Installation Instructions
Parts List
|
2
x screws No. 19
Fitting Kit
|
1
x uriLOCK 0.3L
1
x uriCLEAN 0.5 L
Note
|
Installation of the uridan waterless urinal is very
simple.
If you are retrofitting existing flushing urinals with uridan
waterless urinals, please ensure that the sewer line is jetted
and clean of uric scale before installation. Please also remove
any existing s-trap to avoid double trapping the urinal.
The uridan urinals work without water, and must be fitted to
a 50mm waste pipe. Installation should be carried out by
authorized plumbers in accordance with AZ/NZS3500.2.
PLEASE NOTE: The undiluted discharge from a waterless
urinal must not be transported through copper or copper
alloy pipework.
KHC-10 Installation Instructions – May 2020
1
x fitting No. 15
2
1
x uriCLOTH
x screws fitting No. 15
1
x Cover
www.uridanaustralia.com.au
1
x 87° bend
1
x suction device
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for URIDAN SUMS+
Summary of Contents for URIDAN SUMS+
- Page 1 Please also remove any existing s-trap to avoid double trapping the urinal. The uridan urinals work without water, and must be fitted to a 50mm waste pipe. Installation should be carried out by authorized plumbers in accordance with AZ/NZS3500.2.
- Page 2 Pour 1 bottle uriLOCK ( 0.3 liter) over the cover. Seal the gap between the wall and the urinal with silicone. The uridan urinal is now ready for use! Please leave customer care booklet, cleaning and maintenance instructions, cleaning spray, cleaning cloth and suction device with customer.
