their home or office to suit their needs. Moreover, a wall mounting bracket is also provided to enhance installation flexibility for uses to install the Touchscreen Keypad at a particular place.
  • Page 7 Step 2. Place the Touchscreen Keypad at desired location. Wall Mounting A wall mounting bracket is also included for users to place their Touchscreen Keypad at a fixed place when not in use. Please follow steps below: Step 1. Use the three mounting holes on the bracket as template to drill holes. Step 2.
  • Page 8 Step 5. Hold the Touchscreen Keypad and gently push downwards until you hear a “click” sound.

  • Page 9: Low Battery Notification

    2.4. Low Battery Notification When battery is running low, a low battery notification will be displayed to inform you to recharge the battery. Please refer to Power Supply to recharge the Touchscreen Keypad.

  • Page 10: Operation

    3. Operation 3.1. Home  Date & Time: The Home page displays current Date & Time.  Home Widget : The Home Widget list is for you to control or check currents status of the HVAC sensors or devices which have been learned into the system. To set the list: Step 1.
  • Page 11 Step 2. When finishing selecting the devices, tap OK to confirm. Step 3. The devices that you selected are displayed on the widget list. Step 4. Tap the widget that you want to check. When there is a fault or supervision failure, an orange exclamation mark icon will be displayed on the widget.

  • Page 12: Security

    3.2. Security The current system status is displayed on top of the screen.  System Mode: The system mode is indicated by the 3 icons at top. The current system mode will light up. When a user disarms the system, the Touchscreen Keypad will take a photo and the image can be viewed in the Event page.
  • Page 13 3.2.1. Change System Mode  Tap the desired mode icon and enter the PIN code. You will be required to enter one of the Control Panel User PIN Code to confirm the action. Keypad If incorrect PIN Code is entered, the Touchscreen will display error message and arming will be aborted.
  • Page 14  If the system has existing fault events when arming, the Touchscreen Keypad will display fault message. Tap OK to view the fault list. By checking all faults and tapping “Bypass”, the faults are bypassed and the system is armed now.
  • Page 15 3.2.2. Alarm Dashboard When there is an alarm, the Alarm dashboard will be displayed:  Area: It will be indicated that the alarm is occurred in area 1 and/or area 2. When there are alarms in both areas, you can tap the icon to view the alarm list for each area respectively. ...

  • Page 16: Home Automation Devices

    After disarming the system, you can view these events again through the list. Tap the Close icon to close the alarm dashboard and go back to Security page. 3.3. Home Automation Devices Home Automation devices are displayed under different tabs according to following categories: All , Switch, Lock, and HVAC.
  • Page 17  All: All devices are displayed.  Switch: Power Switch and Relay Switch.  Lock: Door Lock.  HVAC: Temperature control related devices, such as Thermostat, and Thermostatic Radiator Valve.  The device list displays device information:  Device Status will be displayed in each device column. ...
  • Page 18  For Thermostat, click the icon to access configuration page:  The current temperature is displayed on the center. The mode set points are displayed on the bar at the bottom. Toggle the bar to increase or decrease the mode set point.
  • Page 19  For Thermostatic Radiator Valve, click the icon to access its configuration page:  The current temperature is displayed on the center. The mode set points are displayed on the bar at the bottom. Toggle the bar to increase or decrease the mode set point.

  • Page 20: Events

    3.4. Events The Event page records all alarm/status event, pictures and video transmitted by the Control Panel. You can view the image or video by tapping the icons.

  • Page 21: Settings

    3.5. Settings Tap on the gear icon on the top-right corner of the screen to access the Settings menu.  Brightness: Change the brightness of the screen by tapping the slider.  Volume: Change the volume of Touchscreen Keypad by tapping the slider. ...
  • Page 22  Display Home Screen: Enable this function to display home screen when Touchscreen Keypad has been idle for 1 minute/3 minutes, or select Never to disable this function.  Screen Saver: Enable this function after Touchscreen Keypad has been idle for 1 minute/5 minutes, or select Never to disable this function.
