ST5/10/20NPT User Manual
Contents
I. Disclaimer...............................................................................................................................................................................
II. Interface................................................................................................................................................................................
1. Indicator........................................................................................................................................................................
III. Precautions for integration...................................................................................................................................................
IV. Precautions When Powering On...........................................................................................................................................4th
V. List of in-box items................................................................................................................................................................. 5th
VI. Setup..................................................................................................................................................................................... 5th
1. Set the IP Address.......................................................................................................................................................... 5th
2. Set Serial Port Configuration......................................................................................................................................... 6th
VII. Antenna Installation............................................................................................................................................................ 7th
1. Multi-rotor UAV............................................................................................................................................................. 7th
2. Fixed Wing UAV..............................................................................................................................................................7th
VIII. Software Operation............................................................................................................................................................ 8th
1. Start Connecting Tdd-cofdm equipment....................................................................................................................... 8th
2. Restart TDD-COFDM Control Panel software.............................................................................................................8th
3. RF Configuration method.......................................................................................................................................... 8th
3. 1. TX Rate..............................................................................................................................................................9th
3.2. Channel Bandwidth............................................................................................................................................ 9th
3.3. Channel-Frequency.............................................................................................................................................9th
3.4. Wireless Distance............................................................................................................................................... 9th
3.5. RX TX Mode:.....................................................................................................................................................9th
3.6. TX Power..........................................................................................................................................................10th
4. Seria Configuration method:....................................................................................................................................... 10th
4.1. Data Baud Rate.................................................................................................................................................10th
4.2. Data Format...................................................................................................................................................... 10th
4.3. IP Protocol Config............................................................................................................................................ 11th
5. RS232 Configuration Menu.........................................................................................................................................11th
6. IP New Network Configuration method:.................................................................................................................... 12th
7. RF New NET Configuration method.......................................................................................................................... 12th
7.1. RF Net ID:........................................................................................................................................................ 12th
7.2. RF Encrypt KEY ............................................................................................................................................. 12th
SUNTOR ELECTRONICS CO., LIMITED
1st
V1.0
Advertisement
Table of Contents
Related Manuals for Suntor ST5NPT
Summary of Contents for Suntor ST5NPT
-
Page 1: Table Of Contents
4.2. Data Format..............................10th 4.3. IP Protocol Config............................11th 5. RS232 Configuration Menu............................11th 6. IP New Network Configuration method:........................12th 7. RF New NET Configuration method.......................... 12th 7.1. RF Net ID:................................ 12th 7.2. RF Encrypt KEY ............................. 12th SUNTOR ELECTRONICS CO., LIMITED V1.0... -
Page 2: Disclaimer
I. Disclaimer SUNTOR is the registered trademark of SUNTOR ELECTRONICS CO., LIMITED. All product names and brands in this manual are trademarks or registered trademarks of the Company. SUNTOR ELECTRONICS CO., LIMITED. reserves all copyrights of the product and the manual. All the information must not be copied or reproduced in any form without permission of the Company. -
Page 3: Precautions For Integration
It is recommended to use the functions of SUNTOR product, i.e. image transmission and RS232 two-way serial port communication to minimize the quantity of onboard radio devices. -
Page 4: Precautions When Powering On
IV. Precautions When Powering On 8. Before using, make sure that all cables are secure and reliably and all components can work properly. 9. After starting the product, check it for proper operation by observing whether the self-test indicator of ST5/10/20NPT is continuously ON for 30s and then flicker and whether the image of the camera is shown on the ground terminal. -
Page 5: List Of In-Box Items
V. List of in-box items On board x1 Ground terminal x1 On board antenna x1 Ground antenna x1 4P-to-DC power cable x1 DC to DC power cable x2 Network cable x4 Serial port cable x1 (Length: 20cm) Serial port cable x1 (Length: 1500cm) USB cable of serial port 2 x1 VI. -
Page 6: Set Serial Port Configuration
Start T-config.exe by window→ LAN Configuration→Connection Type→Static IP(Input IP Address, Subnet Mask, Default Gateway)→OK 2. Set Serial Port Configuration Note: The following configuration is factory settings, you can modify according to your own needs. Factory Settings Port status: Data Data Baud Rate: 115200 Data Format: Data Mode:... -
Page 7: Antenna Installation
1. Multi-rotor UAV 1) To select the original antenna and the SMA metal shielded semi-flexible blue feeder cable provided by SUNTOR. The feeder cable is used to connect the TX SMA port and the antenna. SMA Feeder Cable 2) The antenna needs to be mounted vertically downwards, and it is not recommended to mount it vertically at the top of the UAV. -
Page 8: Software Operation
1) To select the original antenna and the SMA metal shielded semi-flexible blue feeder cable provided by SUNTOR. The feeder cable is used to connect the TX SMA port and the antenna. 2) The antenna needs to be mounted vertically downwards, and it is not recommended to mount it vertically at the top of the UAV. -
Page 9: Tx Rate
3. 1. TX Rate（Default：QPSK FEC 1/2）: This setting determines the modulation type and in turn the rate at which the data is to be wirelessly transferred. The default and recommended setting for both Master and Slave units is ‘Auto’. When in ‘Auto’ the unit will transfer data at the highest possible rate in consideration of the receive signal strength (RSSI). -
Page 10: Rx Tx Mode
3.5. RX TX Mode: TX Master - A Master may provide a wireless data connection to many slaves RX Slave- A Salve may sustain one wireless connection,i.e. to an Master. 3.6. TX Power （Default：30dbm）: This setting establishes the transmit power level which will be presented to the antenna connector of the TDD_COFDM.Unless required, the Tx Power should be set not for maximum, but rather for the minimum value required to maintain an adequate system fade margin. -
Page 11: Data Format
4.2. Data Format （Default：8N1）: This setting determines the format of the data on the serial port. The default is 8 data bits, No parity, and 1 Stop bit. （Default：UDP Point to Point）: 4.3. IP Protocol Config This setting determines which protocol the serial server will use to transmit serial port data over the TDD-COFDM network.The protocol selected in the IP Protocol Config field will determine which configuration options appear in the remainder of 5. -
Page 12: Ip New Network Configuration Method
6. IP New Network Configuration method: This setting helps you to change the IP address of devices .The default of master’s IP address is 192.168.55.1,the default of slaver’s IP address is 192.168.55.2. For example,you want to change the master’s IP address to “192.168.55”. Then do as the following steps.
