FONESTAR ARRAY-300A Instruction Manual

Amplified line array
Hide thumbs

Advertisement

Quick Links

Download this manual
RR Y-300
AMPLIFIED LINE ARRAY
INSTRUCTION MANUAL

Advertisement

loading

Related Manuals for FONESTAR ARRAY-300A

Summary of Contents for FONESTAR ARRAY-300A

  • Page 1 RR Y-300 AMPLIFIED LINE ARRAY INSTRUCTION MANUAL...
  • Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.

  • Page 3: Exemption Of Liability

    The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use.
  • Page 4 DESCRIPTION - Compact amplified line array system for fixed or mobile installations. - Amplified subwoofer with output for mid-treble loudspeakers with adjustable tilt of 0º to 8º in steps of 2º. - Manufactured in reinforced plywood with highly resistant textured paint finish. CONTROLS AND FUNCTIONS REAR PANEL OF SUBWOOFER FULL RANGE OUTPUT: line level signal output, XLR connector.
  • Page 5 10.- SUBWOOFER PROTECT: LED subwoofer protection signal indicator. It lights up when the line array protection is activated. With the protection activated it cuts off the subwoofer audio output. In this case, switch off the line array, correct the causes of the fault and let the device reset itself for a few minutes before switching it back on again.

  • Page 6: Installation

    CONNECTION - Before connecting the power supply, make sure that the volume controls are at their minimum and that the POWER switch is off. - Connect the device’s power supply cable to the mains supply. - Connect a line level signal coming from a mixer, CD player, etc. to the subwoofer’s FULL RANGE LINE INPUT.
  • Page 7 The most common and suitable way is to hang it with the rigging system. To do so, this ARRAY-300A already has an upper mount installed on the subwoofer with a central anchor point. This mount offers the possibility of hanging from four points which allows the tilt angle to be changed.
  • Page 8 - Finally, position the rest of the loudspeakers one by one, first fixing the front part and then the rear. In the case of the rear anchor between the mid-treble loudspeakers, the connecting system is the same as that previously described except that it has the possibility of using different angles (0º, 2º, 4º, 6º or 8º). This is possible thanks to the holes the anchorage parts have, as can be seen in the following image.

  • Page 9: Technical Specifications

    TECHNICAL SPECIFICATIONS ARRAY-300A CHARACTERISTICS Compact amplified line array system. Amplified subwoofer with output for mid-treble loudspeakers with adjustable tilt from 0 to 8º in steps of 2º. Manufactured in reinforced plywood with highly resistant textured paint finish. Suspension system and accessories.

  • Page 10: Warranty

    2 months after being conscious of the problem. It is only necessary to contact FONESTAR if it is impossible or imposes an undue burden for them to solve it. To benefit from this warranty it is necessary to show the proof of purchase with the date clearly visible, with no corrections or crossing out.
