Technical Information - Reloop MOVE 15 SUB Instruction Manual

TECHNICAL INFORMATION

Global Distribution GmbH did not test the following manufacturers' specification for plausibility and accuracy:
General specifications:
Inputs: ........................... Line In 2x XLR
Outputs: ........................ Line Out 2x XLR
Frequency response: ...... 35 Hz - 125 Hz +/- 3 dB
RMS output: .................. 1500 W
Max. output: .................. 3000 W
Sound pressure level: ..... 128 dB/136 dB (peak)
Mains voltage: ............... AC100V – AC240V
Mains connection: .......... Standard IEC
Dimensions: ................... 440 x 500 x 545 mm
Weight: .......................... 29 kg
Reloop Distribution
Global Distribution GmbH
Schuckertstr. 28
48153 Münster
Germany
Fax ++49/251/6099368
