Summary of Contents for Serpent S100

  • Page 2 Serpent enters the competitive electric 1/10th scale pan car In certain assembly steps you need to make basic market with the S100 World GT, which like all our previous adjustments, which will give you a good initial setup for your cars, has been designed to win straight from the box.
  • Page 3 The printed instruction manual included with your From the Serpent S100 product page you will find Serpent kit is very complete, though due to continuous the very latest information about your Serpent S100: product development, more up-to-date information may reports by team drivers and other experts, tips and be provided at our Serpent.com website.
  • Page 4 Step number; the order in which you should assemble the indicated parts Length after assembly / Gap between two items Assembly path of one item into another Group of items (within lines) should be assembled first Direction the item should be moved Glue one item to another Press/Insert one item into another Connect one item to another...
  • Page 6 CA Glue To prevent the risk of the carbon fi bre splitting in the event of a crash you should apply CA Glue around the chassis’ edge and battery slots as shown in red below. Page...
  • Page 7 Page M3x12...
  • Page 8 M2.2x12 M2.2x12 Page...
  • Page 9 M3x8 M3x8 M3x8 M3x8 Page...
  • Page 10 M3x8 M3x8 M3x8 M3x8 M3x8 M3x8 Page...
  • Page 11 M3x3 M3x6 M3x3 M3x3 Page Silicone Grease...
  • Page 12 M2.2x6 Don’t tighten the screws yet M3x10 Page M3x10...
  • Page 13 M2.5x8 M2.5x8 M2.5x8 M2.5x8 M3x6 M3x6 M3x6 M3x6 Page...
  • Page 14 4.5mm M3x8 M3x8 Page Thread lock...
  • Page 15 M3x5 Page...
  • Page 16 Adjust movement and play with these screws M2x6 Tighten these screws M2x6 after assembling the links M3x5 M3x5 M2x6 M2x6 M3x5 M3x5 Adjust movement and play with these screws Page...
  • Page 17 Massage some shock oil into Unscrew the bottom half of the shock sponge before the pre-assembled shock re-assembling the shock absorbers. absorber. FOR BOTH SHOCKS With the shock body filled with oil, slowly screw the end of the shock back onto the shock body. IMPORTANT! FILLING Do not cross thread!
  • Page 18 M3x5 M3x5 M3x5 M3x5 Page...
  • Page 19 M3x6 M3x6 M3x6 M3x10 M3x10 M3x6 M3x6 Page...
  • Page 20 orientation-conical-springs Page...
  • Page 21 Note Insert orientation M3x8 Page Ride Height of 3.5mm...
  • Page 22 M3x8 M3x5 M3x8 M3x5 Mounting position for 1-S LIPO battery Mounting position for 2-S LIPO battery Page...
  • Page 23 M2.5x8 M3x6 Page...
  • Page 24 M3x5 Page...
  • Page 25 M3x6 NOT INCLUDED M3x8 M3x6 Use the following servo saver insert with these brands of servos. 23 - Sanwa / KO / JR 24 - Hitec 25 - Futaba Page...
  • Page 26 NOT INCLUDED M3x6 M3x6 Page...
  • Page 27 32 mm Page...
  • Page 28 M3x10 Page M3x10...
  • Page 29 M3x10 M3x10 M3x10 Page M3x10...
  • Page 30 Page...
  • Page 31 M3x8 M3x3 Page...
  • Page 34 110104 Page...
  • Page 35 411075 411186 411075 411168 411250 411186 411166 411251 411069 411187 411074 110104 110104 411237 411193 411195 411188 110135 110136 411196 411197 411072 411194 411074 411074 411072 411249 110135 411238 110402 401025 411189 411247 411190 411061 110122 411224 110108 411154 110122 411191 110122 411200...
  • Page 36 Page...
  • Page 37 411040 401025 110137 411239 411007 411121 411040 411239 411120 411040 411023 411243 411242 401025 110109 411040 110115 411154 411023 411243 110109 110128 411241 411154 411061 411240 110402 110122 411241 110100 Page 411143 411077...
  • Page 38 Page...
  • Page 39 1468 Car-stand alu Serpent orange 411245 Decal sheets S100 (2) 110135 Screw allen countersunk M2,5x10 (10) 150001 Tool bag Serpent 411246 Decal sheets S100 chrome (2) 110136 Screw allen countersunk M2,5x8 (10) 411153 Screw allen countersunk M2.2x6mm (10) MERCHANDISING 411154 Screw allen countersunk M3x5mm (10)
  • Page 40 w w w . s e r p e n t . c o m i n f o @ s e r p e n t . c o m...
