Summary of Contents for Jensen CDR5620
- Page 1 CDR5620 6.2” 2 DIN CAPACITIVE TOUCH SCREEN MULTIMEDIA DVD RECEIVER AM-FM-RDS USB/microSD Multimedia Player Front & Rear Camera Inputs INSTALLATION & OWNER’S MANUAL...
-
Page 2: Copyright And Trademark
CDR5620 INFORMATION Copyright and Trademark SD Logo is a trademark of SD-3C, LLC. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG Inc. Other trademarks and trade names are those of their respective owners. All rights reserved. No part of this publication may be reproduced, distributed, or... -
Page 3: Safety Notice
The SAFETY NOTICE is reminder to drive responsibly and safely while using your mobile phone device, or any APP’s that are compatible with this unit. it is highly recommended that your JENSEN CDR5620 is installed by a professional installer or an authorized dealer. -
Page 4: Installation
CDR5620 INSTALLATION Preparation Please read and understand entire manual before installation. Consult a qualified technician for detailed instructions or installation assistance. Before You Start • Disconnect negative battery terminal. • Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it would be subject to dust, dirt or excessive vibration. - Page 5 Using an incorrect fuse could cause damage. The unit uses (1) 15 amp ATO blade-type fuse located on the back of the unit. Front / Rear camera inputs Up to two cameras (not included) can be used. We recommend JENSEN Part # BUCAM200J for front camera and BUCAM300AJ or BUCAM400AJ for rear camera.
- Page 6 STEP 5 STEP 6 Auto Store Presets Pair Bluetooth Select JENSEN BT then enter PASSCODE 0000 on your Device Tips The SETUP WIZARD can be skipped at any time. To rerun the SETUP WIZARD again, long press RESET button with a paperclip for 3...
- Page 7 CDR5620 OPERATION Main Control Locations Press to activate the voice assistant feature. Voice Control Press SRC to access available modes: Radio, Source Menu Bluetooth Phone, Bluetooth Audio, Disc, USB, SD Card, Auxiliary Input, Rear Camera and Settings. Power Press and hold to turn the unit off. Press any button to turn the unit on.
-
Page 8: Main Menu Operation
CDR5620 OPERATION Main Menu Operation Radio Press to access Radio. Media Player Press to access Media Player. BT Handfree Calling Press to access BT handsfree calling. Standby Mode Press to put the unit in standby mode. Press anywhere on the screen to return to the previous mode. -
Page 9: Settings Menu
• Auto Answer - Turn auto answer feature on or off. • PIN - Change the Bluetooth PIN (default is OOOO). • Name - Displays the device name (JENSEN BT). Display: • Illumination Trigger - Turn the illumination trigger On or Off. -
Page 10: Tuner Operation
CDR5620 OPERATION Tuner Operation Main Menu Press to return to the main menu. Preset Stations Press any preset button to play the corresponding preset station. Press and hold to save the current station as a preset. AM Bands Press to select between 2 AM bands. - Page 11 CDR5620 OPERATION Tuner Operation Press automatically seek the last strong station. Press Tune Down and hold to enter manual tuning mode, then press to tune down one step at a time. Displays the current station number. Station Number Press automatically seek the next strong station. Press...
-
Page 12: Media Player Operation
CDR5620 OPERATION Media Player Operation Media Player To play audio files from a disc, USB device or microSD card, insert disc or device and playback will begin automatically. To return to disc, USB or microSD card playback from another mode of operation, select the corresponding icon from the Main Menu. - Page 13 CDR5620 OPERATION Media Player Operation Tune Down / Press to return to the beginning of the current track. Fast Reverse Press again to return to the previous track. Press and hold to fast reverse the current track. Play/Pause Press to pause playback. Press again to resume.
-
Page 14: Media Compatibility
CDR5620 OPERATION Media Compatibility File Type FAT 12 File System FAT 16/FAT 32 .mp3/.MP3/.Mp3/.mP3 File Extension .rmp/.m4a MPEG 1 MPEG MPEG 2 Format MPEG 2.5 MPEG 1 32/44.1/48kHz Sampling MPEG 2 12/16/22.05/24kHz Frequency MPEG 2.5 8/11.025/12kHz... -
Page 15: Bluetooth - Handsfree Operation
Pairing a New Device Complete the pairing sequence from your Bluetooth device. The unit name is “JENSEN BT”. The Bluetooth passcode is “0000”. The unit can be in any mode of operation when pairing is performed. On certain phones, pairing may need to be done more than once. - Page 16 CDR5620 OPERATION Media Player - USB Use the following options during a phone call: Calling Options Press to end a phone call. End call Press to transfer call audio between head unit and mobile Transfer audio phone. Press to mute the microphone during a call.
-
Page 17: Rear Camera
CDR5620 OPERATION Rear Camera Connect an optional rear camera to the Rear Camera inputs (Yellow RCA connector for video and Black RCA connector for audio). Refer to the wiring diagram for details. Manual selection - Touch the Camera icon from the Main Menu. Touch the camera icon on the top left area on the screen to exit camera mode. -
Page 18: Steering Wheel Controls
CDR5620 OPTIONS Steering Wheel Controls A third-party adapter must be used in order for the CDR5620 to be compatible with any OEM steering wheel controls. The CDR5620 has a built-in 3.5mm SWC interface that compatible with many popular 3rd party SWC control modules, such as PAC, METRA, and others. -
Page 19: Limited One Year Warranty
Who is covered? This warranty is extended to the original retail purchaser for products purchased from an authorized Jensen dealer and used in the U.S.A. What is covered? This warranty covers all defects in material and workmanship in this product. The... -
Page 20: Troubleshooting
Please keep your original sales receipt and be prepared to provide this receipt in the event you require service, as your original receipt is considered the best proof of purchase and indicates the date you purchased your JENSEN product. Dealer Info Dealer Name:... -
Page 21: Specifications
CDR5620 GENERAL Specifications FM Tuner US Tuning Range: 87.5MHz-107.9MHz EU Tuning Range: 87.50MHz-108.00MHz Usable Sensitivity: 8.5dBf 50dB Quieting Sensitivity: 10dBf Stereo Separation@ 1kHz: 30dB Frequency Response: 30Hz-13kHz AM Tuner Tuning Range: 530kHz-1710kHz Usable Sensitivity: <42dBu Frequency Response: 30Hz-2.2kHz Bluetooth Version: 4.1 + EDR... - Page 22 CDR5620 INSTALLATION & OWNER’S MANUAL Customer Support 1-888-921-4088 (Monday-Friday, 9AM-5PM EST) Visit https://www.jensenmobile.com Designed and Engineered in USA All rights reserved. No part of this publication may be reproduced, distributed, or transmitted in any form or by any means, including photocopying, recording, or other electronic or mechanical methods, without the prior written permission of NAMSUNG AMERICA INC.
