INSTRUCTION MANUAL

& REFERENCE GUIDE

Advertisement

loading
Need help?

Need help?

Do you have a question about the S120 LTR and is the answer not in the manual?

Questions and answers

Related Manuals for Serpent S120 LTR

Summary of Contents for Serpent S120 LTR

  • Page 1: Instruction Manual

    INSTRUCTION MANUAL & REFERENCE GUIDE...

  • Page 1: Instruction Manual

    INSTRUCTION MANUAL & REFERENCE GUIDE...
  • Page 2 BALL DIff ASSemBLy ShOCK ASSemBLy CUSTOmeR SeRVICe eLeCTRONICS ASSemBLy Serpent has made a strong effort to make this manual fINAL ASSemBLy as complete and clear as possible. Additional info may Reff GUIDe be published in our website: www.serpent.com or you may ask your dealer or the Serpent distributor for advice, or email Serpent direct: info@serpent.com...
  • Page 2 BALL DIff ASSemBLy ShOCK ASSemBLy CUSTOmeR SeRVICe eLeCTRONICS ASSemBLy Serpent has made a strong effort to make this manual fINAL ASSemBLy as complete and clear as possible. Additional info may Reff GUIDe be published in our website: www.serpent.com or you may ask your dealer or the Serpent distributor for advice, or email Serpent direct: info@serpent.com...

  • Page 3: Using The Manual

    USING THE MANUAL Each step contains a variety of numbers, lines, and symbols. The numbers represent the order in which the parts should be assembled. The lines and symbols are described below. Step number; the order in which you should assemble the indicated parts Length after assembly Assembly path of one item into another...

  • Page 3: Using The Manual

    USING THE MANUAL Each step contains a variety of numbers, lines, and symbols. The numbers represent the order in which the parts should be assembled. The lines and symbols are described below. Step number; the order in which you should assemble the indicated parts Length after assembly Assembly path of one item into another...
  • Page 4 CA Glue STEP To prevent the risk of the carbon fibre splitting in the event of a crash you should apply CA Glue around the chassis’ edge and the power pod plate external and internal edge as shown in red below. FRONT ASSEMBLY Nylock Nut M2.2 STEP...
  • Page 4 CA Glue STEP To prevent the risk of the carbon fibre splitting in the event of a crash you should apply CA Glue around the chassis’ edge and the power pod plate external and internal edge as shown in red below. FRONT ASSEMBLY Nylock Nut M2.2 STEP...
  • Page 5 M3x8 STEP M3x8 M3x8 M3x8 M3x8 3.2 mm STEP M3x3 M3x3 Front suspension brackets up INSIDe OUTSIDe Default setup Page...
  • Page 5 M3x8 STEP M3x8 M3x8 M3x8 M3x8 3.2 mm STEP M3x3 M3x3 Page...
  • Page 6 Steering block King pin inserts Default ackerman STEP position in King pin angle adjustable from 0 to 4 3x5x2 the steering degrees. Note orientation block lever. of the king pin 3x5x4 0º 1º 2º 3º 4º insert. Nylock Nut M3x12 Default setup R2.3 3x5x0.3...
  • Page 6 NOTES: STEP 1) Note orientation king 3x5x2 insert 3x5x4 2) King pin angle adjustable from 0 to 4 degrees. Default 2 degrees. Nylock Nut M3x12 R2.3 3x5x0.3 3x5x1 3x5x2 R2.3 Note corrrect STEP ball type to use here M2.5x5 M2.5x5 M3x5 M3x6 M3x6...

  • Page 7: Rear Assembly

    REAR ASSEMBLY STEP M3x6 M3x6 M3x6 M3x6 M3x6 Nylock Nut STEP Note corrrect ball type to use here NOTE Do no overtight to ensure free rotation of the pivot ball. M3x8 Page...

