Ardwolf A30 User Manual

Keypad door lock
Hide thumbs Also See for A30:

Advertisement

Quick Links

Customer Service
Email: service@ardwolf.com
Address: 12240 East End Ave Chino CA 91710 United States
www.ardwolf.com
Content
Product Introductio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Programming. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Functions Detail. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Routine maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . .
2、A31
Back Handle
Back
3. Product Features
Three ways to unlock: User Code, Mifare Card or Key.
Up to 200 user codes can be programmed into the lock.(user code is
between 4-8 digits )
Up to 200 Mifare Card can be programmed into the lock.
Up to 10 service codes can be programmed to each lock for special
purpose, service code can only grant one time access.
Page 02
5. Packing List
1. Front Panel
2. Back Panel
5. Lock Bolt
6. Bolt Protector
10. Pin
9. Square Spindle
(for square spindle fixing)
13. Fixing Screw x 3 (B1)
Fixing Screw x 3 (B2)
14. Screw x 1 (C)
Use B1 or B2 for fixing,
(for front panel fixing)
depends on door thickness
A30
A31
Ardwolf Keypad Door Lock
User Manual
17. Screw x 1 (F)
(for the screw "C" fixing)
18. User Manual
Page 04
2. Installation Tools
1. Pencil
4. Power Drill
7. Utility Knife
Page 06
2. Drill Holes
Strike Plate
Lock Bolt
Fixing Screw x4 (A)
Drill Holes on the door according to the requirements of the
Drill Holes template
Screw (F)
Screw(C)
Pin
Screw(D)
Square Spindle
Page 08
5. The inside chassis installation
a. Put on the waterproof rubber pad,
get the wire through from the "wire
hole" which on
b. Install the inside chassis, fixing it by
using screws of "B1" or "B2" which
depends on the thickness of the door.
c. Connect the wire to the hub on the
inside chassis.
Fixing Screw
(B1)/(B2)
6. Install the battery and back panel
a. Install 4 AA Alkaline batteries.
b. Fixing the back panel by two
screws of "E"
Page 10
Programming
General Information
Exit setting mode:
Enter * to exit the setting procedure, or wait for 10 seconds
Low battery warning:
When the voltage drops below 4.8V,after entering a
valid code, the LED will flash red and beep five times.
Unlocking indicator:
Green light will flash and beep twice.
Locking indicator:
Red light will flash and beep three times.
Reset:
Set the lock back to manufacturer default. Press and hold the reset
button for about 10 seconds (3 beeps with LED blink red). The reset button is
located below the battery compartment. (See Picture)
Manufacturer default settings
Daylight Savings:
Disabled
Auto unlock/lock:
Disabled
Default programming code:
123456
Lock mode:
Storehouse
Construction code:
0 #
12
Service code:
Service codes are used for special purposes such as maintenance
personnel or vendors. Service code only grants one time access. Total of 10 sets of
service codes can be programmed to each lock.
Index No.*:
For each user code or user card. It is associate with a unique number,
we call it index No. (or slot No.). The Index No. is auto generated by lock and starts
with 001. The highest Index No. will be 200. Total user index is 200 that can be
added to each lock. (* Please log the user code along with its index No. for adding
or deleting references)
Passage mode:
When Passage Mode is enabled, the lock will stay in unlocked
status after first valid entry.
Storehouse mode (Lock-back mode):
cally lock in 5 seconds.
Lockout mode:
Enable the Lockout mode will freeze the lock at its current status
(Lock or unlock), temporarily disable all the user codes and user code. Re-enter
the function code 99 to disable the lockout mode, and resume normal operation.
Reset lock memory:Press and hold reset button for about 10 seconds with 3 short
beeps; it will delete all the codes, cards, and restore back to factory default set-
ting.
Reset lock memory:
Press and hold reset button for about 10 seconds with 3
short beeps; it will delete all the codes,cards, and restore back to factory default
