Williams 96 LED Series Installation Instructions

WARNING:
• This product must be installed in accordance with the applicable
installation code by a person familiar with the construction and
operation of the product and the hazards involved.
• Make sure all electrical power is turned off while installing the fixture.
• This luminaire must be adequately grounded for protection against
shock hazards and to assure proper operation.
FIXTURE DETAIL
Use the illustrations below when assembling or disassembling the fixture. (96, 4' shown)
Fiberglass housing
Wireway cover
BACKVIEW
A
B
Nominal Overall
Length Length (A)
2' 27-5/8"
4' 51-7/8"
8' 100-1/4"
H.E. Williams, Inc. Carthage, Missouri
03/16/16JL
End plug
Lens
Mounting
Distance (B)
12"- 17" OC
30"- 42" OC
48"- 80" OC
w w w.hew.com
96 & 97 LED SERIES
• Disconnect power before servicing.
• LEDs are ESD (Electro Static Discharge) sensitive devices that can be
easily damaged if the proper ESD mitigating steps are not taken.
• LEDs are very sensitive to mechanical damage. Caution must be taken
to avoid damage to the LEDs.
• ESD or mechanical damage voids all warranties.
Mounting bracket
Latch
417-358-4065
INSTALLATION INSTRUCTIONS
Page 1 of 2
PN 49090174
