ST5/11/30/50HPT User Manual
Contents
I. Disclaimer...............................................................................................................................................................................2nd
II. Precautions for integration................................................................................................................................................... 2nd
III. List of in-box items................................................................................................................................................................3rd
IV. Interface................................................................................................................................................................................ 4th
V. Precautions When Powering On............................................................................................................................................4th
VII. Antenna Installation............................................................................................................................................................ 7th
1. Multi-rotor UAV............................................................................................................................................................. 7th
2. Fixed Wing UAV..............................................................................................................................................................7th
VIII. Software Operation............................................................................................................................................................ 8th
1. Start Connecting Tdd-cofdm equipment....................................................................................................................... 8th
2. Restart TDD-COFDM Control Panel software.............................................................................................................8th
3. RF Configuration method.......................................................................................................................................... 8th
3. 1. TX Rate..............................................................................................................................................................8th
3.2. Channel Bandwidth............................................................................................................................................ 9th
3.3. Channel-Frequency.............................................................................................................................................9th
3.4. Wireless Distance............................................................................................................................................... 9th
3.5. RX TX Mode:...................................................................................................................................................10th
3.6. TX Power..........................................................................................................................................................10th
4. Seria Configuration method:....................................................................................................................................... 10th
4.1. Data Baud Rate.................................................................................................................................................10th
4.2. Data Format...................................................................................................................................................... 11th
4.3. IP Protocol Config............................................................................................................................................ 11th
5. RS232 Configuration Menu.........................................................................................................................................11th
6. IP New Network Configuration method:.................................................................................................................... 12th
7. RF New NET Configuration method.......................................................................................................................... 12th
7.1. RF Net ID:........................................................................................................................................................ 12th
7.2. RF Encrypt KEY ............................................................................................................................................ 12th
SUNTOR ELECTRONICS CO., LIMITED
1st
V1.0
Advertisement
Table of Contents
Related Manuals for Suntor ST5HPT
Summary of Contents for Suntor ST5HPT
-
Page 1: Table Of Contents
4.2. Data Format..............................11th 4.3. IP Protocol Config............................11th 5. RS232 Configuration Menu............................11th 6. IP New Network Configuration method:........................12th 7. RF New NET Configuration method.......................... 12th 7.1. RF Net ID:................................ 12th 7.2. RF Encrypt KEY ............................12th SUNTOR ELECTRONICS CO., LIMITED V1.0... -
Page 2: Disclaimer
It is recommended to use the functions of SUNTOR product, i.e. image transmission and RS232 two-way serial port communication to minimize the quantity of onboard radio devices. -
Page 3: List Of In-Box Items
8. The HDMI cable and antenna may cause interference to GPS. They should be kept far away from the GPS module and its cables as much as possible in the wiring process. Do not disassemble or modify SUNTOR ST5/11/30HPT. Any problem during installation, contact SUNTOR or the sales agent. -
Page 4: Interface
TPalyer Key USB 2.0 Key Interface Remark: The TX and RX have same interface specifications, All references are given above. V. Precautions When Powering On 1. Before using, make sure that all cables are secure and reliably and all components can work properly. 2. -
Page 5: Operating Instructions & Steps
3. Check the surrounding environment for to ensure there is no other 2.4GHz devices to cause interference. If use the Futaba remote controller, the controller should be adjusted into the French mode. Otherwise, the video transmission performance of ST5/11/30HPT may be serious affected and also the Futaba transceiver may be in the abnormal status and accidents may be caused. - Page 6 2. Connection 3. Power on After checking all the connections are in good condition, turn on the the video source, LCD display, transmitter and receiver. The PWR indicator will bright and the whole system start. 4. The status of all indicators during starting When the device begin to normally start and work, status is described as follow: all indicators...
-
Page 7: Antenna Installation
1. Multi-rotor UAV 1) To select the original antenna and the SMA metal shielded semi-flexible blue feeder cable provided by SUNTOR. The feeder cable is used to connect the TX SMA port and the antenna. SMA Feeder Cable 2) The antenna needs to be mounted vertically downwards, and it is not recommended to mount it vertically at the top of the UAV. -
Page 8: Software Operation
vertically at the top of the UAV. 3) It is recommended to use 29cm long antenna. The best installation position is the center of the UAV tail, prominent outside the body and vertical downward. The second optional mounting position is located below the wing and body joints, vertical down, as far as possible away from the wing but near the machine abdomen, protruding below the abdomen level. -
Page 9: Channel Bandwidth
performance. For example, for a link (8MHz channel) with a signal strength of at least –75dBm, a TX rate of 16-QAM 3/4 FEC is recommended. Setting to the highest rate with a poor link may result in reduced performance. 3.2. Channel Bandwidth （Default：4Mhz）: Select the channel bandwidth from the list. -
Page 10: Rx Tx Mode
3.5. RX TX Mode: TX Master - A Master may provide a wireless data connection to many slaves RX Slave- A Salve may sustain one wireless connection,i.e. to an Master. 3.6. TX Power （Default：30dbm）: This setting establishes the transmit power level which will be presented to the antenna connector of the TDD_COFDM.Unless required, the Tx Power should be set not for maximum, but rather for the minimum value required to maintain an adequate system fade margin. -
Page 11: Data Format
4.2. Data Format （Default：8N1）: This setting determines the format of the data on the serial port. The default is 8 data bits, No parity, and 1 Stop bit. （Default：UDP Point to Point）: 4.3. IP Protocol Config This setting determines which protocol the serial server will use to transmit serial port data over the TDD-COFDM network.The protocol selected in the IP Protocol Config field will determine which configuration options appear in the remainder of 5. -
Page 12: Ip New Network Configuration Method
6. IP New Network Configuration method: This setting helps you to change the IP address of devices .The default of master’s IP address is 192.168.55.1,the default of slaver’s IP address is 192.168.55.2. For example,you want to change the master’s IP address to “192.168.55”. Then do as the following steps.
