Sukup Cyclone Installation & Operation Manual

Pneumatic grain moving system with plc, dynamic bleed valve & optional vfd

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

With PLC, Dynamic Bleed Valve & Optional VFD

Installation & Operation Manual

ATE

07/13/2023 – Updated warranty ---------------------------------------------------------------------------------------------------- 3

Updated warning on avoiding unload equipment ------------------------------------------------------------- 4

Updated instructions for adjusting current sensing settings --------------------------------------------- 25

Added deadhead & cyclone installation instructions ------------------------------------------------ 28 & 29

Updated enclosure box part number for electrical panel N343120 ------------------------------------ 54

Updated/added deadhead drawings & parts lists ------------------------------------------------------ 68-73

05/10/2023 – Updated VFD settings table & electrical requirements table ------------------------------------- 25 & 54

Updated Contact Information page & added QR code for product registration --------------------- 80

02/10/2023 – Added instructions for connecting airlock to dryer --------------------------------------------------------- 16

Updated instructions for mounting main power box & touch screen controller ------------------ 19-21

Updated dynamic bleed valve installation instructions ------------------------------------------------ 22-23

Updated VFD wiring instructions for 3-phase systems ---------------------------------------------------- 24

Updated PLC overview drawing -------------------------------------------------------------------------------- 42

Added instructions for wire 31 if using Mitsubishi VFD --------------------------------------------------- 45

Added instructions for monitoring Mitsubishi F800 inverter status ------------------------------------- 53

09/21/2022 – Eliminated references throughout to discontinued two-motor drive units & 4" units

Updated statements on tightening wires & minimizing electromagnetic interference ------------- 10

Added Mitsubishi VFD settings --------------------------------------------------------------------------------- 25

Added troubleshooting guidance ------------------------------------------------------------------------------- 33

Updated references to Altivar 320 & 630 programming manuals ---------------------------------- 50-51

Updated Altivar 320 & Mitsubishi F800 programming instructions ------------------------------ 50 & 52

Manual L1396

07/13/2023

5" & 6" Systems

Sukup Manufacturing Co.

1555 255th Street, Box 677

Sheffield, Iowa, USA 50475-0677

Phone: 641-892-4222

Website: www.sukup.com

Fax: 641-892-4629

E-mail: info@sukup.com

EVISION

AGE

Table of Contents

Need help?

Do you have a question about the Cyclone and is the answer not in the manual?