setting.
Time format:
0830 = 8:30AM; 1730 = 5:30PM
Schedule Date:
1=Mon, 2=Tue, 3=Wed, 4=Thu, 5=Fri, 6=Sat,7=Sun
Functions Detail
1. How to change master code (but not delete existing users)
▲Function Code: 11#
{#}+{default master code#}+{11#}+{new master code#}+{new master code#}
2. How to change master code (and delete all existing users)
▲Function Code: 22#
{#}+{current master code#}+{22#}+{new master code#}+ {new master
code#}
Page 14
10. How to add user code + user card as dual user (no time
restriction)
▲Function Code: 01#
{#Master code#}+{01#}+{index No. #}+ {user code#}+{touch card # #}
11. How to add one user card (with time restriction)
▲Function Code: 01#
{#Master code#}+{01#}+{index No. #}+ touch {card}+{yymmddhhmm#(start
time)}+{yymmddhhmm#(ending time)}
12. How to add multi-user card (with time restriction)
▲Function Code: 01#
{#Master code#}+{01#}+{index No. #}+ touch {card (1)}+{yymmddhhmm#
(start time ) } + {yymmddhhmm#(end time)} +{index No. #}+ touch {card
(2)} +{yymmddhhmm#(start)}+ {yymmddhhmm#(end time)}...and so on
13. How to disable one user code or user card with index No.
▲Function Code: 02#
{#Master code#}+{02#}+{index No.#}
14. How to enable one user code or user card with index No.
▲Function Code: 03#
{#Master code#}+{03#}+{index No.#}
15. How to enable passage mode and schedule (lock back
when the passage mode end)
▲Function Code: 15#
{#Program#}+{15#}+{weekly schedule}+{#}+{begin time & ending time#}
16. How to disable passage mode
▲Function Code: 16#
{#Master#}+{16#}
Page 16
25.How to setup auto-lock time (it will auto lock the door
everyday at assigned time)
▲Function Code: 66#
{#Master code#}+{66#}+{HHMM#}+{HHMM#}
26. How to disable auto-lock function
▲Function Code: 68#
{#Master code#}+{68#}
27. How to enable / disable Lock-out mode (lock out all the
users if enabled)
▲Function Code: 99#
{#Master#}+{99#}
28. How to program scheduling by week & time
▲Function Code: 45#
st
1
enable daylight saving
nd
2
set up date & time (use 88# function code)
rd
3
adding user code or user card in advance (see No.5 or No.9 how to add
user code & user card)
th
4
program schedule (as below example)
Weekly Schedule Format
Sun
Mon
Tue
Wed
7
1
2
Formula:
{#master code#}+{function code#}+{user code# or card}+{weekly
schedule day#}+{begin time & ending time#}
Page 18
Page 20
Dimension: 6.0 X 3.1 X 2.7 inch
Material: Zinc Alloy
Weight: 5.1 lbs
Sensor Area
Keypad
Lock Bolt
Front Handle
Side
Front
3. Waterproof Rubber Pad
4. Inside Chassis
7. Wrench
8. Strike Plate
12. Fixing Screw x4 (A)
11. Mechanical Key
(for strike plate fixing)
15. Screw x 2 (D)
16. Screw x 2 (E)
(for front panel fixing)
(for back panel fixing)
19. Mifare Card x 2
20. Hole Drilling Template
2. Tape Measure
3. Square Measure
5. Drill Bits
6. Hammer
8. Phillips Screwdriver
9. Chisel
60-70mm
Reset Button
For each valid entry, lock will automati-
Thu
Fri
Sat
3
4
5
6
A30
Ardwolf Keypad Door Lock
1、A30
01
05
12
14
21
Dimension: 6.0 X 3.1 X 2.7 inch
Material: Zinc Alloy
Weight: 5.1 lbs
Back Handle
Scheduling can be programmed, usage restriction policy can be set between time
periods for both user code and mifare card.
Automatic locking: for each valid entry, lock will automatically lock in 5 sec.
Reversible lever: fits both left-handed and right-handed doors.
Trial and Error Protection improves safety in the application environment
Normal open/cancel operation makes it easy for users to set up and cancel
Multi-level management functionality allows users to locate/delete user info in
the lock's internal memory, suitable for different application environments
4. Product Specifications:
Standard 12-key keypad
Fit door thickness between 1.38" and 1.77"
Factory default user code is "123456." The fixed length of master password is 6
digits
Engineering password is fixed at "0". After modifying the master password, engi-
neering password will be disabled.
Service code is any number between 1-6 digits