  • Page 7: Rear Assembly

    REAR ASSEMBLY STEP M3x6 M3x6 M3x6 M3x6 M3x6 Nylock Nut STEP Note corrrect ball type to use here NOTE Do no overtight to ensure free rotation of the pivot ball. M3x8 Page...
  • Page 8 STEP 3x5x0.3 STEP Note corrrect M3x6 ball type to use here M3x5 M3x6 Nylock nut M3 Page...
  • Page 8 STEP 3x5x0.3 STEP Note corrrect M3x6 ball type to use here M3x5 M3x6 Nylock nut M3 Page...
  • Page 9 STEP M2x6 Adjust movement and play with these screws M2x6 M3x5 Note corrrect ball type to use here M3x5 A) OUTSIDE SIDE SPRING CONFIGURATION (DEFAULT) STEP M3x10 Page...
  • Page 9 STEP M2x6 Adjust movement and play with these screws M2x6 M3x5 Note corrrect ball type to use here M3x5 A) OUTSIDE SIDE SPRING CONFIGURATION (DEFAULT) STEP M3x10 Page...
  • Page 10 B) INSIDE SIDE SPRING CONFIGURATION M3x16 STEP 14.1 STEP M3x10 Apply the silicone oil on the inner tube, see CST value in the setup sheet 14.2 Page...
  • Page 10 B) INSIDE SIDE SPRING CONFIGURATION M3x16 STEP 14.1 STEP M3x10 Apply the silicone oil on the inner tube, see CST value in the setup sheet 14.2 Page...
  • Page 11 BALL DIFF ASSEMBLY STEP Note spring washer orientation Apply silicone grease 1/4x3/8 1/4x3/8 1/4x3/8 Flanged 1/4x3/8 Flanged M3X8 STEP 6.5x8x0.25 1/4x3/8 Flanged 6.5x8x0.25 Rear ride height inserts The rear ride height is adjustable in steps of 0.5mm increments using different rear axle bearing adapters.
  • Page 11 BALL DIFF ASSEMBLY Note spring washer orientation STEP Apply silicone grease 1/4x3/8 1/4x3/8 1/4x3/8 Flanged STEP 1/4x3/8 Flanged M3X8 Note insert orientation. For insert number see default setup sheet. 6.5x8x0.25 1/4x3/8 Flanged 6.5x8x0.25 Page...
  • Page 12 17.1 NOTE: Check how many teeth your servo spline has 1) Servo mounts are excentric for ensuring STEP (23, 24 or 25) and use the right inserts. that steering servo could be assembled perfecly centerd. NOT INCLUDeD 3x5x1 M3X5 M3X8 2) Use chassis slot to center the steering servo 17.2...
  • Page 12 17.1 NOTE: Check how many teeth your servo spline has 1) Servo mounts are excentric for ensuring STEP (23, 24 or 25) and use the right inserts. that steering servo could be assembled perfecly centerd. NOT INCLUDeD 3x5x1 M3X5 M3X8 2) Use chassis slot to center the steering servo 17.2...
  • Page 13 18.1 STEP 19.5 mm 18.2 NOTE Note position of the shockball The M3x3 set screw will fix the M3X3 STEP antenna. Do not fully tighten till step 22 after antenna is assembled. M2.5x6 M3X5 M3X6 Page...
  • Page 13 18.1 STEP 19.5 mm 18.2 NOTE Note position of the shockball The M3x3 set screw will fix the M3X3 STEP antenna. Do not fully tighten till step 22 after antenna is assembled. M2.5x6 M3X5 M3X6 Page...
  • Page 14 SHOCK ASSEMBLY 20.1 20.2 20.3 STEP Use some silicone oil NOTE: during assembly For the correct piston check the set-up sheet. 20.4 20.5 M3X10 M3X3 20.7 20.6 Close the shock slowly. Important: crossthread! will overflow through Filling: built-in bleed channel. Fill the shock body with shock absorber oil.
  • Page 14 SHOCK ASSEMBLY 20.1 20.2 20.3 STEP Use some silicone oil NOTE: during assembly For the correct piston check the set-up sheet. 20.4 20.5 M3X10 M3X3 20.7 20.6 Close the shock slowly. Important: crossthread! will overflow through Filling: built-in bleed channel. Fill the shock body with shock absorber oil.
  • Page 15 STEP M3X10 M3X10 M3X10 M3X10 A) LONGITUDINAL BATTERY CONFIGURATION (DEFAULT) STEP NOT INCLUDeD Tip: Use double sided tape to mount the ESC and RX to the chassisplate. NOT INCLUDeD NOTE Tighten the M3x3 set screw assembled in the Step 18 right after assembling the antenna.
  • Page 15 STEP M3X10 M3X10 M3X10 M3X10 A) LONGITUDINAL BATTERY CONFIGURATION (DEFAULT) STEP NOT INCLUDeD Tip: Use double sided tape to mount the ESC and RX to the chassisplate. NOT INCLUDeD NOTE Tighten the M3x3 set screw assembled in the Step 18 right after assembling the antenna.
  • Page 16 Tighten the M3x3 set screw assembled in the Step 18 right after assembling the antenna. A) LONGITUDINAL BATTERY CONFIGURATION (DEFAULT) NOTE S120 LTR desing allows to assemble the STEP battery longitudinal, right or left of the car. Default configuration is longitudinal left. NOT INCLUDeD...
  • Page 16 Tighten the M3x3 set screw assembled in the Step 18 right after assembling the antenna. A) LONGITUDINAL BATTERY CONFIGURATION (DEFAULT) NOTE S120 LTR desing allows to assemble the STEP battery longitudinal, right or left of the car. Default configuration is longitudinal left. NOT INCLUDeD...
  • Page 17 B) TRANSVERSAL BATTERY CONFIGURATION STEP NOT INCLUDeD Nylock Nut Nylock Nut NOTE Use glass-tape (not included) to fix the battery to the chassis. M3X6 M3X6 Detail view longitudinal battery configuration (default) Page...
  • Page 17 B) TRANSVERSAL BATTERY CONFIGURATION STEP NOT INCLUDeD Nylock Nut Nylock Nut NOTE Use glass-tape (not included) to fix the battery to the chassis. M3X6 M3X6 Detail view longitudinal battery configuration (default) Page...

