- Page 1 PRO-MUX-1 Configuration Guide How To Configure the PRO-MUX-1 Multiplexer Page 1...
- Page 2 The Actisense PRO-MUX-1 is a very powerful multiplexer / router, capable of filtering, advanced filtering, directing sentences to specific connected listeners, and auto bauding. With this guide, the user will be able to better understand the power and capability of the PRO-MUX-1 within an NMEA 0183 network.
- Page 3 ‘friendly name’ can be given to each port. There are two routes that can be taken here for talker devices connected to the inputs: 1. The device is left on the autobaud configuration, meaning that the PRO-MUX-1 will adjust the (Au- baud rate on each input port dependant on the baud rate of the talker device connected to it.
- Page 4 • Autoswitch: PRO-MUX-1 will Autoswitch (if enabled) between one or more inputs, and will output the following message if Autoswitch is performed: $MXALR,hhmmss,004,PRO-MUX-1|206221|Autoswitch • Data Overload: PRO-MUX-1 will determine if too much data is being sent at one time to a port, and will output the following message if enabled: $MXALR,hhmmss,002,PRO-MUX-1|206221|Combine: Data overload •...
- Page 5 PRO-MUX-1 Configuration Guide Basic Routing Basic routing functions on the PRO-MUX are designed to give the user control over which Outputs receive sentences from the Inputs. The purpose of routing is to essentially dismiss messages that are not required for certain devices. This is better explained in the example below, where the fol- lowing has been configured: IN 1 sentences from GPS 1 are only going to OUT 2.
- Page 6 PRO-MUX-1 Configuration Guide Autoswitch Configuration Autoswitching is a function where the device determines if the data on the Input is present and will switch to another user determined Input if it is not. By selecting the tick box for ASW 1 or/and ASW 2, it enables the Autoswitch function on the de- vice, and by selecting the ‘Config’...
