REaD ThIS fIRST! The Serpent SRX2 Gen3 is a state of the art 1/10 scale 2wd buggy which will give you the true Serpent - This is a highly technical hobby product, intended to be used in a safe racing environment. This car racing experience.
Page 3
hOW TO USE ThE maNUal lINES DESCRIpTION ICONS DESCRIpTION Each step contains a variety of numbers, lines, and symbols. The numbers represent the order in Each step contains a variety of symbols described below. which the parts should be assembled. The lines are described below. Step number;...
Page 6
STEp 6 STEp 7 baG 2 1- Check how many teeth your servo M3x10 spline has (23, 24 or 25) and use the right lever. 2- Make sure to put the servo M3x10 M3x8 in neutral before mounting 3.2x7x0.5 the lever. M3x12 3x5x1 STEERING LINK LENGTH...
fRONT aSSEmbly STEp 8 STEp 9 baG 3 Place the caster shims and the bushings M3x10 in the steering block first. Then slide the assembly onto the casterblock. M3x16 M3x12 M3x8 M3x16 M3x4 5x13x4 5x10x4 M3x12 STEERING ARMS CHART STEERINGBLOCK ASSEMBLY MORE LESS ACKERMANN ACKERMANN M3x14...
Page 8
STEp 10 STEp 11 baG 4 3x24 M2.3x4 M3x6 CASTER BLOCK INSERTS CHART Front default caster angle is 25º using the 0º default insert. - Caster You can add or remove caster 3x33 M3x3 using the different inserts 3x33 included in the kit. M3x3 It is possible to adjust the caster angle from 20º...
Page 9
STEp 12 12.1 12.2 CAMBERLINK OUTER DEFAULT POSITION 18.65mm FRONT CAMBERLINK LENGTH 16.65mm 25 mm 3X6X1 3X6X1 CAMBERLINK INNER BALLSTUD LENGTH DEFAULT POSITION 18.65mm 16.65mm 3x6x1...
DIff aSSEmbly STEp 20 STEp 21 baG 6 1.5x8 20.1 21.1 21.2 21.3 Fill only as seen in the image 1.5x8 20.2 PIN INSTALLATION Please insert o-ring in the crown groove first 1.5x8...
Page 16
STEp 22 STEp 23 22.1 22.2 M2x10 Finish filling to the brim M2x10...
REaR SUSpENSION aSSEmbly STEp 24 STEp 25 baG 7 SUSPENSION INSERTS Please find qty. 2 Centered Inserts. These 0 inserts are the default setup and should be installed into this RR FR Toe block. Additional information can be found on page 20, for how you can use the inserts to adjust toe-in, an- ti-squat, and pivot width.
REaR aSSEmbly STEp 28 baG 8 REAR AXLE HEIGHT AND OFFSET INSERTS Wide Offset Narrow 10x15x4 0.5mm 0.5mm 5x13x4 1.5mm 1.5mm 2x10 2x10 M2x5 2.5mm 2.5mm REAR WHEEL-AXLE PIN FOR DRIVESHAFT POSITION The axle has 3 pivoting 1) The axle height adjustment will give you the ability to adjust the roll choices.
Page 20
STEp 29 STEp 30 baG 9 Notice, the uprights are symmetrical, but the 3x6x1 camber link mount has to have the proper orientation for Left and Right. Please check below the proper orientation. 3x6x0.5 FRONT LEFT RIGHT 3x6x1 3x6x0.5 REAR 3x33 M3x12 M2.3x4...
Page 21
STEp 31 SUSPENSION INSERTS Below is a diagram of every possible orientation of the compete 7 inserts system. You are able to move 0.5 or 1 degree in any direction from center. We also have 2 special inserts to fill 0.5° left and right offset, by 1°...
Page 23
STEp 33 32.3 33.1 33.2 18.65mm 14.65mm M3x14 3x6x1 3x6x0.5 REAR CAMBERLINK LENGTH 27.9 mm C A M B E R L I N K CAMBERLINK INNER OUTER DEFAULT DEFAULT POSITION BALLSTUD LENGTH POSITION 18.65mm 14.65mm M3x14 3x6x0.5 3x6x1...
Page 24
STEp 34 M3x25 M3x12 M3x25 M3x22 FRONT SHOCKS DEFAULT POSITION M3x12 M3x25 M3x22...
ShOCkS aSEmbly STEp 35 STEp 36 baG 10 fR ShOCkS / baG 11 RR ShOCkS 35.1 36.1 Note the correct orientation of the Use some silicone oil 2.5x6x0.5 shock spacers . during the assembly. Nut M2 For the correct piston holes and size please check the default setupsheet.
Page 26
STEp 37 STEp 38 37.1 37.2 SHOCKS LENGTH: Measure the Assemble the spring and spring- cup (align correctly) to complete shock length fully extended. 1-Bleed: push the shock- 1- Fill up with sillicone oil the shock. FRONT REAR rod all the way in slowly, fully using the silicone to allow excessive oil to oil supplied in the kit.
Page 27
STEp 39 STEp 40 baG 12 M3 Plastic Do not overtighten and Do not overtighten and M3 Plastic smash bushing with the smash bushing with the Nut Flanged Nut Flanged nut and note orientation of nut and note orientation of the lower shock pivot ball.
fINal aSSEmbly STEp 41 Pinion is not included in the kit. Assemble 3.2x7x0.5 the proper pinion for your set-up. M3x8 M3x8 3.2x7x0.5...
Page 29
STEp 42 Provided in the kit are long and short battery posts. The long posts are to be used with Standard size batteries. The short posts are to be used with Low profile/ Thin batteries. M3x16 M3x12 M3x16 M3x12...
Page 30
STEp 43 Use double sided tape to mount the ESC and RX to the chassis.
Page 31
STEp 44 M3x8 The set screws are included in kit. If you want to reduce chassis twist, use the set screws to key into Included in this kit is Qty.1 thick foam pad the battery strap. and Qty.2 medium pads. The default battery position is to have the battery mounted most rearward against the transmission brace..
Page 32
STEp 45 baG 13 M3x12 ANGLED WING SPACERS CHART 0º 2º 4º 6º 8º FRONT REAR M3x12...
Page 33
Follow the cleaning & painting instructions supplied by the polycarbonate paint supplier you choose. 3- Apply the Serpent and SRX2-Gen3 logo-decals on the body and wing. 1- Rims included in the kit. 2- Rubber tyres not included in the kit.
Page 34
DIff aSSEmbly REaR SUSpENSION aSSEmbly REaR aSSEmbly ShOCk aSSEmbly fINal aSSEmbly WING INSTallaTION bODy INSTallaTION DIffERENTIal EXplODED VIEW CENTRal aND STEERING EXplODED VIEW fRONT EXplODED VIEW TRaNSmISSION EXplODED VIEW REaR EXplODED VIEW ShOCkS EXplODED VIEW fINal EXplODED VIEW TEam SERpENT NETWORk...