Questions and answers

Summary of Contents for Sukup Cyclone

Page 1 Updated warning on avoiding unload equipment ------------------------------------------------------------- 4 Updated instructions for adjusting current sensing settings --------------------------------------------- 25 Added deadhead & cyclone installation instructions ------------------------------------------------ 28 & 29 Updated enclosure box part number for electrical panel N343120 ------------------------------------ 54 Updated/added deadhead drawings & parts lists ------------------------------------------------------ 68-73 05/10/2023 –...
Page 2: Table Of Contents
Report any damage or shortage to delivery carrier as soon as possible. Sukup Manufacturing Co.’s responsibility for damage to equipment ended with acceptance by delivery carrier. Refer to bill of lading. Save all paperwork and documentation furnished with the stir delay system.
Page 3: Limited Warranty
Limited Warranty...
Page 4: Safety
Safety decals must be kept in good condition. Replace missing or damaged safety decals by contacting Sukup Manufacturing Co. via mail at PO Box 677, Sheffield, Iowa USA, 50475; by phone at 641-892-4222; or by e-mail at info@sukup.com. It is the responsibility of the owner/operator to know what specific requirements, precautions, and work hazards exist.
Page 5 Safety To avoid electric shock or electrocution, all WARNING: Metal is slippery when wet. To equipment must be properly wired and grounded avoid falls, never carry items if climbing on bin. according to electrical codes. Have Maintain secure hand and foothold if climbing unit wired by qualified electrician.
Page 6 Safety Cyclone Safety Decal Placement Cyclone safety decals are mounted at the factory. 3. Decal L0284 – WARNING: Keep Away From All Yearly and prior to equipment use, ensure that all Moving Parts. decals and shields are in legible condition and in Decal is mounted on the shield.
Page 7 Safety Locations and part numbers of Sukup safety decals listed on previous page are shown below. Replacements for damaged decals are available from Sukup. Decals not identified by part number are supplied by airlock manufacturer. L0900 L0271 L0284 L0281 L0900...
Page 8: Dimensions
Dimensions Dimensions Fig. 1 & Table 1 show dimensions of airlock assy., in inches. Fig. 2 & Table 2 show blower. SWAS0015 03/12/2003 JFJ Fig. 1 & Table 1 – Airlock assy. dims. 5” TUBE 6” TUBE 23.2 26.4 25.8 34.7 39.4 31.6...
Page 9 Dimensions Fig. 3 shows dimensions, in inches of seven-valve distributor assy. (N56651B) for 5″ dia. tube. Fig. 3 – Distributor assy., 5” dia. tube 7 OUTLETS SPACED @ 22.5° ON 15” RADIUS N56651B, SHEET 2 OF 2 09/07/2012 JFJ Fig. 4 shows dimensions, in inches of seven-valve distributor assy. (N56661B) for 6″ dia. tube. Fig.
Page 10: Component Identification
Component Identification Power Box Component Identification Image 1 – Power box components (prior to completion of wiring) 1. Terminals 9. Air pressure transducer 2. Secondary side circuit breaker 10. Control transformer 3. Primary side circuit breaker 11. Power distribution block 4.
Page 11 Component Identification Accessory Component Identification Fig. 5 and Table 3 identify accessories commonly used on pneumatic grain moving systems. SWAS0046 03/29/2006 JFJ Fig. 5 & Table 3 – Air system accessories REF. # DESCRIPTION 5″ PART # 6″ PART # Distribution valve, 7-way N56651B N56661B...
Page 12: Pre-Installation Information
Pre-Installation Information Air System Capacities Air system capacities shown in Table 4 are estimates based on tube diameter, motor horsepower and effective length of system. Actual capacity may vary depending on condition of grain (test weight, moisture content, grain temperature, kernel shape, etc.), ambient temperature and humidity, as well as layout of system.
Page 13 Pre-Installation Information Calculating Effective Length of Air System See Fig. 6 to calculate effective length of air system. Fig. 6 – Top and side views of bins and dryer...