The fixed length of temporary master password is 14 digits
Card Type: Mifare S50 Card
Reading Distance: appr. 2.5cm/1'
Powered by 4 AA alkaline batteries (NOT included)
NOT warterproof
Static Power: 30uA
Dynamic Power: 200mA
1. Installation conditions
Door frame≥110mm (for Inconsistent door thickness ) 35mm≤Door Thickness
≤45mm (More Than 45mm Need To Custom Accessories)
1.2 Confirm The Direction of the door
Door frame≥110mm (for Inconsistent door thickness ) 35mm≤Door Thickness
≤45mm (More Than 45mm Neved To Custom Accessories)
How to adjust the direction of lock handle
Front Panel
1. Remove the 8 small screws
2. Take out the mechanical system
slightly. Do not damage the wire.
3. Remove the screw holding the
handle, then adjust the handle
direction as desired
4. Assemble the screws back
3. Drill Holes On Door
Below is the Drill Holes Template
30
23
1
4. Installation Steps
1. Draw lines
a. To draw a horizontal centerline on
both sides of the inner and outer
door one meter from the ground.
b. Fold Drill Holes Template, align
the handle centerline with the hori-
zontal line on the door, draw the
f r o n t a n d s i d e d r i l l h o l e s l i n e s
according to the requirements of
the Drill Holes template.
3. Install Latch
Install the latch to the hole,and fix
it by using two "A" screws.
4. The front panel installation
a. Connect the screws of "C" and
"F", then fix it in the hole which be
showed on the front panel
b. Fix the screws of "D" on the front
panel
c. Insert the square spindle, fix it by
the "pin" which get through the
small hole in the spindle and the
front panel. Be sure to bend the pin
for fixing.
d. Put on the waterproof rubber pad
e. Align the cylinder holes, install the
front panel.The wire get through
from the main hole.
7. Installation Test
a. Check the flexibility of outside and inside handle
b. Check if the Mechanical keys works
Steps to setup a new lock (please follow the order)
a.
Change master code (For example, change to 1234) # 123456 # 11 # 1234 #
1234 #
Enable daylight saving (optional) # 1234 # 31 #
b.
Set lock time (optional) (For example, set time as January 23, 2008, 2:45PM) #
1234 # 88 # 0801231445#
Add user code (For example, add 1357 to the lock, 001 is index No.) # 1234 #
c.
01 # 001# 1357 # # #
Add user card (Optional.002 is index No.) # 1234 # 01 # 002 # touch MF card
d.
onto reader ## # (wait light goes off)
Set schedule for user code or user card (see 29 How to program schedule
week & time)
Steps to setup a new lock (please follow the order)
Key code:
Key card:
Key card +Key code:
code, #
One time service code:
Mechanical key:
handle
Terms
Master code:
lock/unlock the lock. When # sign is pressed, the red LED will start to flash indicat-
ing the lock is now in programming mode. If more than 6 seconds have passed in
between programming entries, the lock will return to normal operational status.
For maximum security it is recommended to change the default Master Code.
Construction code:
testing the lock. The code will be deleted after the first new user code is added to
the lock.
User code:
3. How to set date and time
▲Function Code: 88#
{#Master code#}+{88#}+{yymmddhhmm#}
4. How to add one user code (no time restriction)
▲Function Code: 01#
{#Master code#}+{01#}+{index No. #}+{user code# # #}
5. How to add multi-user code (no time restriction)
▲Function Code: 01#
{#Master code#}+{01#}+{index No. #}+{user code(1)# # #}+{index No. #}+{user
code(2)# # #}+{index No. #}+{user code3###} ... and more if needed
6. How to add one user access code (with time restriction)
▲Function Code: 01#
{#Master code#}+{01#}+{index No. #}+{user code#}+{yymmddhhmm#(start
time)}+{yymmddhhmm#(ending time)}
7. How to add multi-user code (with time restriction)
▲Function Code: 01#
{#Master code#}+{01#}+{index No. #}+{user code#(1)}+{yymmddhhmm#
(start)}+{yymmddhhmm# (ending time)}+ {index No. #}+ {user code#(2)} +
{yymmddhhmm#(start)} + {yymmddhhmm#(ending)} ...and more if needed