  • Page 18: Final Assembly

    Detail view transversal battery configuration FINAL ASSEMBLY Pinion is NOT STEP INCLUDeD in the kit. Assemble the proper pinion for NOT INCLUDeD your set-up M3X10 Page...

  • Page 18: Final Assembly

    Detail view transversal battery configuration FINAL ASSEMBLY Pinion is NOT STEP INCLUDeD in the kit. Assemble the proper pinion for NOT INCLUDeD your set-up M3X10 Page...
  • Page 19 STEP Body, wheels and tyres are NOT included M3X8 1/8X5/16 Nylock Nut M3 Page...
  • Page 19 STEP Body, wheels and tyres are NOT included M3X8 1/8X5/16 Nylock Nut M3 Page...
  • Page 20 REFERENCE GUIDE Page...
  • Page 20 REFERENCE GUIDE Page...
  • Page 21 FRONT ASSEMBLY 411163 110116 411049 401025 110408 411320 411049 411042 411142 401058 110122 411321 411182 110166 110128 110104 110166 411081 411325 110104 110122 411026 411049 411059 401025 411084 110206 411326 411181 411086 110104 411201 110128 110406 110104 110116 411326 110160 411042 411182 110114...
  • Page 21 FRONT ASSEMBLY 411163 110116 411049 401025 110408 411320 411049 411042 411142 401058 110122 411321 411182 110166 110128 110104 110166 411081 411325 110104 110122 411026 411049 411059 401025 411084 110206 411326 411181 411086 110104 411201 110128 110406 110104 110116 411326 110160 411042 411182 110114...
  • Page 22 BALL DIFF ASSEMBLY 411262 120024 Spur diff gear 64P/86T 120025 Spur diff gear 64P/90T 120026 Spur diff gear 64P/94T 120027 Spur diff gear 64P/98T 411186 120028 Spur diff gear 64P/102T 120029 Spur diff gear 64P/106T 411075 120030 Spur diff gear 64P/110T 411069 411186 411075...
  • Page 22 BALL DIFF ASSEMBLY 411262 120024 Spur diff gear 64P/86T 120025 Spur diff gear 64P/90T 120026 Spur diff gear 64P/94T 120027 Spur diff gear 64P/98T 411186 120028 Spur diff gear 64P/102T 120029 Spur diff gear 64P/106T 411075 120030 Spur diff gear 64P/110T 411069 411186 411075...
  • Page 23 SHOCK ABSORBER ASSEMBLY 411207 411020 411165 411045 411141 411044 411097 411140 411162 411057 411041 411203 411046 411162 411019 110154 411214 Center spring 12lbs S120L 411215 Center spring 14lbs S120L 411207 411216 Center spring 16lbs S120L 411217 Center spring 18lbs S120L Please click here to check all the Optional Parts FINAL ASSEMBLY 411040...
  • Page 23 SHOCK ABSORBER ASSEMBLY 411207 411020 411165 411045 411141 411044 411097 411140 411162 411057 411041 411203 411046 411162 411019 110154 411214 Center spring 12lbs S120L 411215 Center spring 14lbs S120L 411207 411216 Center spring 16lbs S120L 411217 Center spring 18lbs S120L Please click here to check all the Optional Parts FINAL ASSEMBLY 411040...
  • Page 24 - info@serpent.com...
  • Page 24 TEAM SERPENT NETWORK S120 lTR SPARE PARTS S120 lTR OPTiONAl PARTS SERPENT TOOlS SERPENT MERCHANdiSiNg WEbSiTE ANd blOg SOCiAl MEdiA Page...