Page 14 NOTE: Blower can be placed up to 50 feet away from airlock to minimize noise and provide a clean air source. Blower inlet and filter can also be remotely located to provide clean air. Consult Sukup Manufacturing Co. for distances exceeding 50 feet.
Page 15 Pre-Installation Information Use either a deadhead or a cyclone at end of tubing to drop grain out of air stream. See Fig. 8 to determine roof tube lengths required for installing cyclone or deadhead on storage bin. NOTE: When installing a Sukup cyclone it is important that tube not extend more than 1/2″ on inside. A length in excess of 1/2″...
Page 16: Installation
Installation Airlock Set-Up Remove shipping cover from top of airlock and ensure there is no foreign material in airlock body. Attach adaptor to airlock as shown in Fig. 9 using hardware provided in Kit N5570. Trim 10” diameter tube as needed. Stitch-weld each flange ring to tube with three 1” welds spaced equidistantly. Attach tube to bottom of discharge box using eight 5/16”...
Page 17 Check oil level by using sight glass on end of blower. Add oil as needed (Sukup J3200 – 1 quart; J3201 – 5 gallon). Duroflow blower capacity is 1-3/4 qts. Attach air restriction gauge into threaded hole in blower inlet.
Page 18 Installation 5″ Blower Motor Mounting Positions SWAS0013 03/12/2003 JFJ Fig. 11 6″ Blower Motor Mounting Positions Fig. 12 SWAS0020 03/14/2003 JFJ...
Page 19 Installation Main Power Box Installation Attach main power box to a sturdy stand. Use mounting studs on back of box and C-channels (not provided). Figs. 13-15 show dimensions of boxes. Table on Page 54 shows box used for each electrical panel.
Page 20 Installation Fig. 15 – Electrical panel enclosure N6019 dimensions...
Page 21 Installation Touch Screen Control Panel Installation If air system will not be controlled by QuadraTouch Pro dryer console, a touch screen control panel must be installed. Image 2 shows touch screen. Fig. 16 shows dimensions of protective box for touch screen. Use hardware provided to attach mounting bracket shown in Fig.
Page 22 Installation Dynamic Bleed Valve Installation Attach air pressure sensor hose to blower as shown in Image 3 using clamp provided. Insert other end through bottom of power box using watertight fitting. Clamp hose to nozzle shown in Image 4. Image 3 – Air pressure sensor hose connected to blower outlet If not done already, connect wires from dynamic bleed valve Image 4 –...
Page 23 NOTE: Valve and tee assembly (J7552) supplied with Image 6– Loosening butterfly valve collar Sukup air systems can be installed and used with dynamic bleed valve. Image 7 – Setting valve to 0% open...
Page 24 Installation Wiring VFD for 3ph Power Image 9 shows Schneider variable frequency drive wiring for air system using 3-phase power. Connect violet wire #10B to terminal R1A, violet #10 to R1C, violet #11 to R2A, orange #18 to R2C, pink #21 to AQ1, blue STF to DI1, gray #31 to AI1, and black #95 to COM.
Page 25 Installation Adjusting Air System Current Sensing Settings Before running air system for first time, adjust current sensing settings using Table 7. Settings depend on VFD number. Minimum current setting is 0 for all VFDs. Pathway to screen shown below is: Settings → Advanced Settings →...
Page 26 Installation Mounting Distributor to Bin Wall If applicable, see Fig. 17 for mounting distributor to bin wall. Fig. 17 & Table 8 – Mounting distributor to bin wall SWAS0067 03/13/2006 JFJ DETAIL C DETAIL B...
Page 27 Installation Attaching Fill Auger If applicable, see Fig. 18 and Table 9 to attach fill auger to air system. Attach swivel assembly to airlock, then attach flexible connecting belt to inside of angle ring, cutting as needed to fit. SWAS0044 05/26/2006 JFJ Fig.
Page 28 Installation Mounting Deadhead See Fig. 19 and Table 10 for deadhead mounting guidance. Detailed views of deadheads are on Pages 68-73. Deadhead mounts to tube using hardware shown on adapter weldment or hinge assembly shown in applicable detailed view on Pages 68-73. Use N5594 or N5694 sidewall mounting brackets to mount tube to sidewall.