8. How to add one user card (no time restriction)
▲Function Code: 01#
{#Master code#}+{01#}+{index No. #}+{touch card # #}
9. How to add multi-user card (no time restriction)
▲Function Code: 01#
{#Master code#}+{01#}+{index No. #}+{card (1)# #}+{index No. #}+{card (2)#
#} ...and more if needed
17. How to enable LED blink light (on & off)
▲Function Code: 34# & 35#
{#Master code#}+{34# & 35#}
18. How to set up one time service code (up to 10 service codes)
▲Function Code: 33#
{#Master code#}+{33#}+{service code(1)#}+ {service code(2)#}+... and so on
19. How to delete all one time service codes
▲Function Code: 23#
{#Master code#}+{23#}
20. How to delete user code or user card with index #
▲Function Code: 44#
{#Master code#}+{44#}+{index#}
21. How to enable auto-unlock function
▲Function Code: 64#
{#Master code#}+{64#}
22. How to setup auto-unlock time (it will auto unlock the door
everyday at assigned time)
▲Function Code: 63#
{#Master code#}+{63#}+{HHMM#}+{HHMM#}
23. How to disable auto-unlock function
▲Function Code: 65#
{#Master code#}+{65#}
24. How to enable auto-lock function
▲Function Code: 67#
{#Master code#}+{67#}
How to schedule with a "User code"
Example: schedule for user code "2222" which will grant access Mon., Wed.
and Fri., from 8:30AM to 5:30PM
#1357#
Master
code
How to schedule with an "User card"
Example: schedule for user card which will grant access Mon., Wed. and Fri.,
from 8:30AM to 5:30PM
#1357#
Master
code
How to schedule with "User-code + user card"
Example: schedule for code "1357" + card which will grant access Mon.,
Wed. and Fri., from 8:30AM to 5:30PM
#1357#
Master
code
How to schedule passage mode (also see number 16.)
Example: schedule passage mode Monday to Friday, 8:30AM to 5:30PM
#1357#
Master
code
Please keep your fingers clean when use the product.
Avoiding contact with corrosive substances or liquids so as to affect the appear-
ance of the body.
Strictly prohibit hard objects to knock fingerprint reading head surface to prevent
damage and affect the normal use.
If the fingerprint capture window surface is dirty that may affect the normal use of
locks. Please keep window clean everyday.
Safekeeping of the keys, when the fingerprint or password can not open door,
please use the keys.
Please change battery when Low-voltage alarming, so as not to affect the normal
use of locks.
Lock surface can be used furniture polish wax to keep glossy.
Do not use water or alcohol to clean fingerprint capture window. Only permit to
use soft cloth to sweat stains of the collector window.
User Manual
Product Introduction
Back
Side
Installation Guide
Interior
Interior
Wall
Door
Door
Door Open Direction
Back Panel
1. Remove the screws holding the
2. Assemble the screws back
Handle Centerline
20
3
28
User Code, #
Card key touch lock reader
card touch lock reader, LED grow green, enter user
One time code, #
Turn the override key 90 degree clockwise, then turn the
The master code puts the lock into a programming mode. It won't
Installer code is a default temporary code (0) for installer to
User code is the normal code for day-to-day operations.
45#
2222#
135#
Function
User code Schedule Beginning
code
45#
Card#
135#
Function
Card
Schedule
code
2222# +
45#
135#
card
Function
User code +
Schedule
code
user card
15#
12345#
Function
Beginning
Schedule
code
Routine maintenance
A31
Switch Button
Sensor Area
Keypad
Lock Bolt
Front Handle
Front
Page 01
Page 03
Interior
Interior
Wall
Door
Door
handle, adjust the handle
direction as desired
screw position
Page 05
Unit:mm
90
3
18
60
26
Page 07
Page 09
Mechanical Key
Page 11
Page 13
Page 15
Page 17
0830
1730#
Ending time
time
0830
1730#
Beginning
Ending
time
time
0830
1730#
Beginning
Ending
time
time
0830
1730#
Ending time
time
Page 19
Page 21

Advertisement

loading
Need help?

Need help?

Do you have a question about the A30 and is the answer not in the manual?

Questions and answers

Related Products for Ardwolf A30

This manual is also suitable for:

A31