Page 29 Installation Mounting Cyclone See Fig. 20 and Table 11 for cyclone mounting guidance. Detailed view of cyclone is on Page 67. Cyclone mounts to tube using adapter weldment shown on Page 67. Attach support legs to cyclone using bolt holes provided, and to ribs of roof sheets. Adjust lengths of legs so each bears equal weight then tighten setscrews on lock collars.
Page 30: Operation
Operation Operation IMPORTANT: Emergency Stop Button is located on left side of main power box. Red light on button will come on as soon as incoming power is supplied to power box. Motors will turn off immediately if button is pressed.
Page 31 Operation Air system can be operated manually or automatically using Dynamic Bleed Valve (DBV). System can also be operated manually or automatically using optional Variable Frequency Drive (VFD). No matter which method is used, be aware of quality of grain that is entering and leaving air system. Any pneumatic system can cause damage unless care is taken to minimize velocity of grain as it travels through tubing to storage.
Page 32: Maintenance
Oil level in blower should be checked at sight glass on side of blower housing. See Page 17 for blower oil capacity. Use Sukup Manufacturing Co. oil, J3200 (qt size) or J3201 (5 gallon size) if required. Table 12 shows airlock gearbox lubricant based on ambient temperature of operation.
Page 33: Troubleshooting
See 3ph VFD wiring instructions on Page 24, and VFD settings on Pages 50-52. Links to VFD troubleshooting information can be found on Pages 50-51. • Use this link to view a video on optimal settings for a Sukup Air System: • https://www.youtube.com/watch?v=WVDEqTIfvHM Manual Tube Clean-out (Unplugging) Procedure 1.
Page 34: Software Manual
Software Manual Software Manual Sukup Automation Solutions ™ Cyclone Air System ™ Touching main page will bring up “Connected Air Systems” page. Each panel is capable of running five air systems from one display. Select desired system. Manual Control page will...
Page 35 Software Manual Manual Mode Manual Mode enables independent control of each part of the air system. VFD (if equipped) can run at whatever speed is desired. Dynamic Bleed Valve (DBV) controls how much air is blown through the tube. DBV automatically increases or decreases air pressure by oscillating its control valve.
Page 36 Loop Settings are shown on screen at left. Do not change any of these settings without help from a Sukup dealer or from Sukup Manufacturing Co. Basically, these settings change the way that the system reacts to controlling pressure in Automatic...
Page 37 Software Manual Auto Unplug Settings Auto Unplug feature allows air system to automatically clear a plug should one occur. Dynamic bleed valve forces more and more air into system, increasing pressure while making sure not to overload the motor. Settings can be changed to make unplug feature more or less aggressive.
Page 38 Control parameters for VFD (if so equipped) and DBV are shown at left. These are basic operating limits of these devices. Touch Sukup Logo at upper left at any time to reach diagnostics pages. All system values such as real-time analog and digital statuses can be...
Page 39 Software Manual Automatic Control Automatic Control mode will allow user to specify operating pressure. PLC will control pressure using either VFD (if equipped) or DBV. Auto control type needs to be specified by user. Pressure DBV is default control type (PID) on all systems. Screen at left will appear after touching Auto Control Type button.
Page 40 Emergency Stop E-Stop button is located at bottom left of all screens. Touching it will shut down air system and send a signal to other Sukup Automation Solutions equipment to inform them of shutdown. IMPORTANT: E-STOP button on side of control...
Page 41: Wiring Diagrams
Wiring Diagrams...
Page 42 Wiring Diagrams See diagram below for overview of Programmable Logic Controller (PLC) in main power box.
Page 43 Wiring Diagrams...
Page 44 Wiring Diagrams...
Page 45 Wiring Diagrams Wire #31 goes to terminal 1 if using Mitsubishi VFD...
Page 46 Wiring Diagrams...
Page 47 Cyclone Power Box Wiring Decals 3. Decal L0734 – Single Phase to Three Phase, Low Voltage (DC) Cyclone wiring decals are mounted at factory. Yearly and prior to equipment use, ensure that all decals are in legible condition and in place according to these instructions.
Page 48 Wiring Diagrams Decal L0736 – Dynamic Bleed Valve Wiring Decal L0735 – Single- to three-phase power converter, High Voltage (AC) Decal L0734 – Single Phase to Three Phase, Low Voltage (DC)
Page 49 Wiring Diagrams Decal L0924 – Single Phase to Three Phase Power Converter Wiring Note: Unused wires will not be present in conduits...
Page 50: Variable Frequency Drive Programming
ConF FuLL DrC- Ctt ConF FuLL Fun- Stt- *Based on site & drive Troubleshooting Altivar 320 A complete copy of Altivar Machine ATV320 Variable Frequency Drives Programming Manual, NVE41295, dated 09/2021, can be found on Sukup website and at www.schneider-electric.com...
Page 51 7. Repeat Steps 4 through 6 until all parameters are set. 8. When done programming, return to main screen by pressing MODE button three times. Troubleshooting Mitsubishi F800 A copy of Mitsubishi F800 Protective Functions chapter can be found on Sukup website at this location: https://www.sukup.com/assets/general-docs/Mitsubishi_F800_Protective_Functions_6.pdf...
Page 52 VFD Programming Motor OL Amps...
Page 53 VFD Programming NOTE: Information below is from Mitsubishi Electric Inverter FR-F800 Instruction Manual. Monitoring Inverter Status Monitoring of Output Current & Output Voltage NOTE: Pressing SET in Monitor mode switches monitored item to Output Frequency, Output Current and then to Output Voltage. 1.
Page 54: Electrical Requirements
Electrical Requirements See Table 13 for electrical requirements based on electrical panel number. Panel number is found on white sticker inside of power box. Far right column identifies panel enclosure box. See Pages 19-20 for box dimensions. Blower Airlock Airlock Blower Airlock Total...
Page 55 Notes NOTES ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________...
Page 56: Parts/Assemblies
Parts/Assemblies PARTS/ASSEMBLIES 5″ AIRLOCK ASSY. (N51051) SWAS0025 03/28/2003 JFJ...
Page 57 Parts/Assemblies 5″ AIRLOCK ASSY. (N51051) REF. # DESCRIPTION QTY. PART # Stand assembly w/ skids N5478 Meyer airlock gasket, 14” J7513 Airlock transition weldment N55401 Meyer airlock, 14”, w/ gasket J7512 Spacer, reducer – 7ga, galvanized N5419 Shim, reducer N54191 Gear, reducer, 60:1 J3679 Screw, 1/2 –...
Page 58 Parts/Assemblies 6″ AIRLOCK ASSY. (N5605) SWAS0026 03/28/2003 JFJ...
Page 59 Parts/Assemblies 6″ AIRLOCK ASSY. (N5605) REF. # DESCRIPTION QTY. PART # Stand assembly w/ skids N5650 Spacer, reducer – 7ga, galvanized N5419 Shim, reducer N54191 Gear, reducer, 60:1 J3679 Screw, 1/2 – 13 x 2” J0737 Lock nut, 1/2" – 13 J1042 Flat washer, 3/8”...
Page 60 Parts/Assemblies 5″ DUROFLOW BLOWER ASSY. (N51252, N51253 & N51254) SWAS0023 04/06/2006 JFJ...
Page 61 Parts/Assemblies 5″ DUROFLOW BLOWER ASSY. – N51252, N51253 & N51254 20HP 1ph 20HP 3ph 30HP 3ph 40HP 3ph REF. # DESCRIPTION PART # PART # PART # PART # Stand assembly w/ skids N5475 N5475 N5475 N5475 Blower J7500 J7500 J7500 J7500 Shield...
Page 62 Parts/Assemblies 6″ DUROFLOW BLOWER ASSY. (N5624, N5625 & N5626) SWAS0024 04/06/2006 JFJ...
Page 63 Parts/Assemblies 6″ DUROFLOW BLOWER ASSY. (N5624, N5625 & N5626) 40HP 3ph 50HP 3ph 60HP 3ph 75HP 3ph REF. # DESCRIPTION PART # PART # PART # PART # Stand assembly w/ skids N5650 N5650 N5650 N5650 Blower J7504 J7504 J7504 J7504 Shield N5467...
Page 64 Parts/Assemblies 7-VALVE DISTRIBUTOR ASSY. FOR 5″ & 6″ SWAS0062 01/19/2006 JFJ...
Page 65 Parts/Assemblies 7-VALVE DISTRIBUTOR ASSY. FOR 5″ & 6″ 5″ 6″ N56651B N56661B REF. # DESCRIPTION QTY. PART # QTY. PART # Inlet plate N56552-01B N5675-03B Offset tube weldment N5656B N5676B Grease zerk, 1/8” J36092 J36092 O-ring, 3/16”, Neoprene J3557 J3555 Side channel N5652 N5672...
Page 66 Parts/Assemblies DISTRIBUTION VALVE TEMPLATE ASSY. SWAS0068 03/16/2006 JFJ REF. # DESCRIPTION QTY. PART # Plate weldment, 5” N5610 Plate weldment, 6” N5611 U-bolt, 5/16 – 18 x 5.19” ID x 6-1/2”deep J05205 U-bolt, 5/16 – 18 x 6.19” ID x 6-1/2”deep J05206 Wall mounting channel, top N5603...
Page 67 Parts/Assemblies CYCLONE ASSEMBLY & ADAPTORS – N5504 SWAS0011 09/06/2004 JFJ REF. # DESCRIPTION QTY. PART # Cyclone weldment N55001 Air exhaust weldment cap N55011 Cyclone liner, 1/4" thick N5503A Adapter weldment, 5” tube N5502 Adapter weldment, 6” tube N5602 Bolt, 5/16 - 18 x 3/4"...
Page 68 Parts/Assemblies 5″ DEADHEAD ASSEMBLY – N55600 N55600 09/21/2018 DV REF. # DESCRIPTION QTY. PART # Bottom N55602 N55603 End panel N55604 Adapter weldment N55605 Side panel N55608 Back panel N55609 Front panel N55610 Spout, sq./round, 8” F47981 Huckbolt, 1/4 x 5/8” J0892 Huckbolt sleeve, 1/4”...
Page 69 Parts/Assemblies 6″ DEADHEAD ASSEMBLY – N56600 N56600 09/28/2018 DV REF. # DESCRIPTION QTY. PART # Bottom N56602 N56603 End panel N56604 Adapter weldment N56605 Side panel N56608 Back panel N56609 Front panel N56610 Spout, sq./rd., 10” E56371 Huckbolt, 1/4 x 5/8” J0892 Huckbolt sleeve, 1/4”...
Page 70 Parts/Assemblies 5″ HINGED DEADHEAD ASSEMBLY – N55611 N55611 09/24/2018 DV REF. # DESCRIPTION QTY. PART # Bottom N55607 N55603 End panel N55604 Hinge assy. N55613 Side panel N55608 Back panel N55609 Front panel N55610 Spout, sq./round, 8” F47981 Huckbolt, 1/4 x 5/8” J0892 Huckbolt sleeve, 1/4”...
Page 71 Parts/Assemblies 5″ ,90° HINGED DEADHEAD ASSEMBLY – N55612 N55612 09/24/2018 DV REF. # DESCRIPTION QTY. PART # Bottom N55607 N55603 End panel N55604 Hinge assy. N55613 Side panel N55608A Front/Back panel N55609A Spout, sq./round, 8” F47981 Flat washer, 3/8” J1117 Lock washer, 3/8”...
Page 72 Parts/Assemblies 6″ HINGED DEADHEAD ASSEMBLY – N56611 N56611 09/29/2018 DV REF. # DESCRIPTION QTY. PART # Bottom N56607 N56603 End panel N56604 Hinge assy. N56613 Side panel N56608 Back panel N56609 Front panel N56610 Spout, sq./round, 10” E56371 Huckbolt, 1/4 x 5/8” J0892 Huckbolt sleeve, 1/4”...
Page 73 Parts/Assemblies 6″ ,90° HINGED DEADHEAD ASSEMBLY – N56612 N56612 09/29/2018 DV REF. # DESCRIPTION QTY. PART # Bottom N56607 N56603 End panel N56604 Hinge assy. N56613 Side panel N56608A Front/Back panel N56609A Spout, sq./round, 10” E56371 Huckbolt, 1/4 x 5/8” J0892 Huckbolt sleeve, 1/4”...
Page 74 Parts/Assemblies CYCLONE TRUSS KITS 5” TUBE – N5537; 6” TUBE – F4814 SWAS0049 11/15/2006 JFJ 5″ TUBE 6″ TUBE REF. # DESCRIPTION QTY. PART # QTY. PART # Half band, galvanized N5526 F48291 Truss bracket N5545 F4997-02 Truss leg F4995-03...
Page 75 Parts/Assemblies COMPRESSION COUPLER SWAS0060 10/05/2006 JFJ REF. # DESCRIPTION QTY. PART # 5” Compression coupler J7522 6” Compression coupler J7560 Compression coupler liner W/GRD strip, 5” J7524 Compression coupler liner W/GRD strip, 6” J7519 Stainless steel gasket protector, 5” J7594 Stainless steel gasket protector, 6”...
Page 76 Parts/Assemblies FEMALE CAMLOCK ASSEMBLY PARTS J7541 (5” tube stub) & J7564 (6” tube stub) (See Page 11 for male camlock assy. part numbers) SWAS0050 10/01/2003 JFJ TELESCOPING FEMALE CAMLOCK ASSEMBLY N5590 (5” tube) & N5690 (6” tube) 5″ TUBE 6″ TUBE REF.
Page 77 Parts/Assemblies PRE-CLEANER ASSEMBLY - N5351 SWAS0066 05/17/2006 JFJ FILTER AND TUBE ARE NOT PART OF KIT REF. # DESCRIPTION QTY. PART # Tube weldment, Solberg filter extension N55295 Pre-cleaner weldment base N5354 Element w/ pre-filter, Solberg #244P J7584 Filter top plate, 10” dia. N5355 Neoprene washer, 3/8”...
Page 78 Parts/Assemblies FILL AUGER 8″ x 10’ – G7109 8″ x 8’ – G7108 SWAS0072 05/26/2006 JFJ...
Page 79 Parts/Assemblies FILL AUGER PARTS 8″ x 10’ – G7109 8″ x 8’ – G7108 REF. # DESCRIPTION QTY. PART # Screw, 7/16 - 14 x 2-1/2” J0720 Shaft, 1-1/4 x 9” G73291 Lock washer, 7/16” J1210 Nut, 7/16” - 14 J1035 Auger, w/ shafts, 8”...
Page 80: Contact Information
Contact Information CONTACT INFORMATION Sukup Dealer Information Dealer name: Address: Cell phone: Office phone: Fax: In Case of Emergency Have emergency numbers and written directions to your location near a phone. Arrange and practice a safety plan. Ambulance • Fire • Police: 9-1-1...
